Magneplanar CC (Center Channel) Speaker Stand
Table of Contents
1. General Description
2. Carton Contents
3. Packaging
General Description
The Magneplanar CC Speaker Stand is both a speaker stand and a midbass/bass woofer to augment the low
frequencies for Magneplanar center channel speakers. An internal crossover has a high pass filter for the Magneplanar
center channel speaker. The woofer section of the CC Speaker Stand uses the same DiPlanar technology as the MG
20.1 bass driver.
Carton Contents
1- Magneplanar CC Speaker Stand
3- 1/4-20x1 inch Phillips screws
4- 10-24x1-3/4 inch Foot bolts
1- 2 ohm resistor
1- Allen wrench
1- Speaker logo
1- Owner's manual
1- Magnepan shaped pink noise test CD
Packaging
Save all packaging. If you need to transport the speakers, they can be shipped safely only in the original packaging. You
may never have to return your loudspeakers, but should the occasion arise, they should not be shipped in any
packaging but the original. Should you discard it, packaging is available.
Advertisement
Table of Contents
Summary of Contents for MAGNEPLANAR CC
- Page 1 The Magneplanar CC Speaker Stand is both a speaker stand and a midbass/bass woofer to augment the low frequencies for Magneplanar center channel speakers. An internal crossover has a high pass filter for the Magneplanar center channel speaker. The woofer section of the CC Speaker Stand uses the same DiPlanar technology as the MG 20.1 bass driver.
- Page 2 Installation and Adjustments 1. Install the feet on the CC Speaker Stand as shown in Fig. 1. Fig. 1...
- Page 3 2. Using the 3 Phillips screws supplied, install your Magneplanar center channel speaker on the CC Speaker Stand as shown in Fig. 2. Fig. 2...
- Page 4 1. Connect your amplifier to the input at the bottom of the CC Speaker Stand (observing polarity). 2. Using a short section of speaker wire, connect from the CC Speaker Stand output at the top of the CC Speaker Stand to your Magneplanar center channel speaker (observing polarity).
- Page 5 Service and Shipping In the unlikely event you need service for your CC Speaker Stand, we recommend you return it through your dealer. They are experienced in providing service and can assist you if the speaker must be returned to the factory. If you...
- Page 6 Specifications System Description: Planar-magnetic, DiPlanar woofer and center channel speaker stand. Frequency Response: 50 Hz-5 kHz (wide-band response) Recommended Power: See F.A.Q. on web site www.magnepan.com Sensitivity: _____dB @2.83V/1 Meter/50 Hz Impedance: 4 Ohms Dimensions: Warranty: Limited 3-year to original owner Shipping Weight: ___ lbs.
