LIGHTSAFE EBXLEDST Quick Start Manual

These instructions should be read carefully and retained for further reference and maintenance.
IMPORTANT NOTE:
The luminaire must be installed by a skilled electrician and to the most current electrical wiring and building
regulations
This product MUST be earthed
covered by the warranty
This luminaire is NOT suitable to be used with dimmer switches
This product should not be modified in any way, if modified this will invalidate any warranties and Firesafe will not be
liable for any damages caused
The person carrying out the installation is to check and verify that the total load on the circuit, including the rating of
the cable, fuse and/or circuit breaker is not exceeded
It is the responsibility of the installer to consider any fire risks and breach in any fire protection barriers or partitions,
and take the appropriate precautions
Emergency lighting should be installed and maintained in accordance with BS5266 and BS EN50172.

INSTALLATION

1. Ensure the mains supply is isolated
2. Remove the small screw from underneath the fitting and then use a flat blade screwdriver to release the two
securing clips underneath the fitting to remove the front cover from the backplate
3. Fix the base to the wall
4. For non-maintained operation a permanent 230v AC supply is required to the live (L),
(N) terminals on the PCB.
5. For maintained operation for continuous illumination this can be achieved by connecting a link between L1
and L (link supplied) or to have a Switch Live through a remote switch to the L1 terminal on the PCB.
6. Ensure the supplied cable clamp is used to secure the cables inside the luminaire and that ALL electrical
connections are tight and secure with no loose strands
7. Plug the battery lead into connector on the PCB and reconnect the LED connector
8. Clip the front cover back on the backplate ensuring secure and re-insert the retaining screw underneath the
unit
9. Restore the mains supply, the green charge LED should be illuminate
10. Allow 24 hour to charge the batteries and record the installation date in the log book
11. After a 24 hour charge period test the luminaire for a full 3 hour duration by removing the 230v AC supply
and record the date of the commissioning on the battery pack inside the luminaire and also in the log book
12. Subsequent testing should be carried out in accordance with the British/European standards and recorded in
the log book
EBXLEDST
Surface Slimline 3 hour Maintained LED Exit Box
c/w Automatic Self-Test Function
and NOT be subject to an electrical insulation test (500/1000v) which will not be
Earth and neutral
Lightsafe_EBXLEDST_Instructions_Rev01
