Summary of Contents for PREPLINE B20M
- Page 1 USER MANUAL GEAR DRIVEN PLANETARY MIXER Models: B20M, B30M USR Brands, Inc. Phone: 800-764-1172 | www.usrestaurant.com | sales@usrestaurant.com USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE...
-
Page 2: Table Of Contents
Instruction Manual Contents BRIEF INTRODUCTION ……………………………………………...2 ADVANTAGE ……………………………………………………....…2 TECHNICAL DATA ……………………………………………....…3 INSTALLATION …………………………………………………....…3 USING REQUEST AND NOTICEABLE ……………………..……...….…4 CRICUIT DIAGRAM ………………………………………………....5 MAINTENANCE …………………………………………………....…6 FAILURE ANYLASIS AND ELIMINATION ………………....………6 WARRANTY ……………………………………………………….....….7 SPARE PARTS OF BLENDER ………………………………….....…..8 EXPLODED VIEW..................9 USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE... -
Page 3: Brief Introduction
BRIEF INTRODUCTION B20M B30M mixer are advanced machine which is carefully designed and produced by my company . It uses the principle of planetary motion, and do planetary motion agitator in barrels to mix crushed, powder and liquid food and other functions. -
Page 4: Technical Data
TECHINCAL DATA Speed Model Voltage Frequently Power Capacity Size（mm） （r/min） 0.75K B20M 110V 60Hz 113/168/400 20 qt. 17”L x 21”D x 30.5”H 1.10K B30M 110V 60Hz 113/168/400 28 qt. -
Page 5: Using Request And Noticeable
not less than 15 cm to heat dissipation easily. USING REQUEST AND NOTICEABLE 1. Check whether the power supply voltage is the same with the nameplate. Whether power supply ground wire is reliable. 2. If do not have the plug of the power supply lead, machine should be connected to the whole level disconnect device which is installed on a fixed position by the user at least 3 mm . -
Page 6: Cricuit Diagram
medium or high speed to knead dough! 5.The rise and fall of cylinder: a) When it is mixing , twist the bar to rise the cylinder to the highest position to mix fully. b) After mixing or change agitator, twist the bar to fall the cylinder to disassembly the tank or agitator. -
Page 7: Maintenance
Code SQ1/2 No lamp combination A.C.contact thermorela Travel Name Motor switch switch Quantity 1sets Magnetic starter Remark MAINTENANCE 1. After each using , carefully clean tank, agitator, etc, to ensure food hygiene. 2. Elevator guide rail should be coated with a small amount of grease regularly 3. -
Page 8: Warranty
Keep dry on lifting bar Add oil and handle shaft Voltage is not enough Check the voltage supercharge Reduction on load Motor temperature rise rotation speed is high or quickly and speed according to above to agitator does not choose reduce choose suitable speed well... -
Page 9: Spare Parts Of Blender
cause fault. The validity of the warranty: since the date of the cost ( subject to formal purchase invoice) machine for one year. SPARE PARTS OF BLENDER Handle Agitator shaft Gear VAT clamp seat Agitator shaft Eccentric Shaft sleeving carriage sleeving sleeve Front... -
Page 10: Exploded View
B20M EXPLOSIVE PICTURE USRESTAURANT® RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICE...
