Installation Instructions
Reflector
End cap
Fixed Angle
Down Tube
Optional Adj.
Angle Down Tube
Figure 1
Elbow Kit
INSTALLATION INSTRUCTIONS

Before you begin

These instructions illustrate the Stylmark® 685000 LED
Lighting for showcases and cabinets. If you have
questions during assembly, call Stylmark's technical help
line. This package does not include specialty fasteners or
adhesives which may be necessary for complete
assembly.
Please read these instructions carefully before beginning installation.
Stylmark, Incorporated ♦ 6536 Main Street NE, PO Box 32008 ♦Minneapolis, MN 55432
LED Cabinet Lighting
1-800-328-2495 ♦www.stylmark.com
685000
Optional Mount
Optional Mount
Optional lens cover
Power Supply
Alternative Power
Tools you'll need
•
3/16" hex key
•
5/64" hex key
•
11/16" open-ended wrench
•
#2 Phillips screwdriver
•
#1 Phillips screwdriver
•
#2 flathead screwdriver
•
Electric drill & standard bits
Revision D (04/10)
Bracket
Bracket
Supply
Sheet# 971488
