Arkon MC25MM432 Quick Start Manual

MC25MM432 | Mega Grip 25mm Handlebar Phone Mount
APRM2T
SP-RMS250
1
Place handlebar spacer/adapter ring around handlebar. Attach mount
to handlebar around spacer. Use the included hex key to securely
tighten both mounting screws.
Mounting Screw
3
Attach strap by inserting the strap's Dual T-Tabs in to the holder's
Dual T-Slots. Attach adapter by inserting the adapter's Dual T-Tabs
into the strap's Dual T-Slots. Insert screw to secure.
Dual T-Slots s s s s s s s s s s
Dual T-Tabs s s s s s s s s s s s s

Safety Precautions

! !
Arkon is not responsible for any damages caused to your vehicle, your
device, or yourself due to the installation or use of this mount.
MC25MMB SM040-2
Mounting Screw
H Handlebar Spacer/
Adapter Ring
Set Screw

Package Contents:

(1) MC25MMB –Motorcycle Handlebar Mount Pedestal
(1) SP-RMS250 – Small Robust Mount Shaft
(1) SM040-2 – Mega Grip Universal Phone Holder
(1) APRM2T – 25mm Ball to Dual T-Tab Adapter
(1) APLSSTRAP – Dual T-Slot to Dual T-Tab Elastic Securing Strap
This Motorcycle Mount fi ts cylindrical handlebars up to 30mm diameter
and comes with 3 handlebar spacer/adapter rings of different widths.
APLSSTRAP
Select the appropriate size for optimum mounting to your handlebar.
The Mega Grip Universal Phone Holder fi ts smartphones up to 3.25
inches wide.
2
Attach Robust Mount Shaft by unscrewing knob to loosen collar.
Adjust angle then retighten knob to secure.
4
Attach the assembled mobile phone holder by combining the
adapter to the Robust Mount Shaft and tightening to secure.
Consumer Hotline:
USA
(800) 841-0884
INT'L (626) 254-9005
Monday - Friday 9am - 5pm, PST
rev.011119
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China
© Copyright 2019 Arkon Resources, Inc.
