Installation & Setup
LAN Connection
Connect an Ethernet cable from your PC's Ethernet port to the LAN port of the VoIP ATA.
WAN Connection
Connect an Ethernet cable from the router to the WAN port of the VoIP ATA.
VoIP Connection
Connect the telephone to PHONE port and your PSTN line to LINE port.
Power Adapter Connection
Connect the power adapter to the power inlet.
Configuring VoIP ATA with Web Browser
Open web browser and type http://192.168.3.1 in the browser's address box. This number is the default IP
address for this device.
A user name and password prompt will appear. The username is admin and password is admin.
VoIP ATA BRV111,BRV102
Quick Installation Guide
Optional
Check your device rear panel, the
alternative could be as follows:
PHONE (FXS): Connect to the
Telephone (model BRV102)
LINE (FXO): Connect o PSTN Line
(model BRV111)
Advertisement
Related Manuals for Maxcom BRV111
Summary of Contents for Maxcom BRV111
- Page 1 VoIP ATA BRV111,BRV102 Quick Installation Guide Installation & Setup LAN Connection Connect an Ethernet cable from your PC's Ethernet port to the LAN port of the VoIP ATA. WAN Connection Connect an Ethernet cable from the router to the WAN port of the VoIP ATA.
- Page 2 VoIP Application FXS – FXS ---- For more details, please refer to our manual.
- Page 3 2. Manual by PDF format. *optional There are three models for VoIP ATA: 1) one FXS(PHONE) port & one FXO(LINE) port (BRV111) 2) two FXS(PHONE) ports (BRV102) You can check the package content for which one you bought. MAXCOM Sp. z o.o.
