MODEL 825TKL TRACK LOADER
OWNER'S MANUAL – ORIGINAL INSTRUCTIONS
CONGRATULATIONS!
You are now the proud owner of the BARRETO Track Loader. The OPERATOR'S MANUAL is
attached to the machine. Please study it and this manual to become familiar with the Track Loader, its
characteristics, and method of operation. Pay particular attention to the safety and operating
instructions to prevent personal injury or equipment damage.
If you have any questions or need any replacement parts in the future, please contact us at your
convenience. Our toll-free phone number, fax and email are listed below.
THANK YOU for your patronage and confidence in BARRETO equipment.
Barreto Manufacturing, Inc.
Innovative Equipment Engineered to Last
66498 Hwy 203, La Grande, OR 97850
(800) 525-7348 (541) 963-7348
FAX (541) 963-6755
E-Mail:
info@barretomfg.com
Web Site:
http://www.barretomfg.com
U.S. Patent No. 10,260,567
Machine Identification Record
Machine model number
Machine serial number
Engine manufacturer
Engine model number
Engine serial number
825TKL OWNER'S MANUAL
THE
HYDRAULIC TRACK LOADER
________________________
________________________
________________________
________________________
________________________
10/17/22
Page 1 of 22
Advertisement
Table of Contents
Related Manuals for Barreto 825TKL
Summary of Contents for Barreto 825TKL
- Page 1 OWNER’S MANUAL – ORIGINAL INSTRUCTIONS CONGRATULATIONS! You are now the proud owner of the BARRETO Track Loader. The OPERATOR’S MANUAL is attached to the machine. Please study it and this manual to become familiar with the Track Loader, its characteristics, and method of operation. Pay particular attention to the safety and operating instructions to prevent personal injury or equipment damage.
-
Page 2: Table Of Contents
TABLE OF CONTENTS TRACK LOADER INSTRUCTIONS UPON DELIVERY SERVICE INFORMATION HOUR METER TRACK LOADER INTENDED USE LUBRICATION REQUIREMENTS OPERATOR TRAINING WARRANTY OF BARRETO MANUFACTURING EQUIPMENT MAINTENANCE PREPARATION ROUTINE MAINTENANCE HYDRAULIC HOSE REPLACEMENT CHANGING THE HYDRAULIC FLUID ENGINE MAINTENANCE SCHEDULE _____... -
Page 3: Track Loader Instructions Upon Delivery
ENSURE THAT THE RESERVOIR FLUID LEVEL IS VISIBLE IN THE SIGHT GAUGE BEFORE STARTING THE MACHINE. IMPORTANT - The engine on the Barreto Track Loader may or may not have been serviced prior to shipping. Shipping regulations may prohibit shipping with fuel or oil in the engine. Check levels and add oil and fuel as required before starting engine. -
Page 4: Hour Meter
HOUR METER The 825TKL features two ways of checking the machine’s hours. The first is a physical, cumulative hour meter which tracks the total amount of hours the engine has been running. The second hour meter is built into the digital display which also tracks the hours running. The physical hour meter allows the owner to easily check total hours without turning the machine on. -
Page 5: Track Loader Intended Use
This Track Loader is designed to attach to industry-standard tools and implements for light and medium duty construction and landscaping work. LUBRICATION REQUIREMENTS Grease at the intervals indicated per the illustration of grease lubrication points. There is also a grease diagram decal on the machine. 825TKL OWNER’S MANUAL 10/17/22 Page 5 of 22... -
Page 6: Operator Training
• Unloading the Track Loader from the trailer. WARRANTY OF BARRETO MANUFACTURING EQUIPMENT Barreto Manufacturing, Inc. warrants all BARRETO equipment to be free of defects in material and workmanship for a period of one (1) year. Warranty period begins on date of delivery to the original user. - Page 7 To select the operating speed of the track drive, press the “Speed Select” button on the display, then press the button again to cycle through the speed drive options. TIP-OVER PROTECTION 825TKL OWNER’S MANUAL 10/17/22 Page 7 of 22...
- Page 8 Pressing the System Information button again will take the owner to the second screen. From this screen, the owner can check the tool solenoid switches and see feedback from the solenoids. If a 825TKL OWNER’S MANUAL 10/17/22 Page 8 of 22...
- Page 9 Any changes made from the diagnostics pages are saved by turning the key off and on again. After turning the key off and on again, the code must be entered at the lockout screen to access the diagnostics and options again. 825TKL OWNER’S MANUAL 10/17/22 Page 9 of 22...
-
Page 10: Routine Maintenance
• Fasteners • Safety decals Barreto recommends using genuine Barreto spare parts to ensure not only quality but also the health and safety of the operator. Clean safety decals often using soap and water. Do not use abrasive cleaners or solvents such as mineral spirits that may damage the decals. -
Page 11: Hydraulic Hose Replacement
• Fill to the top of the sight glass using a suitable ISO 68 hydraulic fluid. • Replace fill plug. • Dispose of the used fluid according to your local laws and regulations. 825TKL OWNER’S MANUAL 10/17/22 Page 11 of 22... - Page 12 KUBOTA ENGINE MAINTENANCE SCHEDULE 825TKL OWNER’S MANUAL 10/17/22 Page 12 of 22...
-
Page 13: Engine Maintenance Schedule
Please see your engine owner’s manual for specific procedures and products to use for proper maintenance of your engine, as well as proper disposal of used parts/fluids. 825TKL OWNER’S MANUAL 10/17/22 Page 13 of 22... -
Page 14: Track Tension Adjustment
2. Remove axle from rear idler, remove three bolts holding rear idler side plate, remove rear idler. 3. Remove/replace track and rear idler. 4. Reverse procedure to replace track. Adjust track tension per instructions and illustration. 825TKL OWNER’S MANUAL 10/17/22 Page 14 of 22... -
Page 15: Arm Lockout
To lock arms in the fully raised position, remove the lock pin from the cylinder lockout bracket and allow it to swing down around the arm cylinder. Place lock pin in the lower bracket holes to capture cylinder shaft. 825TKL OWNER’S MANUAL 10/17/22 Page 15 of 22... -
Page 16: Battery Maintenance
8. Apply a light coating of grease to the battery terminals to help prevent corrosion. 9. Reinstall the battery securely into the Track Loader. 10. Reconnect the cables. Attach the positive cable first, then the negative one. 825TKL OWNER’S MANUAL 10/17/22 Page 16 of 22... - Page 17 9. When the battery is fully charged, turn off and unplug the charger from the electrical outlet, then disconnect the charger leads from the battery posts. 10. Reinstall the battery securely into the Track Loader. 11. Reconnect the cables. Attach the positive cable first, then the negative one. 825TKL OWNER’S MANUAL 10/17/22 Page 17 of 22...
-
Page 18: Track Loader Electrical Schematic With Kubota
KUBOTA ENGINE ELECTRICAL SCHEMATIC TRACK LOADER ELECTRICAL SCHEMATIC 825TKL OWNER’S MANUAL 10/17/22 Page 18 of 22... -
Page 19: Hydraulic Schematic
HYDRAULIC SCHEMATIC 825TKL OWNER’S MANUAL 10/17/22 Page 19 of 22... -
Page 20: Specifications
SPECIFICATIONS MODEL NUMBER E825TKL DIMENSIONS KUBOTA DIESEL Weight 2950 lb (1338 kg) 52.2” (1.32 m) Height 80.12” (2035 mm) Length 35.5” (901.7 mm) Width ENGINE Engines KUBOTA D1105 Fuel Diesel Power: hp (kW) at 3000 RPM 25 hp (18.6 kW) Fuel Capacity 4.6 U.S. -
Page 21: Track Loader Troubleshooting Guide
TROUBLESHOOTING GUIDE CAUTION!! Always use extreme care when troubleshooting or making adjustments on Track Loader. Stay clear of moving parts when engine is running. Stop engine before disassembling any component. A. Entire hydraulic system does not operate, and the engine is not under load. 1. -
Page 22: Index
G. Auxiliary tool not working 1. Tool function switch Verify HF tool switch is set to Neutral (center position), then select HF Tool again on display INDEX BATTERY, 2, 7, 16, 17 BATTERY CHARGING, 17 BATTERY ELECTROLYTE LEVEL, 16 BATTERY MAINTENANCE, 16 BATTERY VOLTAGE LEVEL, 17 CHANGING THE HYDRAULIC FLUID, 2, 11 DECALS, 9...
