Summary of Contents for KNIPEX 00 50 50 T LE
- Page 1 KNIPEX Quality Operating Instructions 00 50 50 T LE 00 50 51 T LE KNIPEX Tethered Tools Tool bags...
-
Page 2: Table Of Contents
CONTENTS General information Notes on operating instructions Symbols used Copyright Guarantee and warranty Safety Intended use Safety Instructions for operation 2.3 Certified safety Structure and function Design of the Tool Bag Function Product Overview and Technical Data 3.3.1 Dimensions Equipment of the Tool Bag Transport of tools in the Tool Bag Transport of bottles, spray cans or other objects in the side pockets 8 Transport of documents or tablet/PC in the front pocket... -
Page 3: General Information
Tool Bag. The illustrations and descriptions contained in these operating instructions may differ slightly from the Tool Bag actually delivered. KNIPEX-Werk C. Gustav Putsch KG is not liable for damage caused by failure to observe these operating instructions. 1.2 Symbols used All safety instructions in this operating instructions are indicated by corresponding symbols. -
Page 4: Safety
Risk of falling from slipping, stumbling, twisting and from people falling onto a lower surface or an object! KNIPEX Tethered Tools Tool Bags are for tool transport only. They are not for human or animal support, nor are they intended to be part of a human fall protection system. -
Page 5: Certified Safety
• Do not use a KNIPEX Tethered Tools Tool Bag if it will interfere with the safe working condition, or operation of the tool or equipment it is attached to. -
Page 6: Structure And Function
- Part # 00 50 50 T LE: maximum static load 10.0 kg (22 lbs) 4 D-rings at the rear of the inside to attach the tools - Part # 00 50 51 T LE: maximum static load 15.0 kg (33 lbs) OR for attaching KNIPEX tethered tools (maximum dynamic load 3.0 kg / 6.61 lbs ) Only tools weighing less than 3.0 kg / 6.61 lbs may be attached to the 8 D-rings (6 in the inner compartment and one each on the left and right outside of the bag). -
Page 7: Function
STruCTurE aNd fuNCTiON 3.2 Function Tools that do not exceed the permitted capacity for any tethering system component and have a captive tethering point engineered into them can be tethered with the KNIPEX Tethered Tools Lanyards and Adapter Straps. 3.3 Product Overview and Technical Data Product No. Type Height Width... -
Page 8: Equipment Of The Tool Bag
EquipmENT Of ThE TOOl BaG Equipment of the Tool Bag Figure 3: A ttachment of tools and other objects with Lanyards or Adapter Straps (TOOLS NOT INCLUDED!) 4.1 Transport of tools in the Tool Bag Tools can be transported in the two inner compartments. The total weight of the bag must not exceed 10 kg / 22 lbs (00 50 50 T) or 15 kg / 33 lbs (00 50 51 T). Each tool and object in the Tool Bag must be attached to one of the D-rings with a Lanyard or Adapter Strap. -
Page 9: Transport Of Documents Or Tablet/Pc In The Front Pocket
EquipmENT Of ThE TOOl BaG 4.3 Transport of documents or tablet/PC in the front pocket Figure 4: Closing the document pocket Documents and tablet/PC can be stored in the front pocket for easy transportation. The front pocket must be closed with the two flaps with hook and loop fastener. -
Page 10: How To Use The Tool Bag
hOw TO uSE ThE TOOl BaG How to use the Tool Bag 5.1 Transport of the Tool Bag For transporting the Tool Bag on the ground, a carrying strap can be hooked onto the two D-rings on the side. Risk of injury from falling objects! The carrying strap is only suitable for transport on solid ground. -
Page 11: Fastening Tools In The Tool Bag
hOw TO uSE ThE TOOl BaG 5.3 Fastening tools in the Tool Bag Each tool must be attached to one of the D-rings inside the Tool Bag with a Lanyard or Adapter Strap. Several tools can be attached to one D-ring as long as the total weight of the D-ring does not exceed 3 kg /6.6 lbs. -
Page 12: Connecting Adapter Straps
TO uSE ThE TOOl BaG 5.3.3 Connecting Adapter Straps To connect a KNIPEX Adapter Strap: Figure 9: Connecting Adapter Straps 1. Connect the Adapter Strap to the tool via loop and connect this to a lanyard which is fastened to a D-ring as described in chapter 5.3.2. 2. Connect the Adapter Strap to the Lanyard or anchor point via carabiner as described in chapter 5.3.1. Stand: 27.02.23... -
Page 13: Opening The Top Cover
hOw TO uSE ThE TOOl BaG 5.4 Opening the top cover Risk of injury from falling objects! During transport and ascent or descent on a rope, on ladders, etc., the Tool Bag must be closed to prevent tools and materials from falling out, all of which must be attached to the bag by means of a Lanyard or Adapter Strap. -
Page 14: Inspection
Inspection KNIPEX Tethered Tools Tool Bags must be thoroughly inspected before each use. Any KNIPEX Tethered Tools Tool Bags components that has deformities, unusual wear or deterioration must be immediately removed from service and destroyed. - Page 15 KNIPEX-Werk C. Gustav Putsch KG 42337 Wuppertal Tel.: +49 202 – 47 94-0 Fax: +49 202 – 47 74 94 info@knipex.com www.knipex.com...
