This parking system is compliant to:
- EC Council Directive 2006/42/EC Machinery
- DIN EN 14010
Web: www.mutrade.com
Tel.: +86 532 5557 9606 / 5557 9608
Address: No. 106 Haier Road, Jimo District, Qingdao, 266200 P.R. China
E-mail: inquiry@qdmutrade.com
ARP Series
Automatic Rotary Parking system
Please notice that all the speci cation and technical details quoted within this
catalog/datasheet/installation manual maybe out of date or have minor di erences
with our standard equipment from time to time.
Our company reserve the right to change technical details in the description,
information and illustrations in this documentation.
All the speci cation and technical details will be subjected to the drawing
con rmed by the sales contract.
Advertisement
Table of Contents
Summary of Contents for MUTRADE ARP Series
- Page 1 ARP Series Automatic Rotary Parking system This parking system is compliant to: - EC Council Directive 2006/42/EC Machinery Please notice that all the speci cation and technical details quoted within this - DIN EN 14010 catalog/datasheet/installation manual maybe out of date or have minor di erences with our standard equipment from time to time.
- Page 2 Series Introduction Rotary parking system is one of the most space-saving systems that allows you to park up to 16 SUVs or 20 sedans in only 2 conventional parking spaces. The system is independent, no parking attendant is required. By inputting a space code or swiping a pre-assigned card, the system can recognize your vehicle automatically and nd the faster path to deliver your vehicle down to ground either clockwise or...
- Page 3 Multiple car space solutions Allowing you to park up to either 20 sedans 16 SUVs ARP-8 ARP-10 ARP-12 ARP-16 ARP-20...
-
Page 4: General Parts
General parts 1 Rain shelter 2 Platform 3 Platform suspension arm 4 Rack 5 Gear motor 6 Post 7 Control panel 8 Photocell sensor 9 Electric box Guide rail Car door stopper Fence... -
Page 5: Main Features
Main Features German motor Windproof & anti-seismic performance SEW/NORD brand motor, max 22kw, to ensure stable Our unique design achieves stability under 10th grade running and long durability wind and magnitude 8.0 earthquake even when platform moves to top position. Accurate &... - Page 6 Standard Accessories / Parts Gifts for Free The 5 accessories/parts are o ered free as standard to celebrate the exclusive collaboration between Mutrade & Jiuroad in global market except Mainland China, taking e ective from July 14th, 2022. Rain shed Car door stopper Windproof &...
-
Page 7: Speci Cations
Speci cations Sedan type systems Model Number ARP-8 ARP-10 ARP-12 ARP-16 ARP-20 Sedan spaces Motor power (kw) System height (mm) 9,920 11,760 13,600 17,300 20,960 Max retrieve time (s) Rated capacity (kg) 2000 Car size (mm) Sedans only; L*W*H=5300*2000*1550 Cover area (mm) L*W=6,500*5,500 L*W=6,500*5,700 Power supply... -
Page 8: Safety Characteristics
Safety characteristics High speed auto door The door can be installed in front of system. It automatically shuts during system running to prevent entrance by mistake and protect the cars from theft and vandalism. It can also detect vehicles access and open intelligently. - Page 9 Car door stopper Car door opening is highly hazardous to both the vehicles and system. A specially made device can be added to prevent such happening during system running. Windproof device When system goes up to 20m, wind load is one of potential hazards to structural stability. The wind proof device can keep the whole structure stable under the 10th grade wind even when platforms are moving to the highest position.
- Page 10 Dimensions Sedan system SUV system 5.7m 5.5m 6.5m 6.5m...
-
Page 11: Operation
Operation Two ways to operate the system: 1. Code: input the space number of desired platform, then press RUN to start. 2. Card: users can swipe a speci c card to get a certain platform down to the entrance level. Each card matches a speci c platform. -
Page 12: Maintenance
Maintenance To ensure proper and stable function of entire ARP system in the long run, regular and periodic inspection & maintenance are also of vital importance: Weekly Monthly 1) All connecting parts and transmission parts shall 1) Conduct comprehensive inspection to lubrication be working properly free from any bad abrasion and status of whole system big clearance;... -
Page 13: Electrical Installation Preparation
+40c. Atmosphere humidity 50% at +40C. If the local enter & exit frequently. circumstances di er from the above, please contact Mutrade. Electrical installation preparation Parking Cabling preparation to be performed by the customer - Input car number or swipe IC card to lower your platform - To the main switch. - Page 14 References...
