480P Rear Panel

IEC Power Cord Receptacle

The 480P comes with a IEC power supply cord and a selectable power supply.

Voltage Selector Switch

The 480P allows you to select either 115V with 500mA 250V SLOW BLOW fuse or 230V with 250mA 250V Type "T" fuse. WARNING: Fuse
must be changed to correspond with the desired power setting.
RS485 Link to 480R (DB-9 connector type)
This connector is used to connect to the 480R. Cable lengths 480R to 480P - 300 feet max. 500 feet with dbx proprietary cable.

RS485 Link to Network Master (DB-9 connector type)

This connector is used to connect the 480R to the network master. Connect to the CONTROLLER IN on the Network master 480P to Network
cable length- Up to 4000 feet.
RS485 Link to 480R (RJ-45 connector type)
This connector is used to connect to the 480R, and is wired in parallel with the DB-9 connector. Cable lengths 480R to 480P - 300 feet max. 500
feet with dbx proprietary cable.

RS485 Link to Network Master (RJ-45 connector type)

This connector is used to connect the 480R to the network master. Connect to the CONTROLLER IN on the Network master and is and is wired
in parallel with the DB-9 connector. 480P to Network cable length- Up to 4000 feet.

RS232 PC Connection

This input is used to connect a PC to the 480R for 480R software updates.
RS485/ PC Select Button
This recessed button is used to select the link to master controller connector or the PC

480P Front Panel

Power Switch

Turns the 480P and 480R on and off.
Specifications ( 480P Power Supply)

Inputs

Connectors:

Power Requirements

30 Watts
50/60Hz

Dimensions

Dimensions:
Height:
Weight:
Shipping Weight:
18-0294-A
RS 232 and RS 485 Network Communication
Connectors
Selectable
100-120V - 50/60Hz
or 220-240V-
1.75" X Width- 19" X Depth 7.90"
8 lbs.
9.5 lbs.
®
®
Complete Equalization & Loudspeaker Management System
480P
Power
Supply
®
User Manual
