Owner's Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, oper-
ate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions
could result in personal injury and / or property damage! Retain instructions for future reference.
Portable Dehumidi�ier
Descripti on
WELTEM Dehumidifi er is suitable for areas/places where hu-
midity causes serious problems.
Strong dehumidifi cati on performance can prevent any issues
resulted from humidity. Auto drain pump is equipped in the
unit so it is very convenient for user A control panel provides
ease of use and contains a self-diagnosti c functi on and display,
showing operati ng modes, current humidity and target humid-
ity, and faults.
If an abnormal operati on occurs, a visual display of the fault is
shown. Caster wheels are included for easy portability. Suitable
applicati ons include: a factory or work place, industrial kitchen,
computer room, emergency cooling, outdoor event, etc.
Unpacking
Aft er unpacking the unit, carefully inspect unit for any damage that may have occurred during
transit. Check for any loose, missing, or damaged parts.
Specifi cati ons
Model No.
Power Supply Ph-V-Hz
WPD-120
Single Phase, 230V, 50Hz
Model No.
WPD-120
Weight (Net / Gross)
Model No.
WPD-120
141 / 152 lbs.(64/ 69kg)
Owner's Manual
Dehumidifi cati on
Nema Plug
5-15P
Lbs(kg)
Power Con-
Amount
sumpti on Watt s
120L/1day
Power Cord
Power Cord
Gauge AWG
Length ft
14
Supply air Flow
(CMH)
828
1
WPD-120
Figure 1
Rated Current
Amps
920
4.42
Dimensions
W x D x H - in. (mm)
21.7x 23.9 x 33
10
(551 x 607 x 839)
Ambient temperature
range °F( °C)
59~95(15~35)
WPD-120
WPD-120
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weltem Icen IPD-120
Summary of Contents for Weltem Icen IPD-120
- Page 1 / or property damage! Retain instructions for future reference. Portable Dehumidi�ier Descripti on WELTEM Dehumidifi er is suitable for areas/places where hu- midity causes serious problems. Strong dehumidifi cati on performance can prevent any issues resulted from humidity.
-
Page 2: General Safety Information
Owner’s Manual WPD-120 Specifications (Continued) Target humidity range Setting range Model No. WPD-120 0 ~ 99 % 20 ~ 80 % Refrigerant Wheels Design Pressure - Model No. Type / oz(g) pcs / diameter Hi/Low Psig WPD-120 R-410A / 35.3(1000) 4 / 76mm 450 / 250 Compressor overload protector, Anti-freezing thermis-... - Page 3 Owner’s Manual WPD-120 DO NOT operate the unit in explosive or flammable environments. 14. DO NOT use the plug to start and to stop the unit. Always use the control panel to start and to stop the unit. 15. Always turn off the unit when it is not in use and unplug the power plug from the electrical outlet.
- Page 4 Owner’s Manual WPD-120 Assembly (WPD-120) Front View Control box Model 디스플레이 PART NO. 1D R icen02616 제습기디스플레이국문 바이어명 아이센 제습기 전제품 라벨 사이즈 129x74 Display/Electronic controller 알 람 It is for controlling the function 현재습도/온도 설정습도/온도 전원 송풍 제습 예약 수정사항...
-
Page 5: Installation
Owner’s Manual WPD-120 Installati on WARNINGS REGARDING PROPER LOCATION FOR INSTALLATION Do not use the unit in explosive environments or in areas where fl ammable gas leakage may occur. Do not use the unit in areas where it will be exposed to rain or water. Do not use the unit in a corrosive atmosphere. -
Page 6: Operation
Owner’s Manual WPD-120 Operation CONTROL PANEL (1) Display panel for Icen dehumidifier Figure 4 (2) Description of display panel for Icen dehumidifier 1) Power is supplied with deeping sound and fan starts to work when POWER power button is pushed. (Fan starts from Low speed) BUTTON 2) The unit restarts automotically in the case of short-term blackout 1) It works on dehumidification and blower mode... - Page 7 Owner’s Manual WPD-120 (2) Description of display panel for Icen dehumidifier 1) Time is set by pressing the TIMER button for a second - If user do not press any buttons for 5 seconds, it returns to original mode by pressing dehumidification button or selecting set time - During setting mode, user controls setting range by pressing the 'UP' and 'DOWN 'button.
-
Page 8: Maintenance
Owner’s Manual WPD-120 Maintenance FILTER CLEANING (See Figures 5 and 6) Dehumidifier WPD-120 has 2 filters, 1) Open the front grill 2) Slide filter up and use a vacuum cleaner to remove the dust from the filter 3) If the filter is heavily corvered with dust and dirt, warm water and mild sopa or neutral deter gent may be used to wash the filter Do not use any other chemicals to clean filter, as they will likely damage the filter. -
Page 9: Self Diagnostic Codes
Owner’s Manual WPD-120 Maintenance (Continued) – To ensure your product is covered by warranty, the complete faulty product along with your original purchase receipt must be provided at the place of purchase. Product Portable Dehumidifier Customer: Please read and keep this Model No. - Page 10 Owner’s Manual WPD-120 Table 1- Alarm Codes...
-
Page 11: Wiring Diagram
Owner’s Manual WPD-120 Wiring Diagram WPD-120/150 D1.0 PRESSURE SWITCH Power Remote Control (Option) DRAIN PUMP COM CO SEN3 ICE_TEMP SENSOR IR/FU IN_HUMIDITY SENSOR IR/FT PRESSURE SWITCH (FUSE) (Option) T (AC) S Power 1P AC 115V-60Hz 1P AC 208-230V, 50/60Hz FAN' MOTOR MC 1 OCR 1... - Page 12 Technical Advice and Recommendations, Disclaimer. Notwithstanding any past practice or dealings or trade custom, sales shall not include the furnishing of technical advice or assistance or system design. Weltem as- sumes no obligations or liability on account of any unauthorized recommendations, opinions or advice as to the choice, installation or use of products.
