WEST USB Communication Hardware Setup Guide
Purpose:
This guide provides setup and user instructions for the WEST communication hardware. This hardware
is to be used by Westport LNG System qualified technicians to connect a service laptop, loaded with
Westport proprietary WEST diagnostic software, to a Westport powerwed LNG Truck for diagnostic
purposes.
The communication hardware is to be used with WEST software to diagnose the Westport LNG
system and related engine parameters only. For all other engine or vehicle performance
parameters, use base engine manufacturer recommended diagnostic software, procedures, and
Special Tools and Materials Required:
The WEST USB communication hardware kit (P/N 10015993S) includes the following components
(refer to Figure 1 for callouts):
•
1x CAN harness
•
1x CAN to USB converter
•
1x Westport HD carrying case
•
1x User instructions (this guide) (D)
A
Stage 1: Driver Installation
Before using the WEST USB communication hardware, the WEST software, as well as communication
drivers, must be installed on the computer to be used with the hardware. First, refer to the WEST User
service.westport-hd.com
Copyright © 2010-2012 Westport Power Inc. All rights reserved
WEST USB Communication Hardware Setup Guide
NOTE
tools.
(A)
(B)
(C)
B
Figure 1: WEST USB communication hardware
GX & LNG SYSTEM
D
INS NO.
INS-10017744
C
REV DATE PAGE
01 16-03-12 1 of 9
