Afrison Meru Installation And Technical Instructions

Part number breakdown
Part number: AA BBB CC D E F G
AA
FL Flood light Wattage
25w, 50w, 75w,
100w, 150w
Technical information
Operating voltage IP Rating
200 240VAC IP 65
50/60hz
Operating position Universal
Series 5
25w 50w 75w
A (mm) 120 200 280
B (mm) 175 175 175
C (mm) 100 100 100
Max 0.033 0.055 0.077
projected
area (m°)
Weight 1.6 2.4 3
(kg)
U- Bracket mounting holes
*AFRISON TERMS & CONDITIONS
DUE TO ONGOING R&D AFRISON RESERVES THE
WITHOUT PRIOR NOTICE 1, 2 , 3 OR 5 YEAR WARRANTY (REPLACE OR REPAIR) - PLEASE SEE FULL TERMS AND CONDITIONS AT
SHOWN ARE FOR ILLUSTRATION PURPOSES ONLY, ACTUAL PRODUCT MAY VARY DUE TO TECHNICAL DEVELOPMENT. E & OE. © 2022 AFRISON LED. ALL RIGHTS RESERVED.
Meru LED Flood Light
BBB CC
S6 - Series 6
N-Neutral white 4000K
Front cover Operating temperature (°C)
Polycarbonate
Diffused front cover-
Ultra High Impact
100w 150w
350 500
175 175
100 100
0.079 0.113
3.4 3.8
D E
LED colour Lens
C-Cool white 5000K S - 155°
x 85°
W-Warm white 3000K
-20 to 40
CATALOGUE AT ITS OWN DISCRETION AND AT ANY TIME
F G
Mounting type Number of banks
U U-Bracket 1
Standards Mounting hight (m)
SANS 60598 2-6
