Summary of Contents for MFL G440BSW

  • Page 1 PROFESIONAL SHOW LIGHTING USER MANUAL...

  • Page 2: Safety Information

    ***Please carefully read this user manual in its entirety and keep it safe for future reference. It is essential to know the information and comply with the instructions given in this manual to ensure the fitting is installed, used and serviced or correctly and safely.

  • Page 3: Mechanical Details

    MECHANICAL DETAILS Specification Manufacturer：Mingzhi Brand：MFL. Model：G440BSW Input： 100-240V 50HZ-60HZ Power： 700W Light source：Yodn 380W Yodn 440W，OSRAM470W Working lifetime： average lifetime 1500 hours Color temperature：...

  • Page 4: Display Description

    Prism： 8 + 16-facet prism, CW/CCW rotation（Standard，customized is availbale)Auto focusing when zooming Color wheel： 13 colors + open Fixed gobo wheel： 14 gobos + open（Gobo customized is available） Rotating wheel： 7 interchangeable gobos + open（Gobo customized is available） Animation wheel： 3 animation wheel＋open (can make special dynamic flame or water effect) Electronic system: Switch the light bulb through the console，Electronic automatic monitoring of reset failure，Detection of Fan Speed...

  • Page 5: Channel Description

    Motor Vx.xxx 0 - 255 PanFine 0 - 255 Tilt 0 - 255 Manual TiltFine 0 - 255 Password 0 - 255 0 - 255 Tilt 0 - 255 0 - 255 Cyan 0 - 255 Magenta 0 - 255 Yellow 0 - 255 Color...
  • Page 6 P/T Speed -255 Function 50－99 Reset 100－ Lamp Off 150－ Lamp On Shutter Closed 4-103 SLOW STROBE -> FAST STROBE 104-10 Open 108-20 SLOW STROBE -> FAST STROBE 208-21 Open 213-25 RANDOM STROBE SLOW -> FAST 252-25 Open Dimmer 0－255 Linear Dimmer 0-255 CMY open...
  • Page 7 50-54 Colour 10 55-59 Colour 11 60-64 Colour 12 65-69 Colour 13 70-74 Colour 14 75-79 Colour 15 80-84 Colour 16 85-89 Colour 17 90-94 Colour 18 95-99 Colour 19 100-10 Colour 20 105-10 Colour 21 110-11 Colour 22 115-11 Colour 23 120-12 Colour 24...
  • Page 8 52-57 Gobo 9 58-63 Gobo 10 64-69 Gobo 11 70-75 Gobo 12 76-81 Gobo 13 82-87 Gobo 14 88-95 Gobo 1 Jitter 96-103 Gobo 2 Jitter 104-11 Gobo 3 Jitter 112-11 Gobo 4 Jitter 120-12 Gobo 5 Jitter 128-13 Gobo 6 Jitter 136-14 Gobo 7 Jitter 144-15...
  • Page 9 70-99 Gobo3 100-12 FAST ROTATION - SLOW ROTATION 130-13 STOP 136-16 SLOW ROTATION - FAST ROTATION 166-19 Gobo 1 Jitter 196-22 Gobo 2 Jitter 226-25 Gobo 3 Jitter Rotation Gobo white 10-19 Gobo 1 20-29 Gobo 2 30-39 Gobo 3 40-49 Gobo 4 50-59...
  • Page 10 ROTATION 191－ STOP 193－ SLOW ROTATION - FAST ROTATION 0-255 Gobo Rotation Fine Linear Color7/Frost 0－127 White 128－ Frost 192－ Color7 0-255 Prism-zoom Prism1 0－127 Reserve 128-25 Prism1 Prism-1 Rot 0－127 Rotation 128－ FAST ROTATION - SLOW ROTATION 191－ STOP 193－...

  • Page 11: Cleaning And Maintenances

    CLEANING AND MAINTENANCES In order to ensure the fixture could work normally, it should be kept clean always. It is recommended that the fans and ventilation inlet should be cleaned every 15 days. The lens should be regularly cleaned and maintain an optimum light output.
