  • Page 1 MANUALE TECHNICAL MANUAL TECNICO MANUAL TÉCNICO 080414 E DALI/DMX...
  • Page 2 MORSETTI DI COLLEGAMENTO Morsetto Funzione Negativo alimentazione BUS +24Vdc alimentazione BUS Linea BUS dati 0 Vdc B (RX) Linea B DMX512 A (TX) Linea A DMX512 PWR1 Ingresso alimentatore DALI DALI1 DALI DALI2 DALI PWR2 Ingresso alimentatore DALI...
  • Page 3 Modulo interfaccia per protocolli DALI o DMX512. Su bus DALI permette la gestione di lampade e/o alimentatori. E’ prevista la gestione dei 64 indirizzi previsti dal protocollo, delle 16 zone e 16 scenari. Ogni singolo canale può essere usato come on-off, dimmer. Su bus DMX512 permette la gestione di lampade e/o alimentatori RGB.
  • Page 4 CONNECTION TERMINALS Terminal Function BUS power supply negative BUS power supply +24 Vdc BUS data line 0 Vdc B (RX) Line B DMX512 A (TX) Line A DMX512 PWR1 DALI power supply input DALI1 DALI DALI2 DALI PWR2 DALI power supply input...
  • Page 5 Interface module for DALI or DMX512 protocol. DALI bus allows the management of lamps and / or power supplies. And ‘intended to manage the 64 addresses under the Kyoto Protocol, the 16 zones and 16 scenari.Ogni single channel can be used as on-off dimmer. On DMX512 bus allows the management of lamps and / or power RGB.
  • Page 6 BORNES DE CONEXIÓN Borne Función Negativo de alimentación BUS +24 Vcc de alimentación BUS Línea BUS datos 0 Vdc B (RX) Línea B DMX512 A (TX) Línea A DMX512 PWR1 Entrada de alimentación DALI DALI1 DALI DALI2 DALI PWR2 Entrada de alimentación DALI...
  • Page 7 Módulo de interfaz para DALI o el protocolo DMX512. Bus DALI permite la gestión de las lámparas y / o fuentes de alimentación. Y ‘la intención de gestionar las direcciones 64 del Protocolo de Kyoto, las 16 zonas y 16 scenari.Ogni un solo canal se puede utilizar como regulador de encendido y apagado.
  • Page 8 Avvertenze • Effettuare l’installazione seguendo scrupolosamente le istruzioni fornite dal costruttore ed in conformità alle norme vigenti. • Tutti gli apparecchi devono essere destinati esclusivamente all’uso per cui sono stati concepiti. Videotrend srl declina ogni responsabilità per un utilizzo improprio degli apparecchi, per modifiche effettuate da altri a qualunque titolo e scopo, per l’uso di accessori e materiali non originali. • Tutti i prodotti sono conformi alle prescrizioni delle direttive 2006/95/CE (che sostituisce la direttiva 73/23/CEE e successivi emendamenti) e ciò...
