- Page 1 ZINTRA BEAMS CLOSED RAFTER zintraacoustic.com 5 X 5 4 X 5 3 X 5 2 X 5 1 X 5 PAGE 1...
- Page 2 ZINTRA BEAMS CLOSED RAFTER zintraacoustic.com PARTS AND HARDWARE FOR A TYPICAL ASSEMBLY CLOSED RAFTER VERSION / QTY 8in MAIN BEAMS ( 96in / 72in / 48in / 24in ) 5 X 5 4 X 5 3 X 5 2 X 5...
- Page 3 ZINTRA BEAMS CLOSED RAFTER zintraacoustic.com STEP 1 BEAMS ASSEMBLY ASSEMBLE INDIVIDUALS PARTS AS PER PURCHASED PACKAGE. FOLD 8IN MAIN BEAM AND SECURE IT BY INSERTING BEAMS CLIPS INTO PRE-CUT RECTANGULAR HOLES. *BEAMS CLIPS QTY FOR 8IN MAIN BEAMS: *IMPORTANT: DO NOT INSERT CLIPS INTO 96IN BEAM - x6;...
- Page 4 ZINTRA BEAMS CLOSED RAFTER zintraacoustic.com STEP 2 PREPARING 8IN MAIN BEAMS BEFORE ASSEMBLY DEPENDING ON THE ASSEMBLY DETERMINE HOW MANY BEAMS ARE GOING INSIDE AND HOW MANY OUTSIDE THE ASSEMBLY. 2.1 FOR OUTSIDE BEAMS REMOVE PRE-CUT 2.2 FOR INSIDE BEAMS REMOVE PRE-CUT RECTANGULAR HOLES JUST ON ONE SIDE.
- Page 5 ZINTRA BEAMS CLOSED RAFTER zintraacoustic.com STEP 4 8IN BEAMS CONNECTOR INSTALL STEP 5 FINISING INSTALL PAGE 5...
