- Page 1 EcoFlow Glacier Portable Fridge User Manual V1.0...
- Page 2 Once you use this product, it is deemed that you understand, approve and accept all the terms and content in this document. EcoFlow is not liable for any loss caused by the user's failure to use this product in compliance with this user manual.
- Page 3 Contents Safety Instructions EcoFlow App Installation Instructions Select an ideal installation place Set the refrigerator steady Clean and install accessories Connect to the power supply How to Use the Product Refrigerator parts and food storage suggestions LCD indicators Power-on/off Temperature settings and functional operations...
-
Page 4: Basic Information
Basic Information Model EFBX100 Climate class SN/N/ST/T Type of protection against electric shock Class II Single zone: 38 L Operational volume Dual zone: 36 L 776 mm × 385 mm × 445 mm (wheels and telescopic handle not included) (30.6 in × 15.2 in ×... - Page 5 This user manual contains a lot of important safety information. Please be sure to read and follow all safety information. This is a safety warning symbol. Such safety information alerts you to hazards that can be lethal to you and others, and that can cause damages to the product. All safety information is preceded by safety warning symbols and hazard words, including: DANGER, WARNING, and CAUTION.
- Page 6 • Before starting the device, ensure that the power supply line and the plug are dry. Ensure that the power cable and the plug are securely connected. • Do not operate the cooling device if it is visibly damaged. Immediately stop the device and switch off all power supplies.
- Page 7 cooling device. instructions. • Before starting the cooling device, ensure that the power supply line and the plug are dry. • Disconnect the cooling device from the power supply – before each cleaning and maintenance – after every use To avoid contamination of food, please respect the following instructions: •...
- Page 8 Control, monitor and customize your EcoFlow devices from afar with the EcoFlow App. Download at: Privacy Policy By using EcoFlow Products, Applications and Services, you consent to the EcoFlow Term of Use and Privacy Policy, which you can access via the “About” section of the “User” page terms-of-use and...
- Page 9 Ensure that the refrigerator is disconnected from the mains before installing and adjusting accessories. Keep an appropriate distance between the refrigerator and surrounding objects. Ensure at all times that there is a minimum of 2 in (50 mm) ventilation gap on all four sides of the refrigerator.
- Page 11 This product supports AC mains, car charging (12V/24V), and solar charging (EFBX100-EB battery pack (optional) must be connected). AC mains Please use a dedicated power outlet, which should not be shared with other electrical appliances. AC (wall socket) AC power adapter (29 V, 180 W) This product supports AC mains.
- Page 12 5%. This device is equipped with 3-stage battery protection, which can be turned on/off through EcoFlow APP. The battery protection prevents excessive discharging when the device is connected to a vehicle starter battery (lead-acid battery). When not connected to EFBX100-EB battery pack (optional), the device switches off automatically as soon as the supply voltage falls below a set level.
- Page 13 EFBX100-EB battery pack (optional) Solar charging port Solar charging cable (not included) This product supports solar charging and supports charging the EFBX100-EB battery pack (optional) with a maximum power of 180 W. properly.
- Page 14 1. Detachable handle 2. Detachable wheels (optional) 3. Power button 4. Temperature zone switching button 5. Temperature increase/Next button 6. Temperature decrease/Previous button 7. Ice making button 8. Ice detaching button (You can press the button to cancel ice-making operation or manually detach ice from bullet-head-shaped component of the ice maker for access to ice cubes.)
- Page 15 21. Power connector 22. Ice maker drain pipe 23. Battery removal button 24. Battery compartment 25. Drainage hole...
- Page 16 1. Charging 12. Ice-making water shortage 2. Battery level estimator 13. Cannot make ice indicator 3. Remaining battery percentage 14. Left zone temperature 4. Car charging connection 15. Single zone temperature (after removing 5. Adapter connection the zone divider) 6. Solar input 16.
- Page 17 Power-on Press Power-off Press the power button to turn on the device. The general power indicator becomes will automatically turn off. When you operate the product, the LCD will be automatically lit. To manually turn off the LCD, press the power button. To manually turn on the LCD, press any button.
- Page 18 Fridge mode 0°C to 10°C (32°F to 50°F) Freezer mode -25°C to 0°C (-13°F to 32°F) 1. The left zone is up to 25°C (77°F) 5°C (41°F) higher than the right zone, or the right 5°C to 8°C(41°F to 46°F) zone is up to 15°C higher than the 8°C to 10°C(46°F to 50°F)
- Page 19 1. It is recommended to clean the ice maker and ice container every time ice is made. (see Care part) 2. Press the maker. The water level should not be lower than the minimum scale line ( ) or exceed the maximum scale line (MAX LCD will prompt that the ice container is missing and the ice maker cannot work.
- Page 20 • It is recommended you store the ice cubes in the single/dual zone. • During the ice making process, you can still select large/small ice cubes by short pressing the ice making button. • Ice making will increase power consumption. Do not turn on ice making if you do not need it.
- Page 21 1. The fridge mode is used to store food that should not be frozen and have a short storage period. It is suitable for storing fresh food rather than food that is perishable at low temperatures. 2. Hot food should be cooled before putting into the refrigerator. Otherwise, the temperature in the refrigerator will rise, affecting the freshness of other food and increasing the power consumption.
- Page 22 7. After cleaning, please check whether the power cable is damaged or wet, and whether everything is normal. 8. Before plugging in the power supply, please use a soft dry cloth or sponge to dry any moisture to avoid water or other liquids remaining in the electrical components, to avoid electric shock or short circuit.
- Page 23 Moisture can form frost inside the refrigerator or on the evaporator. This will reduce refrigeration capacity. Please defrost the refrigerator to avoid such situations. • Do not use hard or sharp tools to remove ice or loosen frozen items. • Do not use mechanical devices or other methods not recommended by the manufacturer to speed up the defrosting process.
- Page 24 EFBX100 × 1 AC power adapter + cable × 1 Car charging cable × 1 Left zone basket Ice shovel Quick Start Guide × 1 × 1 × 1 Warranty Card × 1...
