Olimpia electronics RT-52/HACCP Quick Start Manual

WALL MOUNTING ELECTRIC INSECTICIDES WITH GLUE TRAP

OPERATION VOLTAGE
CONSUMPTION
LAMPS
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
CONSTRUCTION MATERIALS
DIMENSIONS
TYPICAL WEIGHT
GUARANTEE

HACCP Certification

The above products are designed based on Hazard Analysis
Critical Control Points (HACCP), in order to be appropriate
for placement in storage space, processing and food
distribution.
They have a special adhesive surface that prevents
scattering of trapped insects, as well as lamps with a special
film that does not shattered in case the trap falls.
ΙΝ GENERAL
Electric insecticides are used to exterminate various insects.
They use special fluorescent tubes
insects from a distance. They can be used in any areas
where there are many insects. A special glue trap within the
insecticide in used to trap the insects. If they are placed
outdoor then a special external metallic grid is available to
protect birds that might happen to come near the trap. These
traps protect us from all kinds of insects (mosquitoes, gnats,
flies, e.t.c) without using any chemicals. The insecticides are
mounted high above the floor level and in a clearly visible
place in order to attract the insects more easily. The
52/HACCP and RT-62/HACCP are produced according to
HACCP regulations .One glue trap is included in the
packaging of the electric insecticide.
RT-52 /HACCP . This model uses a special glue trap for
insects and incorporates two
2 x 18 W special fluorescent tubes (blacklight) placed in the
front of the glue trap. The device is powered by a voltage of
220-240VAC.
RT-60 /HACCP . This model uses a special glue trap for
insects and incorporates two
2 x 36 W special fluorescent tubes (blacklight) placed in the
front of the glue trap. The device is powered by a voltage of
220-240VAC.

Spare Parts- Replacements

- Á1066. A package that contains 6
replacement glue traps for RT
52/HACCP and RT-62/HACCP.
- Á1068. A package that contains 12
replacement glue traps suitable for
RT-52/HACCP and RT-62/HACCP.
- A1056. External metallic protection grid.
(1 for RT-52/HACCP and 2 for
RT-62/HACCP)
Page 1 from 2

TECHNICAL CHARACTERISTICS

RT-52/HACCP
68 x 40 x 10 mm
Thank you for your trust in our products
Olympia Electronics - European manufacturer
(Black Light) to attract the
RT-
220-240V AC/50-60Hz
147VA
2x18W
IP 20
EN 60335-1, EN 60335-2-59
0 to 60 C
Up to 95%
Aluminum, ABS self extinguished
5780kgr.
2 years (1 year for the lamp)

Changing the lamp

If the lamp must be changed then follow the procedure bellow:
1. Remove the power plug from the wall
outlet.
2. Replace the lamp which is not operating,
with a suitable type.
3. Insert the power plug into the wall outlet.
The lamp type used are :SYLVANIA type T12 F18W/BL350S
for RT-52/HACCP and T8 F36W / BL368FEP for
RT-62/HACCP.

Maintenance

The glue must be replaced once a month for maximum
efficiency of the insect trap.
In periods where high quantities of insects are observed or if
the insect trap has been installed in areas with high levels of
dust then the glue trap must be checked more frequently. If the
surface of the glue is covered with dust or insects then it must
be replaced.
RT-62/HACCP
167VA
2x36W
o
127 x 40 x 10 mm
8360kgr.
925062000_09_006
