- Page 1 UFM-SDN Appliance Hardware User Manual P/N: MUA9002F-2SF-250, MUA9002F-2SF-500, MUA9002F-2SF-1K, MUA9002F-2SF-2K, MUA9002F-2SF-4K, MUA9002F-2SF-HA Rev 1.0 www.mellanox.com...
- Page 2 © Copyright 2013. Mellanox Technologies. All Rights Reserved. Mellanox®, Mellanox logo, BridgeX®, ConnectX®, CORE-Direct®, InfiniBridge®, InfiniHost®, InfiniScale®, PhyX®, SwitchX®, UFM®, Virtual Protocol Interconnect® and Voltaire® are registered trademarks of Mellanox Technologies, Ltd. Connect-IB™, FabricIT™, MLNX-OS™, MetroX™, MetroDX™, ScalableHPC™, Unbreakable-Link™ are trademarks of Mellanox Technologies, Ltd.
-
Page 3: Table Of Contents
Field Replaceable Units ..........34 Appendix C Avertissements de sécurité d’installation (French) ......35 Mellanox Technologies... - Page 4 Advertencias de seguridad para la instalación (Spanish) ....42 Appendix F Special Regulations Regarding Finland, Sweden, Denmark, and Norway ..46 Mellanox Technologies...
-
Page 5: List Of Figures
Figure 24: Remove HD ............28 Mellanox Technologies... -
Page 6: List Of Tables
Replacement Parts ............34 Mellanox Technologies... -
Page 7: Revision History
UFM-SDN Appliance Rev 1.0 Revision History Table 1 - Revision History Table Date Revision Description February 2013 Initial Release Mellanox Technologies... -
Page 8: About This Manual
The InfiniBand Architecture Specification that is provided by IBTA InfiniBand Architecture Specifica- tion, Vol. 1, Release 1.2.1 UFM®-SDN Appliance Remote Mgmt This document contains information regarding Mellanox Technologies' remote management for the UFM®-SDN Appliance. This requires a cus- tomer support login. -
Page 9: Conventions
This icon indicates a situation that can potentially cause damage to hardware or soft- ware. BEWARE! This icon indicates a situation that can potentially cause personal injury or damage to hardware or software. Abbreviations Table 3 - Abbreviations Term Description Fourteen Data Rate Mellanox Technologies... -
Page 10: Mellanox Product Legend
Rev 1.0 Mellanox Product Legend The following table identifies the components of the appliance as they correspond to the OPN MUA9002F-2SF-250. Place Field Decoder Mellanox Technologies System Type UFM-SDN Appliance Data Transfer Protocol 9 = VPI Size of box 00 = 1U... -
Page 11: Chapter 1 Overview
The MAC address of the first management interface (eth0) can be found on the pull-tab. eth1-3 have the next consecutive addresses. Figure 1: Pull Out Tab Mellanox Pull out tab Figure 2: Pull Out Tab Mellanox Technologies... -
Page 12: Basic Operation And Installation
UFM-SDM T E C H N O L O G I E S Mellanox Mellanox Mellanox Mellanox Rear side 2.1.1 Status LEDs The System Status Indicators are located on the front side panel. Figure 4: System Status Indicators Mellanox Technologies... -
Page 13: Table 4: Figure 4 Legend
Non-critical error – The appliance is running but in a reduced state. Needs atten- of 1Hz tion. Amber Blinking at a Warning – Impending critical state. Need to attend to this problem before it rate of 1Hz becomes fatal. Amber Fatal Error occurred – non recoverable condition system stopped! Mellanox Technologies... -
Page 14: Figure 5: Ufm-Sdn Appliance Front And Rear Side Panels
PS1. Figure 7: Power Supply Unit Status LEDs Each PS unit has a single 2 color LED on the right side of the PS unit, that indicates the internal status of the unit. Mellanox Technologies... -
Page 15: Figure 8: Identification Led And Identifier Button
2.1.1.3 Appliance Identifier ID LED and Button This appliance has a combination button and ID LED . The LED can be lit by pushing the button or by using the remote management. Figure 8: Identification LED and Identifier Button Mellanox Technologies... -
Page 16: Figure 9: Hard Drive Leds
Power on and Drive spun down Solid On Power on with no drive activity Activity LED Blinking Power on with drive activity or drive spinning up 2.1.1.5 Hard Drive Activity LED This LED indicates activity of the on-board hard disk controllers Mellanox Technologies... -
Page 17: Reset Button
NIC #4 NIC #1 NIC #2 Table 7 - NIC Activity Indications LED Configuration LED Description Physical link down / Default Solid Green Physical link up no traffic Flashing Green Physical link up with traffic Flashing Orange Physical errors Mellanox Technologies... -
Page 18: Air Flow
T E C H N O L O G I E S Mellanox Mellanox Figure 13: Rear Side Interfaces ConnectX-3 Port 1 ConnectX-3 Port 2 USB ports NIC #1 NIC #2 NIC #3 RJ45 Serial A port NIC #4 remote management eth1 eth0 eth2 eth3 Mellanox Technologies... -
Page 19: On/Off Button
Various upload/download operations are also support through the USB using the CLI such • UFM® configuration fetching/uploading • UFM® license fetching • UFM® upgrade All USB connectors can be used for performing software update or various upload/download operations using the CLI. USB 1.0 is not supported. Mellanox Technologies... -
Page 20: Port Interfaces
(French),” on page 35, for German see Section D,“Installation - Sicherheitshinweise (German),” on page 39, and for Spanish see Section E,“Advertencias de seguridad para la instalación (Span- ish),” on page 42. 1. Installation Instructions Read all installation instructions before connecting the equipment to the power source. Mellanox Technologies... - Page 21 8. Equipment Installation This equipment should be installed, replaced, or serviced only by trained and qualified personnel. 9. Equipment Disposal Disposal of this equipment should be in accordance to all national laws and regula- tions. Mellanox Technologies...
- Page 22 According to the WEEE Directive 2002/96/EC, all waste electrical and electronic equipment (EEE) should be collected separately and not disposed of with regular household waste. Dispose of this product and all of its parts in a responsible and environmentally friendly way. Mellanox Technologies...
-
Page 23: Chapter 4 Mechanical Installation
2. Install the two rails into the rack. Make sure they are at the same level. Make sure they have the correct side to the top. The blue pins go into the rack holes. Figure 15: Left-hand Rail Outside View Collapsed Slides for Appliance shelf Right left signage Pins for Rack holes Pins for Rack holes Mellanox Technologies... -
Page 24: Figure 16: Left-Hand Rail Outside View Extended
5. Plug in the power cables. 6. Push the ON/OFF button to start. Figure 19: Turn On Power Button w/Integrated LED 7. Check the Status LEDs and confirm that all of the LEDs show status lights consistent with normal operation. Mellanox Technologies... -
Page 25: Connecting Ufm-Sdn Appliance To Your Network/Fabric
PS units. The power cords should be standard 3-wire AC power cords including a safety ground and rated for 15A or higher. The power supplies deliver 750W AC. Caution: After inserting a power cable and turning on the appliance, confirm the green system status LED light is on. Mellanox Technologies... -
Page 26: Extracting And Inserting The Power Supply Unit
Figure 21: Remove the PSU Handle 2. If a power supply is installed, grab the handle with your thumb pointing toward the latch. Push the latch with your thumb towards the handle while you pull the power supply out of the appliance. Mellanox Technologies... -
Page 27: Installing And Removing Hot-Swap Hard Drive
T E C H N O L O G I E S Mellanox Mellanox Mellanox Mellanox These two drive drawers are populated. Empty drive drawers must be occupied by carriers with plastic drive blank provided to maintain proper system cooling. Mellanox Technologies... -
Page 28: Removing A Hard Disk Drive From A 3.5" Hard Drive Carrier
HDD, this process might take up to 48 hours to complete. Battery Replacement Mellanox Technologies does not support battery replacement. Customer removal of the UFM® cover will void the warrantee. Only Remove the cover to comply with WEEE directives or to dis- assemble for environmentally approved disposal. -
Page 29: Appliance Shut Down Procedure
According to the WEEE Directive 2002/96/EC, all waste electrical and electronic equipment (EEE) should be collected separately and not disposed of with regular household waste. Dispose of this product and all of its parts in a responsible and environmentally friendly way. Mellanox Technologies... -
Page 30: Chapter 5 Troubleshooting
4. If the appliance does not come on, check the power supplies. 5. If the appliance comes on, Use the MLNX-OS management to determine the cause of the Shutdown. 6. Check the temperature. 7. Check the Fan status. The appliance is not working and unresponsive: 1. Reset the appliance. Mellanox Technologies... - Page 31 3. Wait 5 minutes. 4. Plug in the appliance. 5. If the appliance does not come on, check the power supplies. 6. If the appliance comes on, use the MLNX-OS management to determine the cause of the shutdown. Mellanox Technologies...
-
Page 32: Appendix Aufm-Sdn Appliance Specifications
Shock and Vibration: ETSI EN 300 019-2-2: 1999- Operating: 90%, non-condensing at 35°C Vibration/ Humidity Protocol Support InfiniBand: Management: Speed protocol Auto-Negotiation of (56Gb/s, Managed using MLNX-OS 40Gb/s, 20 Gb/s, 10Gb/s) QoS / Management Data Rate: Data Rate 56Gb/s Mellanox Technologies... -
Page 33: Approved Cables
For a list of all approved cables see: http://www.mellanox.com/related-docs/user_manuals/Mellanox_approved_cables.pdf EMC Certifications The list of approved certifications per switch in different regions of the world is located on the Mellanox Website at: http://www.mellanox.com/related-docs/user_manuals/Regulatory_and_Compliance_Guide.pdf EMC statements are also in the Regulatory and Compliance Guide. Mellanox Technologies... -
Page 34: Appendix B Field Replaceable Units
Power Supply with front (hard-drives) side to back (power-supplies) side airflow for Mellanox® UFM-SDN Appliance 1U VPI Server MUA90-HD Hard Drive for Mellanox® UFM-SDN Appliance 1U VPI Server MUA90-SKIT Rack installation kit for Mellanox® UFM-SDN Appliance 1U VPI server standard depth racks Mellanox Technologies... -
Page 35: Appendix C Avertissements De Sécurité D'installation (French)
Les câbles InfiniBand en cuivre sont lourds et ne sont pas flexibles, il faut donc faire très attention en les branchant et en les débranchant des connecteurs. Consultez le fab- ricant des câbles pour connaître les mises en garde et les instructions spéciales. Mellanox Technologies... - Page 36 Ce matériel ne doit être installé, remplacé ou entretenu que par du personnel formé et qualifié. 15. Elimination du matériel L’élimination de ce matériel doit s’effectuer dans le respect de toutes les législations et réglementations nationales en vigueur. Mellanox Technologies...
- Page 37 250 V et d’une intensité nominale de 10 A. 21. Bodily Injury Due to Weight <40 lbs 70 - 121 lbs >121 lbs 40 - 70 lbs <18 kgs 32 - 55 kgs >55 kgs 18 - 32 kgs Mellanox Technologies...
- Page 38 Caution: Slide/rail mounted equipment is not to be used as a shelf or a work space. The rails are not intended for sliding the unit away from the rack. It is for permanent instal- lation at final resting place only, not used for service and maintenance. Mellanox Technologies...
- Page 39 Um alle Einhieten spannungsfrei zu machen sind die Netzstecker aller Netz- teile zu entfernen Risk of electric shock and energy hazard. The PSUs are all independent. Disconnect all power supplies to ensure a powered down state inside of the UFM® platform. Mellanox Technologies...
- Page 40 3 - Leiter, mindestens 1,00 mm2 Draht, bewertet mit 300 V, mit einem PVC-Mantel isoliert. Das Kabel muss eine angespritztem Stecker bewertet bei 250 V, 10 A. " 14. Ableitstrom> 3.5mA LEAKAGE >3.5mA WARNUNG: Hohe Ableitstrom; Earth Verbindung, bevor Sie die Verbindung von wesentlicher Bedeutung werden. Mellanox Technologies...
- Page 41 Caution: Slide/rail mounted equipment is not to be used as a shelf or a work space. The rails are not intended for sliding the unit away from the rack. It is for permanent instal- lation at final resting place only, not used for service and maintenance. Mellanox Technologies...
- Page 42 8 cm (3 pulgadas) alrededor de las aberturas de ventilación. 6. Apilamiento del chasis Los chasis no se deben apilar sobre otros equipos. La caída del chasis podría causar lesiones corporales, así como daños al equipo. Mellanox Technologies...
- Page 43 13. Eliminación de equipos La eliminación definitiva de este equipo se debe efectuar conforme a todas las leyes y reglamentaciones nacionales. 14. Códigos eléctricos locales y nacionales Este equipo se debe instalar conforme a los códigos eléctricos locales y nacio- nales. Mellanox Technologies...
- Page 44 UL tipo DP-1 o DP-2. (Nota: cuando residen en circuito no de tipo LPS) Protección contra sobrecargas: Al cableado del edificio se debe incorporar un disposi- tivo de protección contra sobrecargas de circuito derivado, de fácil acceso, con una corriente nominal de 20 A. Mellanox Technologies...
- Page 45 Caution: Slide/rail mounted equipment is not to be used as a shelf or a work space. The rails are not intended for sliding the unit away from the rack. It is for permanent instal- lation at final resting place only, not used for service and maintenance. Mellanox Technologies...
- Page 46 Do not connect this unit to any outlet that is not fully grounded! • Finland - “Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan” • Norway - “Apparatet må tilkoples jordet stikkontakt” Unit is intended for connection to IT power systems for Norway only. • Sweden “Apparaten skall anslutas till jordat uttag.” Mellanox Technologies...
