Page 1
This addendum addresses European Union (EU) Ecodesign requirements for servers and storage products. All data and ratings within this addendum are in reference only to the Supermicro product(s) in the manual. The below information conforms to requirements laid down in Annex II of the Commission Regulation 2019/424.
Page 2
The first is with a Unified Extensible Firmware Interface (UEFI) shell utility. This utility works on X10/X11/X12/H11/H12/M11 motherboard series with onboard SATA/NVMe devices. Any user may access and download this utility through following link: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wftp/utility/Lot9_Secure _Data_Deletion_Utility/ Download the shell utility package and extract it to a USB flash drive, then plug the drive into the server for which secure data deletion is necessary.
Page 3
The indicative weight range of neodymium in the HDD is 0.0 if manufactured by Western Digital, and is between 5-25 grams if manufactured by Seagate. 3(3)(b): Please see the disassembly instructions on the next page.
Illustrated System Disassembly Instructions Please note: All the illustrations in the below disassembly instructions are for demonstration only. Components shown here may not match exactly with the components in your system. CAUTION: Always power off the system and unplug the power cord(s) first before disassembling the system! 1.
2. Data Storage Devices Type and number of fastenings: One (1) latch, and two (2) locking clasps. Tools required: None. Procedure: 1. Push the release button on the drive carrier to extend the drive carrier handle. 2. Use the drive carrier handle to pull the drive out of the chassis. 3.
Page 6
3. Memory Type and number of fastenings: Two (2) latches per memory module. Tools required: None. Procedure: Press both release tabs on the ends of the memory module to unlock it. Once the module is loosened, remove it from the memory slot.
Page 7
4. Processor Type and number of fastenings: Four (4) T30 Torx screws. Tools required: Screwdriver with T30 Torx bit and slotted bit. Procedure: 1. Use a T30-bit screwdriver to loosen the four peek nuts on the heatsink in the sequence of A, B, C, and D.
Page 8
4. Unlock the lever and push it upward to disengage the processor from the carrier as shown in the picture. Carefully remove the processor from the carrier. Handle the processor with care to avoid damage.
Page 9
5. Fans Type and number of fastenings: Four (4) Phillips screws per fan. Tools required: Phillips screwdriver with PH2 bit. Procedure: Using the handle, pull the drawer with the fan from the chassis. Remove the Phillips screws to remove the fan from the fan drawer.
6. Power Supplies Type and number of fastenings: One (1) latch per module. Tools required: None. Procedure: Unplug the power cord from the power supply. Push the release tab on the back of the power supply module to the side and pull the module straight out.
Page 11
7. Power Supplies Type and number of fastenings: For the WIO-L riser: One (1) lever; one (1) Phillips screw for the riser/expansion card assembly; four (4) Phillips screws for the riser attachment. For the Ultra riser: One (1) thumbscrew, and four (4) Phillips screws for the attachment. Tools required: Screwdriver with PH2 bit.
Page 12
8. Expansion Card/Graphics Card Type and number of fastenings: One (1) Phillips screw per expansion card installed. Tools required: Screwdriver with PH2 bit. Procedure: After the riser/expansion card assembly is removed from the system, as described above in Item #7, remove the Phillips screw from the expansion card rear I/O panel (if installed), and pull the expansion card out of the card edge connector on the riser card.
Page 13
9. Motherboard Type and number of fastenings: 12 Phillips screws. Tools required: Screwdriver with PH2 bit. Procedure: Remove all 12 Phillips screws from the locations shown below. Lift the motherboard from its base.
Page 14
10. Batteries Type and number of fastenings: One (1) latch. Tools required: None. Procedure: Push aside the small clamp that covers the edge of the battery. When the battery is released, lift it out of the holder. 11. Backplane Type and number of fastenings: None.
