- Page 1 Thermaflo Model 3010T Temperature Regulating Valve Installation and Maintenance Manual Please read and save these instructions 732-EN V1.4 Thermaflo Inc. 2880 Fair Avenue Newberry, South Carolina 29108 704-940-1228...
-
Page 2: Table Of Contents
Table of Contents Overview ...................... 3 Installation Instructions ..................3 Assembly and Installation .................. 3 Disassembly ....................4 3010T & 3010P, K1, K3, K6 Remote Mount Pilot Tubing – Assembly Instructions ..6 Troubleshooting Guide ..................7 Limited Warranty and Remedy ................8... -
Page 3: Overview
Warning: This manual should be used by experienced personnel as a guide to the installation of the Model Thermaflo 3010T Temperature Regulating Valve. Selection or installation of equipment should always be accompanied by competent technical assistance. You are encouraged to contact Thermaflo Inc, Inc. or its local representative for additional information.704-940-1228 Newberry, SC 29108... -
Page 4: Disassembly
Installation of Capillary System and Thermal Bulb When using the thermal bulb in a pipe, make sure the After the pilot body has been installed, install the capillary thermal bulb is installed in a location where the heated fluid system. See Figure 5-1 on Page 5. Be sure to insert flows freely around it. - Page 5 Main Valve Disassembly See Figure 5-2 below Make sure that a small bead of Never Seize is used Remove hexagonal bolts (38) from main valve cover (26) around the top and bottom circumferences of the and remove cover from body (1). diaphragms before assembly of bottom and top diaphragm Remove main valve spring (13) and the main valve (6).
-
Page 6: 3010T & 3010P, K1, K3, K6 Remote Mount Pilot Tubing - Assembly Instructions
3010T & 3010P, K1, K3, K6 Remote Mount Pilot Tubing – Assembly Instructions (See drawings for proper piping of remote pilots) The valves have the following “similar” parts. ¼” long nipple (4), ¼”x ¼” short nipple (6), fitting B (13) and union/ coupling (5). Use thread tape on the threads of both nipples. -
Page 7: Troubleshooting Guide
Troubleshooting Guide Problem Cause Solution Temperature regulator does not Improper adjustment. Readjust according to Regulating Methods on page 2. reach desired set temperature. Faulty steam trap draining equipment. Check trap and correct problem. Inadequate pressure to eliminate condensate. Re-pipe system to gravity drain condensate. Clean Y strainer on inlet to valve. -
Page 8: Limited Warranty And Remedy
As a condition of enforcing any rights or remedies relating to Thermaflo products, notice of any warranty or other claim relating to the products must be given in writing to Thermaflo: (i) within 30 days of last day of the applicable warranty period, or (ii) within 30 days of the date of the manifestation of the condition or occurrence giving rise to the claim, whichever is earlier.
