Summary of Contents for Rhinomed R3104
- Page 1 HEAVY DUTY AXLE STAND - 6 TONS PN: R3104 RHINOMOTIVE LTD - UK 71-75 Shelton Street, London, United Kingdom Scan QR Code www.rhinomotive.com...
- Page 2 CAPACITY NET WEIGHT LIFTING HEIGHT WORK RANGE R3104 6 TONS 13.2 KG 22.5 CM 38.5 CM - 61.5 CM 1. GENERAL SAFETY INFORMATION • Save these instructions. For your safety, read, understand, and follow the information provided with and on this pair of jack stands before using.
- Page 3 4. WARNING 1. Study, understand, and follow all instructions before operating this device. 2. Do not exceed rated capacity. 3. Use only on hard, level surfaces. 4. Centre load on saddle. 5. Use as a matched pair only. 6. Do not modify the jack stands in any way. Unauthorised modification may impair the function and/or safety and could affect the life of the equipment.
- Page 4 5. ASSEMBLY INSTRUCTIONS 1. Install ratchet bar into frame (fig.1) with ratchet portion of bar aligned with locking pawl (stopper). 2. Move the ratchet bar to its lowest position by raising the locking handle, thereby releasing the stopper, and guiding the bar downward (fig. 2). 3.
- Page 5 9. STORAGE Store stands in upright position and in a clean, dry area. 10. PARTS LIST Description Gear Rack Base Frame Lever Outer Lever Safe Operating Temperature is between 40°F - 105°F (4°C - 41°C) T he manufacturer reserves the rights to make design changes and or improvements to product lines and manuals without notice.
