- Page 1 DV12 PROFESSIONAL HOT WATER EXTRACTION CLEANING SYSTEM OWNER/ OPERATOR MANUAL ThermaCor Incorporated #1 Carpet and Upholstery Cleaning Systems Thermacorinc.com 1-877-483-1049...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Message from the Corporate O ce ....................2 Identifying Features and Additional Commercial Units..............3 Inspection Upon Delivery ........................4 Important Safety Information ........................ 4 Set-Up Procedure ............................5 Extraction Cleaning Procedure ......................5 System Clean-Up ............................6 General System Maintenance ........................ -
Page 3: Message From The Corporate O Ce
Thank you for joining the ever-growing family of Thermax owners. Here’s to many years of use and, most importantly, here’s to a healthier indoor environment. Sincerely, Michael Johnson President ThermaCor, Inc. *Steam cleaning is the generic technology used to describe the hot water extraction process of cleaning carpet. -
Page 4: Identifying Features And Additional Commercial Units
ADDITIONAL COMMERCIAL UNITS IDENTIFYING FEATURES Also available to make your job easier, the Thermax CP5 gives you the power and efficiency to clean carpets and upholstery in both commercial and residential settings. THERMAX CP5 ermax CP5 is an industry proven performer, built to endure the most 1) Clean Solution Tank demanding carpet and upholstery... -
Page 5: Inspection Upon Delivery
INSPECTION UPON DELIVERY Carefully unpack and inspect the Thermax DV12 and be sure all components ordered are included. Orders might be packed in more than one box. NOTE: Contact the carrier immediately regarding any damage incurred during shipping as it is your responsibility to le a damage claim with the carrier. -
Page 6: Set-Up Procedure
SET UP PROCEDURE 1) Pre-mix cleaning solution as required for speci c application in a ve gallon (19 liter) pail. Pour pre-mixed solution through solution ll hole of system. NOTE: This system has a built-in solution heat maintenance feature, start with hot water if possible. Hot water is hygienic and maximizes cleaning potential. -
Page 7: System Clean-Up
SYSTEM CLEAN UP When the carpet cleaning process is complete, it’s time to clean the system. De-activate all switches to “OFF” position. 1) Empty and rinse recovery tank. 2) Empty solution tank. a. To empty solution tank set the preheat witch to “OFF” position. Now activate “VACUUM” switch to “Single Vac” position. b. -
Page 8: Optional Package And Accessories
OPTIONAL PACKAGES & ACCESSORIES The following optional packages and accessories do not come standard with your DV12. Contact your local distributor or the Corporate O ce to receive details on how to purchase these items. CLEAR VIEW FLOOR WAND DELUXE CONTRACTOR PACKAGE PART # 29 771 00 SPECIAL ORDER ONLY PART # D CONTR 12 Includes: 30’... - Page 9 OPTIONAL ACCESSORIES CONTINUED DV12 W/20 FT. HIDE A HOSE DELUXE AUTO DETAIL PACKAGE & BUILT ON STAINLESS PART # D AUTO 12 STEEL DETAILER INCLUDES: 6’ HAH W/BUILT ON SS PART # DV12 20D HAH DETAILER, SS CREVICE TOOL, 20’ HAH 20 FT.
-
Page 10: Cleaning Solutions
STEAM CLEANING SOLUTIONS DEFOAMER 6070 : TRIAD CARPET & UPHOLSTERY CLEANER Available in 1 gal., 1 gal. case of 4, 6060 : Available in 1 gal., 1 gal. case of 4, Special Special order only 55 gal drum. order only 30 gal. and 55 gal drum. Designed to Defoamer is used in the solution liftand oils, stains, and deeply embedded soils from recovery tank to control potentially... -
Page 11: Dv12 Specifi Cations
THERMAX DV12 SPECIFICATIONS DIMENSIONS: RECOVERY TANK: SOLUTION TANK: • Length ..... 34” • High-Density Polyethylene • Hygienic Stainless Steel • Width 19” •... -
Page 12: Troubleshooting
TROUBLESHOOTING CONDITION CAUSE CORRECTION System Will Not Operate 1) Plugged into dead outlet 1) Plug into live grounded outlet 2) Blown fuse or breaker 2) Replace fuse or breaker 3) Defective power cord 3) Replace power cord 4) Defective switch 4) Replace switch 5) Loose wiring 5) Properly connect wiring... -
Page 13: Dv12 Base Unit Schematic
THERMAX DV12 SCHEMATIC 99 99 THERMINATOR - DV12... -
Page 14: Dv12 Base Unit Parts List
THERMAX DV12 PARTS LIST ITEM NO. THERMAX NO. DESCRIPTION ITEM NO. THERMAX NO. DESCRIPTION 24-005-01 ASSY, DOME, SMOKE, DV12 02-680-00 SWITCH, THERMAL RESET 23-005-005 GASKET, DOME, DV12 05-355-00 SHEILD, HEAT, DV12 24-007-01 ASSY, LID, DV12 04-573-00 HINGE,CASE,SS, DV12 04-058-00 SCREW #6 X 5, PHIL, WOOD, SS HOUSING 04-276-00 WASHER, WAVE SPRING, .760 OD 01-295-103... -
Page 15: Auto Detail Package Parts List & Schematic
DV12 WARRANTY The Thermax DV12 is warranted to be free from Manufacturers defect for a period of three (3) years on all electrical components such as the pump, heater, and vacuum motors. However once the part has been replaced it then becomes a limited 90 day warranty 1) Warranty extended only to original owner. -
Page 16: Thermax Warranty
____________________________________________________________________________________________ Name of Distributor ____________________________________________________________________________________________ Distributor Phone Number ____________________________________________________________________________________________ Date of Purchase ____________________________________________________________________________________________ Serial Number PLEASE NOTE: Retain this owner’s manual along with your copy of the Warranty Registration Form. Proof of purchase must also accompany all warranty claims. 2219 Eagle Dr Middleton, WI 53562 1-877-483-1049 Website: www.thermacorinc.com...
