Effectrode Atomic Owner's Manual

S p e c i f i c a t i o n s
• Operates anywhere on planet Earth where 110-
250V AC power is available.
• Supplied with IEC mains power cable and 4 ×
very heavy duty 5.5mm × 2.1mm pedal leads.
• 4 × isolated 12VDC @ 1250mA outputs (linear
regulated and heavily filtered–super quiet).
• One of the outputs can be configured to power
9VDC center negative pedals (600mA max.).
• Short circuit/overload protection protects tube
pedals from damage.
• Power requirements: 110 – 240V AC @ 60
Watts.
• Dimensions: width 7.5"; depth 4.8"; height 1.5"
• Weight: 1lb14oz (on Earth); 4lb 12oz (on Jupiter)
• Construction: Solid die-cast aluminum box.
• Finish: dark graphite powder coat.
If removing the rear panel of this
unit, first completely isolate it from
the mains by disconnecting the
mains power cable as there are
hazardous voltages within that
could cause injury or death. If you
are uncertain about what you are
WARNING!
doing please seek advice from a
qualified electrical engineer.
MODEL: AT-2A
Copyright © 2020 Effectrode Thermionic
SERIAL: . . . . . . . . . . . . . . .
®
Owner's Manual
12 Broughton Crescent, Barlaston,
Staffs, England. ST12 9DB
www.effectrode.com
