3. TECHNICAL SPECIFICATIONS

11
10
9
8

3.1. General appearance

1. Upper basket with racks
2. Upper spray arm
3. Lower basket
4. Lower spray arm
5. Filters
6. Rating plate
7. Control panel
8. Detergent and rinse-aid dispenser
9. Salt dispenser
10. Upper basket track latch
11. Upper Cutlery Basket
12. Turbo Drying Unit: This system provides
better drying performance.
1
2
3
4
5
12
3.2. Technical specifications
Capacity
Dimensions
Height
6
Width
7
Depth
Net Weight
(kg)
Operating
voltage (V)
/ frequency
(Hz)
Total current
(A)
Total Power
(W)
Water
supply
pressure
(Mpa)
EN - 8
10 place
settings
820-870(mm)
550(mm)
598(mm)
32 kg
220-240
V 50 Hz,
10(A)
1900(W)
Maximum:
1 (Mpa)
Minimum:
0.03 (Mpa)
