- Page 1 Moab Quick Start Guide INSTALLERS: PLEASE LEAVE THIS MANUAL WITH THE OWNER. 400199 v. 1.3 | March 2023...
- Page 2 You can confirm your Moab board is paired by connecting it to your screen and looking at the 485 pairing LED located just to the left of the RJ45 Motor Port on the top of Moab. If this LED is off then Moab has already been paired, if this LED is ON then you need to pair the motor.
- Page 3 ***If this is an LV motor, fine adjustments are not available, pushing and holding RED/UP or BLUE/DOWN buttons, will move the screen until you let go. QR code for 2 min video on Pairing Moab to the motor Step 2 400199 Ι v. 1.3 Ι March 2023...
- Page 4 Switching to USER mode. Move the #1 Dip Switch into the OFF position. In User mode a single press on RED/UP will move the screen upper limit and a single press on BLUE/DOWN will move the screen to lower limit. RED/UP BLUE/DOWN Screen Innovations...
