Summary of Contents for ELERIX EXS-410MHC-B
- Page 1 Technical manual ELERIX SOLAR PANEL Mono Half Cut Crystalline Solar Module 410Wp Black PRODUCT WEBPAGE www.elerix.com EXS-410MHC-B...
- Page 2 ELERIX SOLAR PANEL Mono Half Cut Crystalline Solar Module 410Wp Black ELERIX Mono Half Cut Crystalline Solar Module 410Wp Key Features Excellent module efficiency up to: 18.42% IP68 junction box for long-term weather endurance Heavy snow load up to 5400 Pa, wind load up to 3600 Pa...
- Page 3 14.0 ELERIX SOLAR PANEL 12.0 1000W/m 11.0 10.0 Mono Half Cut Crystalline Solar Module 800W/m Front View 410Wp Black Front View 600W/m 1096 400W/m 1048 1096 1096 1096 1048 200W/m Nameplate 4-Φ9×14 Nameplate Installing Hole 4-Φ9×14 Installing Hole Junction Box Junction Box 6-Φ4.3...
- Page 4 ELERIX SOLAR PANEL Mono Half Cut Crystalline Solar Module 410Wp Black I-V CURVES OF PV MODULE(395 W) I-V CURVES OF PV MODULE(395 W) 14.0 12.0 1000W/m 11.0 10.0 800W/m 600W/m 400W/m 200W/m Voltage(V) Electrical Specification EXS-410MHC-B Maximum Power (Pmax) 410W Module Efficiency 21.40%...
- Page 5 ELERIX SOLAR PANEL Mono Half Cut Crystalline Solar Module 410Wp Black Electrical DATA@NOCT EXS-410MHC-B Pmax [W] Vm [V] 32.80 Imp [A] 9.45 Voc [V] 39.10 Isc [A] 10.00 NOCT: Irradiance: 800W/m , Ambient Temperature: 20°C, Air Mass: 1.5, Wind Speed: 1m/s...
- Page 6 ELERIX SOLAR PANEL Mono Half Cut Crystalline Solar Module 410Wp Black Packaging Configuration Modules per ox 31 pieces Number per 20GP 276 pieces Modules per 40’ HQ 806 pieces Temperature Characteristic NMOT (Nominal Module 45°C (±2°C) Operating Temperature) Temperature Coefficient of P - 0.36%/°C...
