Summary of Contents for deZem HarvyLR-36
- Page 1 IoT sensor HarvyLR User manual and technical data of the LoRaWAN sensors HarvyLR-36 and HarvyLR-360 © 2023 deZem GmbH deZem GmbH Wilmersdorfer Str. 60, 10627 Berlin Version 2.2 Phone: +49 30 31 800 730 Fax: +49 30 31 800 731 Feb 2023 contact@dezem.de ·...
-
Page 2: Table Of Contents
User manual IoT sensor HarvyLR Contents 1 Introduction ................................3 2 Safety instructions ..............................3 3 Product description ..............................4 3.1 Product designation ............................4 3.2 Intended use ..............................4 4 Functional Description .............................. 5 5 Installation ................................6 5.1 First time charging of HarvyLR ......................... 6 5.2 Connecting the sensor ............................. -
Page 3: Introduction
Please read the following information carefully. Keep the manual or pass it on to other users of the product. Visit our website www.dezem.de with the respective website belonging to the product. There you may find further information about the product. -
Page 4: Product Description
It is particularly suitable for the acquisition of RMS currents using the deZem clamp-on current transformers as well as industrial 4–20 mA output signals. The intelligent event filter inte- grated in the sensor provides metering t series (inrush currents, etc.) accurate to the second at a defined maximum rate. -
Page 5: Functional Description
DC) of only 0.15 mA on average is sufficient to record and send metered values every 10 minutes on average. Even higher data rates are possible with larger input currents. Optionally, the HarvyLR can be integrated into the deZem DataSuite, see chapter 5.3. -
Page 6: Installation
5 Installation 5.1 First time charging of HarvyLR Prerequisite: HarvyLR is set up on a LoRaWAN server (e.g. deZem IoT platform, i.e. deZem.io). For initial charging, we recommend connecting the HarvyLR to the computer via the optional USB adapter cable. -
Page 7: Disposal
Due to the applicable regulations, the electrical and electronic devices of deZem GmbH may not be disposed of via the public collection points for electrical devices. The complete electronic devices of deZem GmbH must be returned to us for disposal. The prepaid delivery must be sent to the following address: deZem GmbH, Wilmersdorfer Str. -
Page 8: Technical Data
Input current 0–25 mA AC 0–250 mA AC 0–36 mA DC 0–360 mA DC Connection 1x JST-socket, suitable for deZem clamp-on current transformers IoT protocol LoRaWAN v1.03, Class A Device, EU863-870 Mhz Permissible ambient conditions Temperature: 0–55 °C Humidity: 30–60 %... -
Page 9: Support
RX: receive mode, TX: transmit mode 8 Support Do you have any further questions about set-up and operation? Our deZem team will be happy to answer them. Give us a call: +49 30 3180 0730 or write us an email to support@dezem.de.
