Summary of Contents for Spectrum Digital RS485
- Page 1 RS485 Cable For AppBox System User’s Guide RS485 Cable System User’s Guide AppBox...
- Page 2 Notice ! Spectrum Digital, Inc (SDI) provides the enclosed product under the following conditions: The user/customer assumes ALL responsibility and liability for the proper use, storage, and safe handling of the product. Further, the user indemnifies SDI from all claims arising from the use, installation, storage, and handling of the product.
-
Page 3: Table Of Contents
RS485 Cable Product Contents ........ -
Page 4: Introduction
This document describes the RS485 cable (Part/SKU #: 703917-0001) used with the AppBox. This cable brings the RS485 signals off the AppBox C21/D21/E54/E70 J2 connector or J2 image connector on the Distribution Box to a device that has a RS485 interface. -
Page 5: Rs485 Cable Product Contents
1.4 RS485 Cable AppBox / Distribution Box Connector The RS485 cable end which plugs into the AppBox J2 connector or Distribution Box is a molded 10 pin (2 rows x 5 pin) connector. A view of this connector is shown below. -
Page 6: Rs485 Cable Rs485 Device Connector
1.5 RS485 Cable RS485 Device Connector The RS485 cable end which plugs into a RS485 device is a female 9 pin D-sub connector. A view of this connector is shown below. Pin 1 Pin 5 Screw Screw Pin 6 Pin 9... - Page 9 Spectrum Digital, Inc PO Box 1559 Sugar Land, TX. 77487-1559 Web site: www.spectrumdigital.com Sales: sales@spectrumdigital.com Support: support@spectrumdigital.com Copyright Spectrum Digital Inc, © 2020 519178-0001 RS485 Cable System User’s Guide AppBox...
