SilverWolf TEEKON AC-PM MOTOR 12HP Installation And Service Manual

Ac golf car speed & range enhancement kit

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

AC GOLF CAR SPEED & RANGE

ENHANCEMENT KIT

INSTALLATION

AND SERVICE

MANUAL

FITS:

Curtis Controller 1510/1515

ClubCar

Precedent

2004 TO PRESENT

Part # PK-000012-CC

* Sold Separately

*2 Ga AC Power Cables – Required

for speeds greater than 19 MPH

www.silverwolfmotors.com

Onward

™

Get the SilverWolf

™

*Smartphone

not included

App at;

™

PART # 05-000100 V2.0CC

Table of Contents

Need help?

Do you have a question about the TEEKON AC-PM MOTOR 12HP and is the answer not in the manual?

Questions and answers

Summary of Contents for SilverWolf TEEKON AC-PM MOTOR 12HP

Page 1 2004 TO PRESENT Part # PK-000012-CC * Sold Separately *2 Ga AC Power Cables – Required for speeds greater than 19 MPH Get the SilverWolf App at; ™ PART # 05-000100 V2.0CC www.silverwolfmotors.com © 2021 SilverWolf Vehicles Inc. All rights reserved.
Page 3: Table Of Contents
Controller & Module Overview ..........................................8 INSTALLATION INSTRUCTIONS- CLUB CAR PRECEDENT -ONWARD 48V ..................9 ® ® ® SILVERWOLF APP SETUP & FEATURES ............................15 ™ Features (Home Screen) ............................................16 Vehicle Setup ................................................17 Pre-Set Vehicle Modes ..............................................18 Advanced Settings ..............................................18 Display Settings................................................19 On-The-Fly Regen Braking ............................................20...
Page 4: Introduction
Vehicles Inc. assumes no responsibility for errors or omissions in this manual, in regards to liability or damages resulting from ™ the use of information contained in the manual. If it is lost or damaged please contact your local dealer or SilverWolf Vehicles Inc..
Page 5: Made In Canada
• Keep the controller and the area around it clean and free of debris. • Do Not submerge the Controller or it’s Parts. • Vehicle and all parts must be serviced by qualified service personnel. For an authorized service location call 1-888-398-7078 or email support@silverwolfmotors.com call SilverWolf Vehicles Inc. www.silverwolfmotors.com ™...
Page 6: Parts List
PARTS LIST - Club Car Precedent ® ™ Confirm that all parts listed below are with your kit before starting installation. AC-PM MOTOR If you are missing parts please contact your local dealer or SilverWolf Vehicles Inc. ™ TECHNOLOGY BY ACCELERATED SYSTEMS INC SILV...
Page 7 Main Positive Cable (from Battery + to Solenoid)- Red (30”) 40-000531 Main Negative Cable (from Battery - to Controller) - Black (24”) 40-000532 Positive Power Cable (from Solenoid to + on Controller)- Red (16”) 40-000534 SilverWolf Vehicles Inc. www.silverwolfmotors.com ™...
Page 8: Installation Instructions -Club Car ® Precedent ® -Onward
SILV MADE IN CANADA THE VEHICLE AND/OR CAUSE SERIOUS INJURY OR DEATH! Cable is on the Positive Controller Post Installation or Servicing of the SilverWolf TEEKON Systems Must be done by a Trained Golf Car ™ Technician. CHECK Before installing or servicing READ THE FOLLOWING:...
Page 9: Controller & Module Overview
ACCELERATED SYSTEMS INC SILV MADE IN CANADA Vehicle Smart Module Connector Plug Location Vehicle 16 Pin Vehicle Harness Connector 2-3 4WD 8 Pin SilverWolf 4WD System (optional) ™ To SilverWolf ™ Controller Controller Wiring Locations STATUS LIGHT SilverWolf Vehicles Inc. www.silverwolfmotors.com ™...
Page 10: Installation Instructions- Club Car ® Precedent ® -Onward ® 48V
TECHNOLOGY BY ACCELERATED SYSTEMS INC SILV MADE IN CANADA The installation of the Silverwolf TEEKON Kit is done from the Battery Compartment; with the 2 middle Batteries removed to allow access ™ to the Controller Panel. The Cover at the rear of the Cart will also need to be removed to access the Motor. DO NOT remove the Rear black plastic Controller Cover located in front off the Motor.
Page 11 2. Note: Before Sliding the Motor into place mark 2 of the bolt holes with a Dry Erase Marker. This will help align the Motor Bolt Holes. Slide the Silverwolf High Power Club Car Motor (10 Spline) on to the Shaft of the Transaxle and align it as shown in the photo below.
Page 12 WASHER Bottom! WASHER DO NOT OVER TIGHTEN! DO NOT OVER TIGHTEN! V = YELLOW W = BLUE CONTROLLER HARDWARE MUST BE INSTALLED IN THE ORDER SHOWN! CONTROLLER HARDWARE MUST BE INSTALLED IN THE ORDER SHOWN! SilverWolf Vehicles Inc. www.silverwolfmotors.com ™...
Page 13 Cables to allow air flow and for some movement. Bolts with a Torque Wrench to 53in-lbs/6 Nm Wire Terminal DO NOT Must Always be OVER TIGHTEN! FLAT WASHER on the Bottom! CONTROLLER HARDWARE MUST BE INSTALLED IN THE ORDER SHOWN! SilverWolf Vehicles Inc. www.silverwolfmotors.com ™...
Page 14 Cart check that the Cables going from the Motor into the Controller Area are secured against the side of the Vehicle. Leave the Zip Ties slightly loose so there is space between the Cables to allow air flow and for some movement. SilverWolf Vehicles Inc. www.silverwolfmotors.com ™...
Page 15 Bottom! CONTROLLER HARDWARE MUST BE INSTALLED IN THE ORDER SHOWN! Note: After the initial test the Vehicle can be taken off the Jack Stands for a final test and to set up the SilverWolf Smart Phone App. ™...
Page 16: Silverwolf ™ App Setup & Features
SETUP AC-PM MOTOR 1. Go to the Apple App Store or the Google TECHNOLOGY BY ™ ™ ACCELERATED SYSTEMS INC Play Store. To download the SilverWolf ™ SILV MADE IN CANADA Smartphone App. Get the SilverWolf App at; ™ Select “New User to setup your User Credentials and register the TEEKON kit for easy updates and warranty.
Page 17: Features (Home Screen)
Device and when it is in range. The Backup Buzzer will also engage: 2 Beeps = Connected and 1 Long Beep = Disconnected Simulation Mode: This is a demonstrations tool to show how the Silverwolf Smart Phone App works. Changes made are not live and ™...
Page 18: Vehicle Setup
SILVERWOLF SMARTPHONE APP ™ ™ IN THE MENU AC-PM MOTOR TECHNOLOGY BY ACCELERATED SYSTEMS INC VEHICLE SETUP SILV MADE IN CANADA Before using the Vehicle make sure to accurately set the FAILURE TO FOLLOW THE WARNING! Vehicle specification as shown below!
Page 19: Pre-Set Vehicle Modes
Cable is on the Negative Controller Post In order to access Sport Mode SilverWolf requires you to sign a Liability Waiver. Once it is received and confirmed by SilverWolf an update will be sent to your device that will allow you to unlock Sport Mode.
Page 20: Display Settings
SILVERWOLF SMARTPHONE APP ™ ™ IN THE MENU AC-PM MOTOR TECHNOLOGY BY ACCELERATED SYSTEMS INC DISPLAY SETTINGS SILV MADE IN CANADA Change Language Speedometer Reading : Select MPH or KPH CHECK FOR UPDATES Online Updates to keep the firmware and configuration up to date.
Page 21: On-The-Fly Regen Braking
SILVERWOLF SMARTPHONE APP ™ ™ ADVANCED SETTINGS AC-PM MOTOR TECHNOLOGY BY FAILURE TO FOLLOW THE ACCELERATED SYSTEMS INC FAILURE to follow the WARNINGS below can WARNING! WARNINGS BELOW CAN DAMAGE SILV MADE IN CANADA damage the Vehicle and/or cause SERIOUS...
Page 22 5 Controller Bolts with a required. Torque Wrench to 53in-lbs/6 Nm WARNING: When using the SilverWolf App make sure the Device (Phone or Tablet) is ™ Wire Terminal DO NOT mounted in the Vehicle.
Page 23: Troubleshooting
TROUBLESHOOTING ™ The SilverWolf App includes basic troubleshooting Icons as well as a more detailed diagnostics page. AC-PM MOTOR ™ TECHNOLOGY BY ACCELERATED SYSTEMS INC On the Main Screen a Warning Icon will appear in the yellow Info Ribbon when...
Page 24 Fault. Shows the status and a numerical reading of the Main Components. The Input Voltages & Flags/Vectors Cont’d section provides Current additional Status on Mode the Cart. Settings Current Controller Settings SilverWolf Vehicles Inc. www.silverwolfmotors.com ™...
Page 25 App is not being used or it does not connect, there is a Red Light on the Controller and the Smart Module which will ACCELERATED SYSTEMS INC ™ indicate the status of the cart. MADE IN CANADA Note: Before contacting the dealer or SilverWolf for support, make sure that the Batteries have a full charge. ™ For SilverWolf Support contact support@silverwolfmotors.com.
Page 26: Warranty
MADE IN CANADA SilverWolf™ Vehicles Inc. hereby warrants to the original purchaser of a new motor kit and/or accessories that they shall be free from defects in material and workmanship, under normal use and service, subject to the exclusions and limitations set forth below, for a period of one (1) year from date of original retail purchase to customer or End-User.
Page 27 Disclaimer TECHNOLOGY BY ACCELERATED SYSTEMS INC This limited warranty is exclusive. SilverWolf™ makes no other warranty of any kind, expressed or implied. Any implied SILV MADE IN CANADA warranties of merchantability or fitness for a particular purpose which exceed the obligations or time limits stated in this warranty are hereby disclaimed by SilverWolf™...
