Summary of Contents for HWT HWT-1004-XAH
- Page 1 HWT-1004-XAH Battery Pack A ssembly Instructions Battery Pack Assembly Instructions HWT-1004-XAH Ver.: 0.1...
-
Page 2: Change History
HWT-1004-XAH Battery Pack A ssembly Instructions 1 Change History Revision Changes Description Date Author Remark 英文版 (Renee) V0.1 Initial release 2020-09-18 Mike Wang... - Page 3 HWT-1004-XAH Battery Pack A ssembly Instructions 2 Battery Pack Assembly procedure 2.1 Solder the cable of the battery mount on the bike. Step 1: Please disassemble four screws which are marked by red circles in the photo as below. And remove the cover from the battery mount.
- Page 4 HWT-1004-XAH Battery Pack A ssembly Instructions Step 2: Open the cover. Then, the DC-Jack connector has connected with 2 wires by soldering and fixed by gluing already. No more processing. (Red wire is C+, Black wire is C-)
- Page 5 HWT-1004-XAH Battery Pack A ssembly Instructions Step 3: Solder the cable in sequence by the PIN definition of discharge connector. Soler the cables from P+ → C+→CAN-H→CAN-L→P-/C-. Please attention, the two wires P- and C- must be soldered to the same PIN.
- Page 6 HWT-1004-XAH Battery Pack A ssembly Instructions Step 4: Please knot the cable after soldering to prevent the soldering area are separated caused by an external force. Step 5: After soldering cables, please assemble the cover back by four screws to the battery mount.
- Page 7 HWT-1004-XAH Battery Pack A ssembly Instructions 2.2 Assemble the battery mount to the down tube of the bike Step 1: Please note, when fixing the screw head, the height of the screw head cannot exceed the battery frame, to avoid interference during battery assembly and affect the stability of battery fixing.
- Page 8 HWT-1004-XAH Battery Pack A ssembly Instructions 2.3 Install the battery pack to the battery mount Step 1: Please turn off the battery pack power before installing to the battery mount. a. Press the power button from the battery pack, the LED light will light up in sequence and run from the left side to the right side, and then run back to the left side.
- Page 9 HWT-1004-XAH Battery Pack A ssembly Instructions b. To ensure the safety of installation, please press and hold the Power button on the battery pack for 5 ~ 10 seconds until LEDs turn off to make sure the battery pack is powered down already. Then, install the battery pack to the...
- Page 10 HWT-1004-XAH Battery Pack A ssembly Instructions Step 2: Install the batteyr pack to the bike frame. a. Place the bttery pack discharge connector toward the discharge end of the bike mount on the bike frame. See the photo as below.
- Page 11 HWT-1004-XAH Battery Pack A ssembly Instructions c. As shown in the photo below, after pressing the battery pack down by the arrow, you can hear a " Click" sound, indicating that the battery pack has been fixed on the bike mount, and the key can be removed.
- Page 12 HWT-1004-XAH Battery Pack A ssembly Instructions 2.4 Remove the battery pack from the battery mount Step: Turn off the power from the battery pack. And insert the key to turn the lock head to the direction as shown in the photo below to retract the lock head holder to remove back.
