P a r t i c l e I n s t r u m e n t s
Model 3075/3076
Constant Output Atomizer
Instruction Manual
P/N 1933076, Revision H
October 2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3075 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TSI Instruments 3075

Summary of Contents for TSI Instruments 3075

  • Page 1 P a r t i c l e I n s t r u m e n t s Model 3075/3076 Constant Output Atomizer Instruction Manual P/N 1933076, Revision H October 2002...
  • Page 3 Product Overview Unpacking the Model 3075/3076 Atomizer Constant Output Atomizer Setting Up the Atomizer Instruction Manual Operating the Atomizer Atomizer Applications Atomizer Maintenance and Service Appendixes...
  • Page 4 M a n u a l H i s t o r y The following is a manual history of the Model 3075/3076 Constant Output Atomizer Instruction Manual (Part Number 1933076). Revision Date First Version March 1989 June 1993 January 1994...
  • Page 5 Part Number 1933076 / Revision H / October 2002 Copyright ©TSI Incorporated /1986–2002 / All rights reserved. Address TSI Incorporated / 500 Cardigan Road / St. Paul, MN 55126 / USA Fax No. (651) 490-3824 E-mail Address particle@tsi.com Limitation of Warranty Seller warrants the goods sold hereunder, under normal use and service as and Liability described in the operator's manual, shall be free from defects in workmanship and...
  • Page 6 Model 3075/3076 Constant Output Atomizer...
  • Page 7 This section gives instructions to promote safe and proper handling of the Model 3075/3076 Constant Output Atomizer. The Model 3075/3076 Constant Output Atomizer is designed to release aerosol to a system that is at atmospheric pressure. Therefore, the pressure at the outlet of the Atomizer should be maintained close to atmospheric pressure (below 10 psig).
  • Page 8 Model 3075/3076 Constant Output Atomizer...

  • Page 9: Table Of Contents

    Setting Up the Model 3075 Atomizer ........3-5 Before You Begin ............3-5 Setting Up in the Nonrecirculation Mode ....... 3-6 Modifying the Model 3075 for use in the Recirculation Mode ................3-8 Operating the Atomizer ........... 4-1 Operating in the Recirculating Mode ........4-1 Operating in the Nonrecirculating Mode ......
  • Page 10 3-1 Model 3076 Atomizer in the Recirculation Mode ....3-3 3-2 Model 3076 Atomizer Modified for the Nonrecirculation Mode............. 3-5 3-3 Model 3075 Atomizer in the Nonrecirculation Mode ... 3-7 4-1 Model 3062 Diffusion Dryer ..........4-4 5-1 Particle Diameter Mean, Mode and Standard Deviation vs.
  • Page 11 5-8 Output of the Electrical Aerosol Detector With Damping . 5-10 6-1 Atomizer Assembly ............6-2 T a b l e s 2-1 Model 3075/3076 Atomizer Accessory Kit......2-1 A-1 Specifications of the Model 3075/3076 Constant Output Atomizer ................A-1 Contents...
  • Page 12 Model 3075/3076 Constant Output Atomizer...

  • Page 13: About This Manual

    O r g a n i z a t i o n The following is a guide to the organization of this manual: Chapter 1: Product Overview This chapter introduces the Model 3075/3076 Constant Output Atomizer, gives a list of features, and provides a brief operating description of the instrument.

  • Page 14: Related Product Literature

    Model 3074 Filtered Air Supply (part number 1933074) TSI Incorporated This manual contains setup and operating instructions for a filtered air supply, which can be used with the Model 3075/3076 Constant Output Atomizer. Model 3012 Aerosol Neutralizer (part number 1933012) TSI...

  • Page 15: Getting Help

    G e t t i n g H e l p To obtain assistance with the Model 3075/3076 Constant Output Atomizer, either refer to Chapter 6, “Atomizer Maintenance and Service,” or contact Customer Service: TSI Incorporated 500 Cardigan Road St. Paul, MN 55126 USA...

  • Page 17: Chapter S

    C H A P T E R 1 P r o d u c t O v e r v i e w This chapter introduces the Model 3075/3076 Constant Output Atomizer, gives a list of features, and provides a brief operating description of the instrument.

  • Page 18: How The Atomizer Works

    The Atomizer comes in two models: Model 3075 and Model 3076. Model 3075 is equipped with a syringe pump for operation in the nonrecirculation mode; the Model 3076, used as a conventional recirculation atomizer, does not have a syringe pump. Either model can be modified to work in either mode.

  • Page 19: Model 3075/3076 Schematic

    Aerosol Out 0.0135 Dia. Hole in 3/8 Dia. Disc. Compressed Air In O-Ring Liquid In Excess Liquid to Closed Reservoir Figure 1-2 Model 3075/3076 Schematic Product Overview...
  • Page 20 See Chapter 3 for instructions on setting up the Atomizer in recirculation and nonrecirculation modes. The Model 3075 Atomizer syringe pump has 30 gear positions. If you ordered a Model 3075, see the manufacturer’s instruction sheet for operating instructions for the pump.

  • Page 21: Unpacking The Atomizer

    U n p a c k i n g L i s t The contents of the Atomizer’s accessory kit depends on the model you purchased: Model 3075 or 3076. Compare the equipment you received to the items listed in Table 2-1.

  • Page 22: Unpacking Instructions

    U n p a c k i n g I n s t r u c t i o n s The Model 3075/3076 Constant Output Atomizer is shipped with protective coverings on the inlets and outlets. If anything is missing...

  • Page 23: Setting Up The Atomizer

    M e e t i n g C l e a n A i r R e q u i r e m e n t s The Model 3075/3076 Atomizer requires a source of clean, dry air at a flow of at least 3.5 standard liters per minute (SLPM) at no more than 240 kilopascals gauge [35 psig].

  • Page 24: Selecting And Preparing The Solution

    Setting Up in the Recirculation Mode In the recirculation mode, the 1-liter bottle (with black plastic cap) acts as the reservoir for the solution. Model 3075/3076 Constant Output Atomizer...

  • Page 25: Model 3076 Atomizer In The Recirculation Mode

    The 1-liter bottle is pre-assembled for use in the recirculation mode. The cap has two fittings: one delivers solution to the atomizer block, the other returns excess solution to the bottle from the Atomizer. The smaller fitting has a hose barb on the outside; on the inside, this fitting is soldered to a stainless steel tube that protrudes into the bottle.

  • Page 26: Modifying The Model 3076 For Use In Nonrecirculation Mode

    ⁄ combine a -inch MPT and a -inch FPT elbow fitting along with ⁄ -inch MPT and a ¼-inch TU Swagelok connector. ® Swagelok is a registered trademark of SWAGELOK Quick-Connect Co., Hudson, OH 44236 Model 3075/3076 Constant Output Atomizer...

  • Page 27: Setting Up The Model 3075 Atomizer

    S e t t i n g U p t h e M o d e l 3 0 7 5 A t o m i z e r Use the information in this section to set up the Model 3075 with a syringe pump in the nonrecirculation mode.

  • Page 28: Setting Up In The Nonrecirculation Mode

    Atomizer (side port of the Swagelok tee). This line equalizes the pressure between the Atomizer and the bottle and thus allows the excess liquid to drain into the bottle. The Swagelok plug is not needed in this mode. Model 3075/3076 Constant Output Atomizer...

  • Page 29: Model 3075 Atomizer In The Nonrecirculation Mode

    High Efficiency Filter Air Dryer Pressure Regulator Atomizer Assembly Pressure Relief Excess Liquid Drain Off Valve Compressed Air Supply Model 3074 Filtered Air Supply Liquid Feed Syringe Pump Figure 3-3 Model 3075 Atomizer in the Nonrecirculation Mode Setting Up the Atomizer...

  • Page 30: Modifying The Model 3075 For Use In The Recirculation Mode

    Modifying the Model 3075 for use in the Recirculation Mode In recirculation mode the syringe pump is not used. The 1-liter bottle acts as a reservoir for solution. This bottle comes pre- assembled for use in the recirculation mode and needs no modifications.

  • Page 31: Operating The Atomizer

    O p e r a t i n g t h e A t o m i z e r Use the information in this chapter to operate the Model 3075/3076 Constant Output Atomizer. This chapter contains information on the following:...

  • Page 32: Operating In The Nonrecirculating Mode

    Atomizer assembly. Then switch to gear position no. 14. 4. The generator is now in operation. Its operation will be stable until the solution in the syringe runs out. Model 3075/3076 Constant Output Atomizer...

  • Page 33: Drying The Aerosol

    5. To change the aerosol particle size, use a solution of different concentration. Flush the Atomizer with about 25 cubic centimeters of solvent and then refill the syringe with the new solution. (A thorough cleaning—which means disassembling the Atomizer—is usually unnecessary unless you change from a high-solute concentration to a low-solute concentration.) Prepare the Atomizer for operation as done in step 3.

  • Page 34: Neutralizing The Aerosol

    A neutralizer operates most effectively on dry particles. The Atomizer may be used to atomize most solutions or suspensions. A few common applications of the Atomizer are described in Chapter 5 of this manual. Model 3075/3076 Constant Output Atomizer...

  • Page 35: Atomizer Applications

    C H A P T E R 5 A t o m i z e r A p p l i c a t i o n s This chapter contains applications for the Model 3075/3076 Constant Output Atomizer. G e n e r a t i n g S o l i d P a r t i c l e s Materials such as sodium chloride, sugar, uranine, and methylene sucrose are commonly used to generate solid particles.

  • Page 36: Size Distribution Of Sodium Chloride Aerosols Generated By The Atomizer

    Size Distribution of NaCl Aerosols 3.5E+06 3.0E+06 2.5E+06 .012 g/cc .0012 g/cc 2.0E+06 .0001 g/cc 1.5E+06 1.0E+06 5.0E+05 0.0E+00 1000 Particle Diameter (nm) Figure 5-2 Size Distribution of Sodium Chloride Aerosols Generated by the Atomizer Model 3075/3076 Constant Output Atomizer...

  • Page 37: Typical Number Distribution Of A Sodium Chloride

    Figure 5-3 Typical Number Distribution of a Sodium Chloride Aerosol Atomized from 0.001 gram/cm Solution Atomizer Applications...

  • Page 38: Typical Surface Area Distribution Of A Sodium Chloride

    Figure 5-4 Typical Surface Area Distribution of a Sodium Chloride Aerosol Atomized from 0.001 gram/cm Solution Model 3075/3076 Constant Output Atomizer...

  • Page 39: Typical Volume Distribution Of A Sodium Chloride Aerosol Atomized From 0.001 Gram/Cm Solution

    Figure 5-5 Typical Volume Distribution of a Sodium Chloride Aerosol Atomized from 0.001 gram/cm Solution It should be emphasized that the aerosol coming out of the Atomizer is wet and has a high electrostatic charge. Until the particles are completely dry, the particle size changes. A diffusion dryer, discussed in Chapter 4, is highly recommended.

  • Page 40: Generating Oil Aerosol

    D i s p e r s i n g S o l i d P a r t i c l e s Nonsoluble submicron particles, such as carbon black, have been successfully dispersed using this Atomizer [6]. The complete configuration is shown in Figure 5-6. Model 3075/3076 Constant Output Atomizer...

  • Page 41: Using The Atomizer To Generate Carbon Black Aerosol

    Electrostatic Diffusion Charge Dryer Neutralizer Constant Output Carbon Atomizer Black Aerosol Clean, Dry Compressed Liquid Sonic Atomization Probe Excess Liquid Suspension Reservoir (100–500 cm Container) Figure 5-6 Using the Atomizer to Generate Carbon Black Aerosol ⁄ The suspension is aspirated through the -inch-diameter tube from an open reservoir and excess suspension is returned to the same reservoir.
  • Page 42 Then, in Figure 5-8, the output aerosol was fed through the 1-liter bottle and through an evaporation/condensation aerosol conditioner. The system was allowed sufficient time (about 1 hour) to reach equilibrium. Model 3075/3076 Constant Output Atomizer...

  • Page 43: Output Of The Electrical Aerosol Detector Without Damping

    Figure 5-7 Output of the Electrical Aerosol Detector Without Damping Figure 5-8 shows the output of the electrical aerosol detector under these improved conditions. Atomizer Applications...

  • Page 44: Output Of The Electrical Aerosol Detector With Damping

    Figure 5-8 Output of the Electrical Aerosol Detector With Damping 5-10 Model 3075/3076 Constant Output Atomizer...

  • Page 45: Atomizer Maintenance And Service

    A t o m i z e r M a i n t e n a n c e a n d S e r v i c e Use the information to maintain the Model 3075/3076 Constant Output Atomizer and to contact TSI Incorporated for service.

  • Page 46: Atomizer Assembly

    Fitting, Union Tee (1601593) Fitting (1601592) Fitting Adapter (1601594) Fitting, Modified (1601542) O-Ring Nozzle Base (2501010) (2401034) Nozzle, Plate (2401036) Fitting (1601510) Fitting, Tube (1601830) Figure 6-1 Atomizer Assembly Model 3075/3076 Constant Output Atomizer...

  • Page 47: Servicing The Atomizer

    S e r v i c i n g t h e A t o m i z e r Use the information in this section to contact technical personnel at TSI or to return the Atomizer for service. Technical Contacts If you have any difficulty setting up the Atomizer, if you need to replace the 1-liter bottle, or if you have technical or application questions about this instrument, contact an applications...
  • Page 48 Model 3075/3076 Constant Output Atomizer...

  • Page 49: Specifications Of The Model 3075/3076 Constant Output Atomizer

    The following specifications—which are subject to change—describe the most important data of the major components. Table A-1 Specifications of the Model 3075/3076 Constant Output Atomizer Number mean droplet diameter . 0.30 µm DOP; 0.35 µm water Max PSL size ......
  • Page 50 Model 3075/3076 Constant Output Atomizer...
  • Page 51 A P P E N D I X B T e c h n i c a l P a p e r This appendix contains a technical paper by Liu and Lee.
  • Page 52 Model 3075/3076 Constant Output Atomizer...
  • Page 53 Technical Paper...
  • Page 54 Model 3075/3076 Constant Output Atomizer...
  • Page 55 Technical Paper...
  • Page 56 Model 3075/3076 Constant Output Atomizer...
  • Page 57 Technical Paper...
  • Page 58 Model 3075/3076 Constant Output Atomizer...
  • Page 59 A P P E N D I X C B i b l i o g r a p h y The following articles or books are cited in the text of the manual. 1. Liu, B.Y.H., and K.W. Lee (1975) “An Aerosol Generator of High Stability”...
  • Page 60 Model 3075/3076 Constant Output Atomizer...
  • Page 61 500 Cardigan Road St. Paul, MN 55126 U.S.A. Fax: (651) 490-3824 E-mail Address: particle@tsi.com Manual Title: Model 3075/3076 Constant Output Atomizer P/N: 1933076 Rev.: H 1. Was the manual easy to understand and use? Please identify any problem area(s) ___________________________________________________________...
  • Page 63 TSI Incorporated 500 Cardigan Road, Shoreview, MN 55126 U.S.A. Web: www.tsi.com...
