Summary of Contents for FUELCLOUD Kiosk Lite
- Page 1 Kiosk ite Installation Manual Manual Version 1.0 Revised 3/13/23...
- Page 2 Physical installation cannot be completed without an online account. For help on the FuelCloud website, please see the Quick Setup Guide video on the dashboard. Get the installer...
- Page 4 Privacy State ent FuelCloud is committed to protecting user’s privacy. For more information about FuelCloud’s privacy policy, please review our full terms and conditions at: fuelcloud.com/privacy-policy FCC State ents Find complete details of our FCC compliance at: fuelcloud.com/fcc-compliance Ter s and Conditions For a complete terms and conditions, including warranty disclaimers visit: fuelcloud.com/terms-condition...
- Page 7 BEFORE INSTALLATION Hardware and Install Warnings Installations must be in accordance with the National Electrical Code (NFPA No. 70) and the Automotive and Marine Service Station Code (NFPA No. 30A). The installer is responsible for investigating and following any applicable local codes. Restricted Access: Access can only be gained by service persons or by users who have been instructed about the reasons for the restrictions applied...
- Page 9 Hazardous Area Examples Classified Areas Adjacent to Dispensers: SIDE VIEW TOP VIEW Classified Areas Adjacent to Dispenser Mounted on Aboveground Storage Tank: SIDE VIEW TOP VIEW END VIEW Class 1, Div 2 or Class 1, Zone 2 Class 1, Div 1 or Class 1, Zone 1 Dispenser Note: Diagrams are not to scale.
-
Page 10: Turn Power Off
BEFORE INSTALLATION Identify Your Installation Location The FuelCloud Kiosk Lite must be installed 18 inches away from all fuel dispensers and tanks. All conduits coming from hazardous areas must have seal-offs 18 inches above the hazardous zone. AC power is required. Choose a location where it is accessible. - Page 11 Kiosk Lite back mounted dimensions (in.) : Kiosk Lite back mounted instructions: 1. Knock out the plugs on the back. 2. Mount the Kiosk Lite to a wall or brackets. *Mounting hardware not included.
- Page 12 INSTALLATION Power Wiring Warning: AC power and communication wires must be in separate conduits. 1. Unlock and open the Kiosk Lite panel. 2. Mount MDR-60- 2 power supply on the DIN rail.
- Page 13 3. Connect 110/ 0 VAC to L, N(L ), and G of the power supply. 4. Connect V+ and V- to the DC terminal on the screen underside. Antenna connections: 5. Connect the Wi-Fi (white), cellular (blue), and GPS (black) antennas.
-
Page 14: Optional Hardware
INSTALLATION Optional Hardware Install a heater: 1. Mount the included heater onto the DIN rail. 2. Connect 110VAC to the heater. Line connects to terminal 1 and neutral connects to terminal 2. - Page 15 Install an ethernet switch: 1. Mount the MDR-60-2 power supply on the DIN rail. 2. Connect 110/220 VAC to L, N(L2), and G of the power supply. 3. Connect V+ and V- to the DC terminal on the ethernet switch.
- Page 17 INSTALLATION Power On & Verification Turn on power to the kiosk at the breaker. TRIP Kiosk should take about 5 seconds to start booting up: Once you see a list of pumps on the screen, you’re all finished! There may be fog inside the screen that will burn off after an hour or so in daylight.
- Page 18 Internet If cellular and hardwired ethernet are not options for connecting the FuelCloud kiosk to the internet, the kiosk can be connected to a Wi-Fi network. The SSID and password must be known to bring the kiosk online. The CloudBox can be connected directly to the kiosk through ethernet.
- Page 19 Revised 03/13/ 3...
