GLD 55-0511 Manual

Mainstreet 36 inch table soccer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GLD Products
Mainstreet 36 Inch
Table Soccer
Item 55-0511
MAINSTREET 36 INCH
TABLE SOCCER
Replacement Parts
Order direct at
www.gldproducts.com
or call our Customer Service department at
(800) 225-7593
8 am to 4:30 pm Central Standard Time
Item 55-0511
September 2013
UPC Code 7-19265-51170-0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 55-0511 and is the answer not in the manual?

Questions and answers

Summary of Contents for GLD 55-0511

  • Page 1 GLD Products Mainstreet 36 Inch Table Soccer Item 55-0511 MAINSTREET 36 INCH TABLE SOCCER Replacement Parts Order direct at www.gldproducts.com or call our Customer Service department at (800) 225-7593 8 am to 4:30 pm Central Standard Time Item 55-0511 September 2013...
  • Page 2 GLD Products Mainstreet 36 Inch Table Soccer Item 55-0511 Staple your receipt here. Important: A copy of your receipt will be needed to activate your warranty (see page 17)
  • Page 3 Web: www.gldproducts.com This manual may have been updated. For the latest manual visit the GLD products website. Place your package near the location where it will be used. Carefully unpack all components and verify you have all the correct pieces.

  • Page 4: Parts Identifier

    GLD Products Mainstreet 36 Inch Table Soccer Parts Identifier Item 55-0511 Part Part Part Illustration/ Illustration/ Illustration/ No./ No./ No./ Order Number Order Number Order Number Qty. Qty. Qty. Soccer Playfield End Apron Order No. 3-281 Order No. 3-280 Side Apron Order No.
  • Page 5 GLD Products Mainstreet 36 Inch Table Soccer Item 55-0511 Qty. Qty. Qty. End Cap Order No. 3-294 Left Apron Corner Right Apron Corner Order No. 3-295 Order No. 3-296 Qty. Qty. Qty. Soccer Ball 8 x 30 mm Leg Bolt Order No.

  • Page 6: Product Registration

    GLD Products Mainstreet 36 Inch Table Soccer Item 55-0511 IF YOU HAVE A WARRANTY CLAIM, CALL US FIRST Please see page 15. GLD Products Available 8 am to 4:30 pm Central Standard Time S84 W19093 Enterprise Drive Muskego, WI 53150 USA...

  • Page 7: Tools Required

    Unpack the boxes and part bags. Inspect and count the parts. The Parts Identifier page can be used to record your results. • If any parts are damaged or missing contact GLD customer service. • Missing fasteners may be purchased at a hardware store using the descriptions on the Parts Identifier page(s).
  • Page 8 GLD Products Mainstreet 36 Inch Table Soccer Item 55-0511 STEP 1 - ASSEMBLE PLAYER RODS 1. Position a side apron (#1) with the finished edge down. Important: To achive the correct facing direction of the players, first insert the two single player goalie rods (#12 red and #13 blue) into the outer bushings.
  • Page 9 GLD Products Mainstreet 36 Inch Table Soccer Item 55-0511 STEP 2 - ASSEMBLE THE PLAY FIELD 1. Position the soccer playfield (#3) with the graphics down. 2. Slide the soccer playfield (#3) between the two side aprons (#1). The playfield will fit into the slots in the side aprons.
  • Page 10 GLD Products Mainstreet 36 Inch Table Soccer Item 55-0511 STEP 3 - ASSEMBLE THE LEGS Each leg assembly has four main pieces, two legs (#4 left and #5 right) and two leg panels (#6). The leg panels (#6) are all the same. Locate the screw holes that the leg panels (#6) screw into.

  • Page 11: Step 4 - Attach The Legs

    GLD Products Mainstreet 36 Inch Table Soccer Item 55-0511 STEP 4 - ATTACH THE LEGS Both of the leg assemblies are the same. 1. Place the table assembly on the flat floor. The bottom must be facing up. 2. Position a leg assembly so that the bolt holes line up with the table assembly.
  • Page 12 GLD Products Mainstreet 36 Inch Table Soccer Item 55-0511 STEP 5 - TURN BASE OVER The base assembly is ready to be turned over. LIFT THE BASE ASSEMBLY AND TURN IT OVER TO REST ON THE LEGS. DO NOT ROLL THE TABLE OVER. This will place a sideways force on the legs. The legs should be off the floor until the base assembly is rotated completely.
  • Page 13 GLD Products Mainstreet 36 Inch Table Soccer Item 55-0511 STEP 7 - ATTACH HAND GRIPS 1. Place a hand grip (#18) on the ends of the player rods that have two small dimples in the rod. Push from the end to slide it onto the rod. A light soap solution may be used on the end of the player rod to help the hand grip slide.
  • Page 14 GLD Products Mainstreet 36 Inch Table Soccer Item 55-0511 STEP 8 - LEVEL THE TABLE 1. Use a carpenters level and adjust the leg levelers (#17) as needed until the table is level. Only basic leveling is needed as this is a fast game and the ball is always moving.

  • Page 15: Day Limited Warranty

    GLD Products Mainstreet 36 Inch Table Soccer Item 55-0511 90-DAY LIMITED WARRANTY The Manufacturer warrants to the original retail purchaser that this product is free from defects in material and workmanship under normal use and conditions for a period of ninety (90) days from the date of original purchase.
  • Page 16 GLD Products Mainstreet 36 Inch Table Soccer Item 55-0511 This page left intentionally blank. 1-800-225-7593 www.gldproducts.com...
