INSTALLATION AND MAINTENANCE
MANUAL FOR
BA-440 DUALBEAM BARCODE READER
revised 3/29/2012
800-528-9167
Barcode Automation inc.
407-327-2177
FAX 407-327-6172
Post Office Box 195268
Winter Springs, FL 32719-5268
email Cust-Svc@Barcode-Automation.com
Doing It Better - Because We Care.
web page http://www.Barcode-Automation.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DualBeam BA-440 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bai DualBeam BA-440

Summary of Contents for Bai DualBeam BA-440

  • Page 1 INSTALLATION AND MAINTENANCE MANUAL FOR BA-440 DUALBEAM BARCODE READER revised 3/29/2012 800-528-9167 Barcode Automation inc. 407-327-2177 FAX 407-327-6172 Post Office Box 195268 Winter Springs, FL 32719-5268 email Cust-Svc@Barcode-Automation.com Doing It Better - Because We Care. web page http://www.Barcode-Automation.com...

  • Page 2: Foreword

    FOREWORD The purpose of this manual is to provide information on how to install, configure, operate, and maintain the Barcode Automation BA-440 DualBeam Barcode Reading and Access Control System. Barcode Automation Inc. has made every effort to insure that the information in this manual is both accurate and adequate.

  • Page 3: Introduction

    INTRODUCTION This section contains information for proper installation, operation and maintenance of the Barcode Automation BA-440 DualBeam Barcode Reader. Each item in this section should be read completely before proceeding to other sections of this manual. If there are any questions contact Barcode Automation, inc at 1-800-528-9167 for assistance.

  • Page 4: Optical Safety

    WARNING Use of controls, adjustments or performance of procedures other than those specified herein may result in exposure to hazardous radiation or electrical voltages. OPTICAL SAFETY Never stare directly into laser beam. The laser diode is interlocked with the motor that turns the polygon mirror so that if the motor slows or stops for any reason the laser will be automatically turned off.

  • Page 5: Required Maintenance

    REQUIRED MAINTENANCE REQUIRED MAINTENANCE The BA-220 DualBeam laser window should be cleaned both inside and outside as needed The BA-440 window should be cleaned as needed with a non- with a non-abrasive glass cleaner. abrasive glass cleaner. Optical components inside the reader should The internal reader optics should be cleaned at 6 month intervals with 100% denatured be inspected and cleaned at 6 month intervals.

  • Page 6: Warning Label Placement

    Warning Label Placement for BA-440 AVOID EXPOSURE LASER LIGHT IS EMITTED Front FROM THIS APERTURE CLASS II LASER PRODUCT THIS PRODUCT CONFORMS TO DHHS REGULATION 21 CFR SUBCHAPTER J. NOT USER SERVICEABLE CAUTION LASER LIGHT DO NOT STARE INTO BEAM 658nm LASER DIODE 1.0 MILLIWATT MAX.

  • Page 7: Table Of Contents

    Contents Foreword ...................2 Introduction ................3 FCC Class A Statement .............3 CDRH Compliance Statement ...........3 Safety Precautions ..............3 Optical Safety ................4 Electrical Safety .................4 Required Maintenance ..............5 Warning Label Placement ............6 General Specifications ...............8 Input Power .................8 Environmental ..............8 Communications ..............8 Optical .................9 Scan Pattern ................9 Basic Installation and Setup Steps ..........10...

  • Page 8: General Specifications

    General Specifications Light Source: Visible Laser Diode Output Wavelength (nominal): 658 nM CDRH Safety Class II Output Power: less than 1mW/cm Read Zone: Operating Distance: 24 to 72 in (61 to 182 cm) measured from window Decals: Various Color Decals can be used; Configurable to Read decals from Accu-Sort, Amtel, ISI, &...

  • Page 9: Optical

    General Specifications OPTICAL Reading area begins 24” from enclosure and extends out to 72” The laser lines are vertical with a fan shaped read area. Read area chart is measured in inches above pavement. This assumes that the center of the BA-440 DualBeam window is...

  • Page 10: Basic Installation And Setup Steps

    Basic Installation and Setup steps 1. Determine where the Reader will be installed 2. Run wiring to the mounting point for power & communications 3. Pour concrete pad for post mount 4. Secure mounting post and BA-440 DualBeam to the pad 5.
  • Page 11 44” above the pavement where the vehicle tires ride. BAI offers a standard mounting post that is 38” high. It is intended to be used on a 6” curb or concrete mounting pad for a total height of 44”.

  • Page 12: What Wiring Do I Need

    What Wiring do I need? For most applications, there are three basic ways to use the BA-440 DualBeam Reader. As a Stand Alone Access Control 24VDC Gate input 2 wires for relay contacts BA-440 DualBeam reads barcode and if Valid closes relay contacts to Open Gate ♦...
  • Page 13 What Wiring do I need? Reader connected to Access Control Panel Access Control 24VDC Panel Gate input 3 wires for Wiegand Signal BA-440 DualBeam reads barcode decal and sends number to Access Panel ♦ Panel determines if the decal number is Valid and controls gate ♦...
  • Page 14 What Wiring do I need? Reader connected to Computer Security System Computer System 24VDC Gate input 3 wires for RS232 Signal BA-440 DualBeam reads barcode decal and sends data to Computer System ♦ Computer System determines if the number is Valid ♦...

  • Page 15: Typical Installation Illustration

    Typical Installation Illustration With a 38” mounting post, and a 6” curb, the BA-440 DualBeam (at 24” from the housing) can read barcode decals between 35” and 65” above the pavement . Copyright 1999-2012, Barcode Automation, inc.

  • Page 16: Wiring Connections

    Wiring Connections Wiring Terminal Block Main Power Switch Beeper On/Off Switch Copyright 1999-2012, Barcode Automation, inc.

  • Page 17: Wiring Connection Definitions

    Wiring Connection Definitions Input from Power Supply, 24 Vdc @ 1.5A GND IN the negative or “-” from the 24 Vdc power supply +24V IN the positive or “+” from the 24 Vdc power supply OptoIsolated Wiegand Communications Data1 Wiegand 1 data communication to access system Data0 Wiegand 0 data communication to access system Comm...

  • Page 18: Wiring Connection Details

    Wiring Connection Details Power Input Terminals GND IN +24V IN The power input terminals for 24Vdc input are marked for the Ground and +24Vdc leads. Reader is Reverse polarity protected. NOTE: The 24Vdc input must supply 1.5 Amps to the Reader for proper operation.

  • Page 19: Wiegand Connection Terminals

    Wiring Connection Details Wiegand Communication Terminals Data1 Data0 Comm Wiegand communication from the BA-440 can be run two different ways; optoisolated or direct connection. The Optoisolated connection has several advantages, provided the Access panel or telephone entry system supports it. To use the Optoisolated connection the access panel or telephone entry system must provide voltage to the Data0 and Data1 connections on the reader.

  • Page 20: Optoisolated Wiegand Connection

    Wiring Connection Details Wiegand Communication Terminals Data1 Data0 Comm Optoisolated Connection (Preferred) The Wiegand output communication terminals are marked as Data1, Data0 and Common. The normal configuration for Wiegand communication from the BA-440 is optoisolated, where the reader does not supply voltage on the Data0 and Data1 terminals and Comm does not have a direct connection to the reader ground.

  • Page 21: Direct Wiegand Connection

    Wiring Connection Details Wiegand Communication Terminals Data1 Data0 Comm Direct Connection (if Optoisolated connection cannot be used) In some cases the Optoisolated Wiegand communication cannot be used. Generally this is due to the Access panel or telephone entry not providing voltage on the Data0 and Data1 lines. To change the Wiegand connection from optoisolated to direct: 1.

  • Page 22: Vehicle Detect Input Terminals

    Connection Terminal Detail Vehicle Detect Input Terminals Aux In- Aux In+ This is an optional dry contact input (Normally Open) to control when the reader will detect barcode decals. When used the Aux In connection will allow decal reads only when the connection is Closed. DO NOT APPLY VOLTAGE TO THESE TERMINALS.

  • Page 23: Relay Output Terminals

    Connection Terminal Detail Relay Output Terminals AuxOut- AuxOut+ This is a dry contact output whose function changes depending on the reader configuration. See the Configuration manual for details. GdRead- GdRead+ This is a dry contact relay output intended to control a gate operator. See the Configuration manual for details.

  • Page 24: Finishing The Ba-440 Installation

    Finishing the BA-440 DualBeam Installation After the Reader is mounted and the wiring is connected, the opening for in the bottom of the baseplate must be sealed off. Use silicone, RTV, or other sealant to close off the opening in the bottom so it is watertight.

  • Page 25: Mounting Angle

    Mounting Angle The BA-440 DualBeam should be aimed straight across the road as Curb shown. BA-440 Car Window Powering Up the BA-440 DualBeam When testing the BA-440 DualBeam it is useful to have a laptop computer on hand that can communicate with the reader. This allows the installer to take advantage of the diagnostics built into the unit or alter the configuration if necessary.

  • Page 26: Led Indicators

    LED Indicators Look on the decoder circuit board, which is mounted on the opposite side from the wiring terminals. A column of LED indicators provide information on reader operations. From top to bottom they are: Gd Read (Green) - will light for approx 1 second when a decal is read Lsr Act (Yellow) - indicates when the laser is on Rst Act (Green) - will light when the unit is being reset Data0 Act (Red)
  • Page 27 LED Indicators Continued… As you pass the barcode through the laser line also watch the two red LED’s (Data0 Act and Data1 Act) that show the status of the Wiegand data lines. When the barcode is read, both should “flash” or “flicker” red very quickly.

  • Page 28: Barcode Label Placement On Vehicles

    Barcode Label Placement on Vehicles 12345 1. Always place the decals on the same side of the vehicle that the reader is on. 2. Apply to the outside of the window glass. Decals will not read reliably through the glass. 3.
  • Page 29 Applying Barcodes 1. After cleaning window surface, 2. Bend decal backing at least Peel decal back 1 inch from backing 90° 3. Line up decal vertically on window, 4. Place squeegee at top of decal Press firmly on top where the backing Press it firmly against window was peeled back.
