- Page 1 Carpet Sprayer Operator and Parts Manual Model No.: 605848 TENNNANT COMPANY Commercial Products 12875 RANSOM STREET HOLLAND MI 49424 U.S.A. 1–800-522–7839 616-786–2330 605851 FAX: 1–800–678–4240 Rev. 01 (06-00) CUSTOMER SERVICE: 1–800-982-7658 Home Find... Go To..
-
Page 2: Operation
OPERATION This manual is furnished with each new Carpet FOR SAFETY: Sprayer. It provides necessary operation, maintenance Always wear safety goggles when pressurizing and trouble shooting instructions. Read this manual this sprayer. completely and understand the machine before operating or servicing. Read and follow operating instructions. -
Page 3: Safety Hints
OPERATION Start or stop spraying by operating the hand control lever (see figure 1, #3). See also Figure 2. The spray SAFETY HINTS pressure can be monitored with a pressure gauge (accessory). At the time of the manufacture of this sprayer, we are not aware of any approved plant protection chemicals SMALL O–RINGS SCREW CAP... - Page 4 OPERATION NOTE: Once the tank lid is removed, the pump Should the pumping action become difficult, remove handle “piston” and “cylinder” (pump body) are the pump from the tank, remove the pump piston disassembled simply by pulling apart. (see figure 3, #4) from the pump cylinder and REGULAR INSPECTION: Inspect and replace worn grease the O–ring of the pump piston (see figure 3, or damaged parts promptly.
-
Page 5: Parts List
PARTS LIST CARPET SPRAYER PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. ∇ 606033 PRESSURE RELEF VALVE ASSEMBLY 606032 KIT, O-RING SET 606034 CARRYING STRAPS O-RING 606035 PUMP PISTON O-RING 606036 PLUG GASKET 606037 TANK LID VALVE CONE 606038 CYLINDER SUPPORT O-RING 606039 CYLINDER...
