Congratulations on the purchase of your of a new motorized treadmill. To help to ensure the enjoyable

and trouble-free operation of your new treadmill, we strongly suggest you read this manual carefully

and follow its recommendations.

Important Safety Instruction ...........1

Assembly Instruction ......................2

Console Operation .........................4

Exercise Programs .........................6

AI670/680

Treadmill Operations ......................7

Preset Program ............................12

Utiliztion ........................................14

Maintenance .................................15

Need help?

Do you have a question about the AI670 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aspire AI670

Page 1: Table Of Contents
Table Of Contents AI670/680 Congratulations on the purchase of your of a new motorized treadmill. To help to ensure the enjoyable and trouble-free operation of your new treadmill, we strongly suggest you read this manual carefully and follow its recommendations.
Page 2: Important Safety Instruction
IMPORTANT SAFETY INSTRUCTIONS DANGER – To reduce the risk of electrical shock, always ♦ Keep unplugged and have the safety key out of reach of children, when unplug this appliance from the electrical outlet immediately after using not in use to prevent accidents. and before cleaning.
Page 3: Assembly Instruction
AI670/680 ASSEMBLY INSTRUCTION WARNING After unpacking the fitness equipment, examine it carefully for possible damage. If there is any damage or there are missing parts, please contact your retailer or an authorized repair facility for assistance. 1. Since your treadmill is a heavy piece of equipment, we recommend the after taking off the top portion of the box; you slit the corners of the lower carton and fold down the sides.
Page 4 AI670/680 ASSEMBLY INSTRUCTION Step 1: Handlebar support post assembly FIG.1 FIG.2 FIG.3 1. Remove screw M and nut Q from both the 3. Fit and tighten screws M and nut Q back to both sides of the base frame. left and right sides of the base frame.
Page 5: Console Operation
AI670/680 CONSOLE OPERATION Button description START / STOP : Handlebar toggle for incline / speed adjustment : This will start the treadmill and this will stop the treadmill. Left handlebar = For incline adjustment. Increase or decrease by There will also be an emergency stop switch. (Safety key) 1 every time.
Page 6 AI670/680 CONSOLE OPERATION AI670 / AI680 : AI670 / AI680 : Audio in / out (Option)
Page 7: Exercise Programs
AI670/680 EXERCISE PROGRAMS This treadmill has 1 manual and 12 preset programs (5 speed programs, 5 incline programs, 1 step count program and 1 distance program) Each preset program has 5 different levels. Speed Programs - Programs P1-P5 automatically change the speed of the treadmill throughout the workout. Each program starts as per your program setting.
Page 8: Treadmill Operations
AI670/680 TREADMILL OPERATIONS Before starting your treadmill the following actions will need to be properly completed: 1. Be certain that your treadmill sits stable on the floor. It is also recommended that you locate your treadmill in a pleasant area that gives you something to look at while working out, such as a window or television.
Page 9 AI670/680 TREADMILL OPERATIONS Programs Setup and Selection 1. Select Program: To start a program simply select the desired program by pressing on either the Speed or Incline arrows “ ” or “ ” buttons and then press the “MODE” button.
Page 10 AI670/680 TREADMILL OPERATIONS Target Heart Rate Program Setup 1. Select Program: Use either “ ” or “ ” arrows to scroll through the program until “H 01” or “H 02” is shown on the center display. Then press “MODE” button.
Page 11 AI670/680 TREADMILL OPERATIONS Body Mass Program Body Mass Index B.M.I. – is a scientific measure that uses the ratio of height and weight. It is a general measure of health risk, but does not take into account lean body mass. As a result, a healthy muscular individual with very low body fat can be classified as overweight.
Page 12 AI670/680 TREADMILL OPERATIONS Intelli-Guard The treadmill is equipped with the Intelli-Guard safety feature. This feature senses when you stop walking on the treadmill and for safety purposes it automatically pauses the treadmill to avoid accidental falls and resulting injury. The Intelli-Guard feature is triggered when the treadmill senses that you are no longer walking or running on the treadmill.
Page 13: Preset Program
PRESET PROGRAM Under preset programs, the preset workout time is 24 minutes. You can adjust the workout time while in set program mode. AI670/680 Interval km/h Level Speed Speed 10.0 10.0 10.0 10.0 11.0 11.0 10.0 11.0 11.0 12.0 12.0 10.0...
Page 14 PRESET PROGRAM Under preset programs, the preset workout time is 24 minutes. You can adjust the workout time while in set program mode. AI670/680 Interval Level Speed Speed Speed Speed Speed LOW HIGH LOW HIGH LOW HIGH LOW HIGH LOW HIGH LOW...
Page 15: Utiliztion
UTILIZATION Read the following carefully before using your treadmill ♦ Always stretch your muscles before commencing the exercise ♦ This treadmill is equipped with a safety key – Always clip the program. Warm up slowly by walking at a slow speed. Increase cord attached to the safety key to a part of your clothing so the workout intensity gradually until you reach your desired workout safety key will properly detach from the computer console,...
Page 16: Maintenance
MAINTENANCE General cleaning 5. Once belt is aligned, stop treadmill. If belt is loose or has been slipping, tighten both sides exactly 1 full clockwise turn. This will tighten mat. If belt still shows signs of slipping, stop treadmill and 1.
Page 17 MAINTENANCE Belt Lubrication Your treadmill running belt should be lubricated every 3 months (irregardless of use) or every 50 hours of use, whichever comes first. Even if the treadmill is not being used, silicone will dissipate over time and the belt will dry out. Note: Even though the running belt is lubed from the manufacturer, it is not a bad idea to lubricate the running belt when first using the treadmill in case the belt has dried some between the dates the unit was manufactured and when it was purchased.
Page 18 MAINTENANCE Folding/unfolding (Soft drop function) Fold up: Release: After the workout session, you You can release the treadmill can fold the treadmill to the from the upright position. upright position. Lift up the rear 1. Push the frame by hand. end of the treadmill until the 2.
