Arkon Slim-Grip Ultra MC25MM632 Manual

MC25MM632 | Slim-Grip® Ultra™ 25mm Handlebar Phone or Midsize Tablet Mount MC25MM632 | Slim-Grip® Ultra™ 25mm Handlebar Phone or Midsize Tablet Mount
APRM2T
SP-RMS250
1
Place handlebar spacer/adapter ring around handlebar. Attach mount
to handlebar around spacer. Use the included hex key to securely
tighten both mounting screws.
Mounting Screw
3
Attach strap by inserting the strap's Dual T-Tabs in to the holder's Dual
T-Slots. Attach adapter by inserting the adapter's Dual T-Tabs into the
strap's Dual T-Slots. Insert screw to secure.
Dual T-Slots
Dual T-Tabs s
Safety Precautions
! !
Arkon is not responsible for any damages caused to your vehicle, your
device, or yourself due to the installation or use of this mount.
MC25MMB SM060-2
Mounting Screw
H Handlebar Spacer/
Adapter Ring
Package Contents:
(1) MC25MMB –Motorcycle Handlebar Mount
(1) SP-RMS250 – Small Robust Mount Shaft
(1) SM060-2 – Slim-Grip
(1) APRM2T – 25mm Ball to Dual T-Tab Adapter
(1) AP2TSTRAP – Dual T-Slot to Dual T-Tab Elastic Securing Strap
This Motorcycle Mount fi ts cylindrical handlebars up to 30mm diameter
and comes with 3 handlebar spacer/adapter rings of different widths.
AP2TSTRAP
Select the appropriate size for optimum mounting to your handlebar.
The Slim-Grip® Ultra™ Universal Smartphone & Tablet Holder fi ts devices
up to 7.5 inches tall.
2
Attach Robust Mount Shaft by unscrewing knob to loosen collar.
Adjust angle then retighten knob to secure.
4
Attach the assembled mobile phone holder by combining the adapter
to the Robust Mount Shaft and tightening to secure.
Set Screw
Consumer Hotline:
USA
(800) 841-0884
INT'L (626) 254-9005
Monday - Friday 9am - 5pm, PST
® Ultra ™ Universal Smartphone & Tablet Holder
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China
