- Page 1 Tally System Gen. 2 O P E R A T I N G M AN U A L 01.01.2023...
-
Page 2: Disclaimer
In no event shall ARRI or its subsidiaries be liable for or have a remedy for recovery of any special, direct, indirect, incidental, or consequential damages, including, but not limited to lost profits, lost savings, lost... -
Page 3: Imprint
The information and intellectual property contained herein is confidential between ARRI and the client and remains the exclusive property of ARRI. If you find any problems in the documentation, please report them to us in writing. ARRI does not warrant that this document is flawless. -
Page 4: Table Of Contents
Mounting the Tally Client module................... 18 Wiring ARTEMIS......................19 Wiring TRINITY 2......................21 Wiring TRINITY Live / TRINITY Gen. 1................. 22 Wiring CCP-Live......................25 Wiring Camera........................ 25 Pinout..........................27 Cleaning and Repair.......................28 Cleaning Instructions...................... 28 Repair..........................28 Transportation and Storage...................29 Disposal........................... 30 ARRI Service Contacts....................31... -
Page 5: About This Document
Our Advanced Service Training courses are designed to transfer detailed knowledge about how to service and repair all types of ARRI products and give you permanent access to detailed Service instructions, special tools and spare-parts. To learn more, please visit... -
Page 6: Intended Use
Only use the Tally System Gen. 2 as described in the Operation Manual and User Manual. Any other use is considered improper and can result in property damage. ARRI assumes no liability for damages or changes that are caused by improper use. -
Page 7: About This Product
No matter it is in the studio or the OB vehicle system, the tally system is a very important component. How does it work? The ARRI Tally System Gen. 2 contains a so-called Host module, which normally mounted onto the 15mm rods and is thus located under the lens, and the so-called Client module, which is mounted on top of the operator's monitor. -
Page 8: Dimensional Drawing
76 g / 0.17 lb Client Module 81 g / 0.18 lb Environmental Conditions The Tally System Gen. 2 should only be used and stored under certain environmental conditions. Check the following conditions before commissioning and operation: Electrical Requirements Input voltage: 28 V DC Operating Temperature -20°... -
Page 9: Scope Of Delivery
The packaging consists of recyclable materials. For the sake of the environment, dispose the packaging material at a suitable disposal site only. Always store, ship and dispose according to local regulations. ARRI is not liable for consequences from inadequate storage, shipment or disposal. - Page 10 About this product TRINITY 2 Tally Set for TRINITY Gen.2, 3pin Fischer K0.0044678 K2.0044490 Tally System Gen.2 / Host Tally System Gen.2 / Client K2.0044491 K2.0010482 Tally Sensor Cable, Gen. 1 & 2 Tally Gen. 2 Pwr, TST-2, Fischer 3pin to Lemo 0S 3pin, 0,35m / 13.7in K2.0044143 Tally Gen.
-
Page 11: Declaration Of Conformity
Declaration of Conformity Approval Information The TALLY System Gen. 2 is approved for use in countries where the CE or FCC declaration is accepted. That contains the European Union, Canada, Japan and the USA. The import and use in other countries may be subject to legal, official or regulatory requirements and regulations. It is the... - Page 12 About this product FCC Class A Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 13: Safety Instructions
Safety Instructions Safety Instructions This safety information is in addition to the product specific operating instructions in general and must be strictly observed for safety reasons. Read and understand all safety and operating instructions before you operate or install the system. Retain all safety and operating instructions for future reference. -
Page 14: Safety Instructions
When connecting and disconnecting the system components and cables, there is a risk of crushing fingers and hands. Use only accessories approved by ARRI. The use of accessories not approved by ARRI is at your own risk. Please observe all relevant safety guidelines. -
Page 15: Installation And Operation
Installation and Operation Installation and Operation Installing the Tally Sensor Tally Sensor In standard use, the Tally Host module is triggered by a photocell. The photocell is located in the top module of the Tally Sensor Cable (K2.0010482). Placing the Tally Sensor Place the tally sensor cable directly onto one of the available Tally LEDs of the camera or viewfinder. -
Page 16: Mounting The Tally Host Module
Installation and Operation Mounting the Tally Host Module SAM Plates To place the tally host module under the lens on an ARTEMIS 2 or TRINITY (Gen. 1 & 2) combine the components as shown. NOTE With an artemis Gen. 1, the setup is basically identical. Only another dovetail plate and other lightweight support are used. - Page 17 Installation and Operation SSB-1 / SSB-4 To place the tally host module over the lens on a TRINITY 2 or TRINITY Gen. 1 combine the components as shown. NOTE For TRINITY 2 you will need SSB-4 (K2.0044225). For TRINITY Gen. 1 you will need SSB-1 (K2.0035956).
-
Page 18: Mounting The Tally Client Module
Installation and Operation Mounting the Tally Client module ARTEMIS Monitor Use 3M™ Dual Lock™ Reclosable Fasteners SJ3550CF to place the Tally Client module on top of the monitor. TRINITY Monitor Use 3M™ Dual Lock™ Reclosable Fasteners SJ3550CF to place the Tally Client module on top of the monitor. -
Page 19: Wiring Artemis
Installation and Operation Wiring ARTEMIS Tally Host Module (ARTEMIS 2 & 1) - Page 20 Installation and Operation Tally Client Module (ARTEMIS 2 & 1)
-
Page 21: Wiring Trinity 2
Installation and Operation Wiring TRINITY 2 Tally Host Module (TRINITY 2) -
Page 22: Wiring Trinity Live / Trinity Gen. 1
Any TRINITY Gen. 1 upgraded to a TRINITY Live system can communicate with the TALLY System Gen. 2. The classic TRINITY Gen. 1 must be brought to your local ARRI service to be converted to operate with the TALLY System Gen. 2. - Page 23 Installation and Operation...
- Page 24 Installation and Operation Tally Client Module...
-
Page 25: Wiring Ccp-Live
Since there are many different sockets with different pin outs, ARRI does not offer these special cables. However, they can be produced by the respective technician in the studio or OBI Van on request. To activate the ARRI Tally System Gen. 2, the camera's tally signal must be switched to ground. - Page 26 Installation and Operation...
-
Page 27: Pinout
Installation and Operation Pinout Tally Gen. 2 Host Module Interfaces Sensor In 4pin Lemo / ---- Power In / Tally Out 3pin Lemo / 12V max. 300mA Tally Gen. 2 Client Module Interfaces Power In / Tally In 3pin Lemo / 12V max. 2A Monitor Power Out 2x 2pin Lemo / 12V max. -
Page 28: Cleaning And Repair
Repairs carried out by Untrained Personnel Risk of injury and damage. Do not try to repair the device yourself. Repairs may only be carried out by authorized ARRI service partners. For repairs and maintenance work on the TALLY System Gen. 2, please contact "ARRI... -
Page 29: Transportation And Storage
Follow the specified environmental conditions. Do not store the accessories in places where they may be subject to temperature extremes, direct sunlight, high humidity, severe vibration or strong magnetic fields. If you have any questions regarding the transport or storage of ARRI products, please contact "ARRI Service". -
Page 30: Disposal
Disposal Disposal ATTENTION The product can be returned to the manufacturer Arnold & Richter Cine Technik GmbH & Co. Betriebs KG. This product falls within the scope of Directive 2012/19 / EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of June 4, 2012 on waste electrical and elec- tronic equipment (WEEE II). -
Page 31: Arri Service Contacts
