OPERATING MANUAL
Naise N260 - Sensor
Important: Please read the instruction manual carefully prior to installation and keep it for future reference.
Product
Power
Function
Ordering code
(W)
Description
Fitting series
On/off HF sensor
N260 12 SOF
N260
12
LED Fixture
Sensor-DIM
N260 12 SDM
N260
12
(Bi-level dimming)
LED Fixture
Corridor function
N260 12 STM
N260
12
(Tri-level dimming)
LED Fixture
Accessories
No.
Pic.
Qty.
Usage
1
3
Fix light
2
3
Rawl Plug
3
2
Rubber plug
Ceiling Mounting Installation:
1
2
Push the securing lugs on the both
Twist the diffuser.
sides.
260
Mounting: Wall or Ceiling
Light features:
Ra: >80
Life Time: 5 years
Light Source: LED SMD2835
Input:220V-240VAC 50/60Hz
C0/ C180:
C90/ C 270:
Color temperature:
Code
Color temperature
CCT(K)
Lumen
30K
Warm White
3000
1020
40K
Natural White
4000
1068
50K
Cool White
5000
1116
3
Fix the base to the surface with
screws.
Advertisement
Related Manuals for EL-produkter Naise N260
Summary of Contents for EL-produkter Naise N260
- Page 1 OPERATING MANUAL Naise N260 - Sensor Important: Please read the instruction manual carefully prior to installation and keep it for future reference. Product Power Function Ordering code Mounting: Wall or Ceiling Description Fitting series Light features: On/off HF sensor Ra: >80...
- Page 2 Setting options ( For code N260 12 SOF/N260 12 SDM/N260 12 STM) Sensitivity ceiling mounting pattern (m) I – 100% Sensitivity can be adjusted by selecting the combination 100% II – 50% on the DIP switches for different applications. 12 m Hold-time I –...
