General Introduction Purpose of this document Related documents The device Device description & variants Symbols Scope of delivery Technical function Safety Symbols used Usage limits 3.2.1 Intended use 3.2.2 Type of use Field of use – electromagnetic compatibility (EMC) 3.2.3 Spatial limits 3.3.1 Required areas / space...
Page 4
Maintenance Cleaning Problem remedies / FAQ Support Decommissioning Deinstallation Disposal Annex Technical data Notes on CE mark Manufacturer´s address Manual_DTC133UHL_EN Rev. 1.0 / 17.11.2022 4 / 18...
3D Global Solutions GmbH reserves the right to make changes to its products, their documentation or specifications without prior notice. All information and functions described in this document refer to the device status (hardware &...
2 The device 2.1 Device description & variants The device may be available in different variants with different characteristics. The description and technical data applicable to the respective variant are listed in the corresponding datasheet. Unless otherwise indicated, the information given in these operating instruction applies to all variants.
3 Safety Start of the safety instructions • Read this section particularly carefully before using the device! • Always keep this information close at hand! 3.1 Symbols used Within this operation instruction, various symbols are used for specific indication of dangers, risks or information.
3.2 Usage limits 3.2.1 Intended use The product is intended exclusively for the following use: The visualization of specially prepared 3D image content or 2D image content as well as the optional detection of the current position of a user in front of the screen by means of an integrated headtracking camera to enable the position-specific preparation of the 3D image content.
3.3 Spatial limits 3.3.1 Required areas / space The following areas/spaces are required for the intended use: • Floor space (W x D): (minimum required area on a sufficiently stable, level table with ergonomically expedient working height) depending on used stand / display mounting •...
3.3.2.2 User orientation (the way in which the user must be aligned with the display) • Both eyes in horizontal alignment (head not tilted) • View to the front of the display When using the headtracking system: • Direct, unobstructed view of the entire front of the display (incl. housing) •...
3.4 Temporal limits The intended use presupposes the following temporal limits: 3.4.1 Service life (how long the product can be operated before it has to be replaced) ca. 15.000 Operation hours ≙ ca. 5 years at max. permissible duty cycle 3.4.2 Duty cycle (how often can the product be used and for how long) 10 h / day...
• Not in the vicinity of easily inflammable materials • On a stable flat surface of a suitable table with sufficient load-bearing capacity and an ergonomically expedient working height (e.g. inspection workstation) • No direct sunlight Temperature range: 10° - 40° C Relative humidity: max.
• Opening the housing, repairs, modifications or conversions to the device or attempts to do so will result in the immediate voiding of any warranty/liability claims against 3D Global Solutions unless these have been expressly approved in writing by 3D Global Solutions.
3.7 Perception of stereoscopic images Some people may experience undesirable effects such as dizziness, eye ache, headache, fatigue or nausea when viewing stereoscopic images, especially when viewing content with very strong 3D effects. Persons with impaired eyesight or defective vision may also experience such or similar effects to a more frequently or intensified extent.
4 Commissioning 4.1 General instructions To achieve the best possible results with your system, please observe the following general instructions: • The optimum image quality on the display is achieved after a warm-up period of approx. 20-30 minutes. • Make sure that your system is positioned so that the display is operated at an angle of 90°...
• Connect a suitable ext. power supply to the designated interface of the device. • Start your system. • If necessary, switch on the display with the "Power button" on the back. 5 Operation • The device switches on automatically as soon as an image signal is present. ...
Page 17
6.2 Problem remedies / FAQ The following list is intended to help you localize possible errors and to suggest possible causes and solutions. If necessary, contact the manufacturer’s Support department. Problem Possible cause Possible remedies Remarks • Check the connections •...
Page 18
The EU Declaration of Conformity is kept at the disposal of the competent authorities by the manufacturer and will be made available on request. 8.3 Manufacturer´s address 3D Global Solutions GmbH Am Krebsgraben 15 / Gebäude 2.2 78048 Villingen-Schwenningen / Germany T +49 7721 916 19-60 www.3dgs.eu...
