Summary of Contents for Struers LaboUI
- Page 1 LaboUI Instruction Manual Original Instructions Doc. no.: 16207025-01_C_en-us Date of release: 2023.03.13...
- Page 2 Copyright The contents of this manual are the property of Struers ApS. Reproduction of any part of this manual without the written permission of Struers ApS is not allowed. All rights reserved. © Struers ApS 2023.04.04. LaboUI...
-
Page 3: Table Of Contents
Getting started Device description LaboUI Transport and storage Long-term storage or shipping Installation Unpack the machine Check the packing list Installation - LaboUI Noise and vibration levels Operate the device Control panel functions Maintenance and service General cleaning Daily Weekly... - Page 4 Troubleshooting Technical data Technical data - LaboUI Diagrams - LaboUI Legal and regulatory information 10 Manufacturer Declaration of Incorporation of Partly Completed Machinery LaboUI...
-
Page 5: About This Manual
1 About this manual About this manual CAUTION Struers equipment must only be used in connection with and as described in the Instruction Manual supplied with the equipment. Note Read the Instruction Manual carefully before use. Note If you wish to view specific information in detail, see the online version of this manual. -
Page 6: Safety Messages
Wait 5 minutes until residual potential on the capacitors is discharged. 9. Struers equipment must only be used in connection with and as described in the Instruction Manual supplied with the equipment. 10. If the equipment is subjected to misuse, incorrect installation, alteration, neglect, accident or incorrect repair, Struers will accept no responsibility for damage to the user or the equipment. -
Page 7: Safety Messages In This Manual
This sign indicates that additional information and hints are available. Safety messages in this manual WARNING Struers equipment must only be used in connection with and as described in the Instruction Manual supplied with the equipment. CAUTION Keep clear of rotating parts during operation. -
Page 8: Getting Started
3 Getting started Getting started Device description LaboUI is a control panel (grinding/polishing) which can be mounted on the following machines for manual materialographic preparation: LaboPol-20, LaboPol-30 and LaboPol-60. On the control panel the operator can set the rotation speed of the preparation disc, start and stop the machine, control water application and the disc spin function. -
Page 9: Transport And Storage
• Package the unit securely before transportation. Insufficient packaging could cause damage to the unit and will void the warranty. Contact Struers Service. • We recommend that you use the original packaging and fittings. Long-term storage or shipping For instructions on how to prepare the unit for long-term storage or shipping, see the specific machine manual. -
Page 10: Installation - Laboui
5 Installation Installation - LaboUI Note This device must be mounted securely on the machine. Procedure Install the control panel in the connection hole of the machine. 1. Remove the plastic disc protecting the communication cable. 2. Connect the communication... -
Page 11: Operate The Device
Button Function Disc rotation • Starts rotation of the disc (Spin function). Water Manual override • Press the button to apply water. Water is applied when no process is running. • Press the button again to stop applying water. LaboUI... -
Page 12: Maintenance And Service
Do not use acetone, benzol or similar solvents. If the machine is not to be used for a longer period of time • Clean the machine and all accessories thoroughly. Daily • Clean all accessible surfaces with a soft, damp cloth. LaboUI... -
Page 13: Weekly
For further information, or to check the availability of spare parts, contact Struers Service. Contact information is available on Struers.com. Service and repair We recommend that a regular service check be carried out yearly or after every 1500 hours of use. - Page 14 Storage and transport Surrounding 0 – 60°C/32 – 140°F conditions temperature Humidity < 85 % % RH non- condensing Power supply LaboUI is connected directly to LaboPol Dimensions and weight Width 15 cm/5.9" Depth 13.5 cm/5.3” Height 37.6 cm/14.8” Weight 0.8 kg/1.8 lbs...
- Page 15 9 Technical data 16203050 B LaboUI...
- Page 16 Responsibility of the manufacturer The following restrictions should be observed, as violation of the restrictions may cause cancellation of Struers legal obligations. The manufacturer assumes no responsibility for errors in the text and/or illustrations in this manual. The information in this manual is subject to change without notice.
- Page 17 Based on: 16207901 B Declaration of Incorporation of Partly Completed Machinery Manufacturer Struers ApS • Pederstrupvej 84 • DK-2750 Ballerup • Denmark Name LaboUI Model Function Control panel for LaboPol 20/30/60 grinding/polishing machine Type Cat. no. 06206901 The above listed machinery is only intended...
- Page 18 Tõlked leiate aadressilt Katso käännökset osoitteesta Pour les traductions, voir Za prijevode idite na A fordítások itt érhetők el Per le traduzioni consultare www.struers.com/Library 翻 訳 については、 Vertimai patalpinti Tulkojumus skatīt Voor vertalingen zie For oversettelser se Aby znaleźć tłumaczenia, sprawdź...
