- Page 1 Newline HW86 Multi-functional and professional mobile cart User Manual (Installation instructions) Edit ： APAC PM Vincent Huang Photos ： APAC PM Vincent Huang and APAC FAE Ethan Chen Date ： 2020/12/09...
-
Page 2: Table Of Contents
Material No.: 61704NL0000HW86 Contents 1. Features ........................2 2. Product specifications ..................... 2 3. WARNING! ......................3 4. Part List: ........................4 5. Explosive view ......................5 6. Assembly step ......................6 Step 1. Assemble base and wheels ............... 6 Step 2. -
Page 3: Features
Material No.: 61704NL0000HW86 1. Features For display panels: 55”-100” Maximum capacity: 300lbs/136.4kg Accessories shelf max load: 25lbs/13.6kg Video support tray max load: 10 lbs/4.5kg VESA:200*200-1000*600mm 2. Product specifications... -
Page 4: Warning
Material No.: 61704NL0000HW86 Outline Dimension Packing Dimension Net Weight (Kg) Packing Weight (Kg) Capacity (Kg) L x W x H (mm) L x W x H (mm) 1260 x 715 x 1400-1700 2080 x 720 x 130 136.4 Product Weight and Dimensions Outline Dimension Packing Dimension... -
Page 5: Part List
Material No.: 61704NL0000HW86 4. Part List:... -
Page 6: Explosive View
Material No.: 61704NL0000HW86 5. Explosive view... -
Page 7: Assembly Step
Material No.: 61704NL0000HW86 6. Assembly step Step 1. Assemble base and wheels Use nuts to fix the four wheels to the base Please attach the four wheels with nut lock and cover with dust cover. Step 2. Start to assemble Columns... - Page 8 Material No.: 61704NL0000HW86 M8 Hex Wrench Before the column is installed into the base, put the 3-hole and the 2-hole fixed iron pieces into the side groove of the column respectively. Stand the base sideways and aim the column at the base hole. Then tighten the screws to fix the column.
-
Page 9: Step 3. Screen Support Fixture To Columns Installation
Material No.: 61704NL0000HW86 Please note that the 3-hole and 2-hole fixing iron pieces have been placed in the grooves. Step 3. Screen support fixture to columns installation Usually the handle is already attached to it. If not, please lock it yourself. Handle locking method: Please put the 2-hole fixed iron piece into the side groove of the column and lock the fixed handle at the appropriate position. - Page 10 Material No.: 61704NL0000HW86 M6 Hex Wrench Please note: In any case, please make sure that the lock positions on both sides are on the same horizontal line, that is, the same height first. After fixing the handle, put the 3-hole fixing iron sheet into the groove.
- Page 11 Material No.: 61704NL0000HW86 Put on the cover and lock the screws then. Push up the 3-hole fixing iron piece on the other side, and then lock the support fixtures. Support fixture...
-
Page 12: Step 4. Screen Support Bracket To Fixture Installation
Material No.: 61704NL0000HW86 Step 4. Screen support bracket to fixture installation M8 Hex Wrench Lock the screen support bracket. -
Page 13: Step 5. Rails To Display Installation
Material No.: 61704NL0000HW86 Step 5. Rails to Display installation Lock the screen support rails at the appropriate height holes. Notes: Plastic spacers must be used when assemble adaptor onto your display to avoid display threaded holes damaged when thread holes are shallow. -
Page 14: Step 6. Accessories Shelf Assemble And Installation
Material No.: 61704NL0000HW86 Ask 2-4 people to lift the IFPD and place it on the screen bracket, and move it left and right to adjust to a proper position. Lock the buckle to fix the IFPD. M5 screwer Step 6. Accessories shelf assemble and installation... - Page 15 Material No.: 61704NL0000HW86 M6 Hex Wrench After sliding the 2-hole fixed iron piece to a proper height, lock the horizontal pillar. At the same time make sure the horizontal piliar is horizontal.
-
Page 16: Step 7. Video Support Tray Assemble
Material No.: 61704NL0000HW86 M6 Hex Wrench M6 Hex Wrench Lock the storage tray then. Step 7. Video support tray assemble M5 screwer... - Page 17 Material No.: 61704NL0000HW86 Assemble the video support tray first. M6 Hex Wrench...
-
Page 18: Installation Completed Views
Material No.: 61704NL0000HW86 7. Installation completed views...
