20V MAX BRUSHLESS
1/4" IMPACT DRIVER
3 Year Limited Warranty on Battery and Charger
READ ALL INSTRUCTIONS BEFORE FIRST USE.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
KEEP AWAY FROM CHILDREN.
3042597
Maximum initial battery voltage (measured without a load)
JD509620
is 20 volts. Nominal voltage is 18 volts.
WEAR CSA APPROVED
EYE PROTECTION
5 Year Limited Warranty
WEAR EAR
PROTECTION
WEAR A
FACE MASK
Advertisement
Table of Contents
Related Manuals for Benchmark 1239-300
Summary of Contents for Benchmark 1239-300
- Page 1 20V MAX BRUSHLESS 1/4" IMPACT DRIVER 5 Year Limited Warranty 3 Year Limited Warranty on Battery and Charger READ ALL INSTRUCTIONS BEFORE FIRST USE. KEEP THIS MANUAL FOR FUTURE REFERENCE. KEEP AWAY FROM CHILDREN. 3042597 Maximum initial battery voltage (measured without a load) JD509620 is 20 volts.
-
Page 2: Product Specifications
PRODUCT SPECIFICATIONS 20V MAX BRUSHLESS 2VSR DRILL 2 Variable Speeds 0–2,400 / 0-2600 RPM (no load) 2 Variable Impact Speed 0–2,700/ 0-3,000 BPM Torque 1,800 in/lbs (158 Nm) maximum Hex drive Quick release 1/4" (6.35 mm) Weight 3.5lbs (1.57kg) Battery 20V 2.5Ah Max* Li-ion (Maximum charged battery voltage, measured without load, is 20V with a nominal... -
Page 3: Table Of Contents
1239-300 20V MAX BRUSHLESS 1/4" IMPACT DRIVER TABLE OF CONTENTS Product Specifications .................. 1 Table of Contents ..................2 General Safety Instructions ................3 Eye, Ear & Lung Protection ................3 Electrical Safety .................... 4 Power Tool Safety ..................4 Work Area Safety .................. -
Page 4: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS WARNING: Before using this tool or any of its accessories, read this manual and follow all Safety Rules and Operating Instructions. The important precautions, safeguards and instructions appearing in this manual are not meant to cover all possible situations. -
Page 5: Electrical Safety
1239-300 20V MAX BRUSHLESS 1/4" IMPACT DRIVER WARNING: Ventilation openings in batteries and chargers must always be open to allow cooling air to circulate freely. Air vents that are blocked, restricted or covered may result in the battery or charger overheating. -
Page 6: Power Tool Use And Care
Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries. connecting to power source and/or battery pack, picking up or carrying the tool. -
Page 7: Battery Tool Use And Care
1239-300 20V MAX BRUSHLESS 1/4" IMPACT DRIVER Hold power tool by insulated gripping surfaces, when performing an operation where the fastener may contact hidden wiring or its own cord. Fasteners contacting a “live” wire may make exposed metal parts of the power tool “live”... - Page 8 WARNING: If any part is missing or damaged, do not plug the tool into the power source or install any accessory until the missing or damaged part is replaced. Use impact sockets and accessories that are designed for use with an impact driver. Do not use chrome plated sockets and accessories.
-
Page 9: Battery & Charger Safety
1239-300 20V MAX BRUSHLESS 1/4" IMPACT DRIVER BATTERY & CHARGER SAFETY WARNING: Only use the charger supplied with this kit to charge the 20V Max* Li-ion batteries for this tool. Charging any other batteries may damage the charger and possibly cause serious injury. -
Page 10: Battery Pack Recycling
BATTERY PACK RECYCLING To preserve our natural resources, please recycle or dispose of batteries properly. The batteries charged by this charger may contain chemicals and metals that are harmful to the environment. Never dispose of re-chargeable batteries in your normal household garbage or in landfill sites as they will add to the pollution of the environment. -
Page 11: Symbols
1239-300 20V MAX BRUSHLESS 1/4" IMPACT DRIVER SYMBOLS WARNING: Some of the following symbols may appear on the impact driver Study these symbols and learn their meaning. Proper interpretation of these Three-phase alternating current VOLTS with neutral Amperes Direct current... -
Page 12: Know Your 20V Max Brushless 2Vs Impact Driver
KNOW YOUR 20V MAX BRUSHLESS 2VS IMPACT DRIVER Quick 3 LED Forward / Reverse Air vents Release Work Light Switch Trigger Speed Selector Battery Belt Switch Buttons 5350-023 Clip Battery charger 5350-010 Air Vents Red LED Green LED... -
Page 13: Assembly And Operation
1239-300 20V MAX BRUSHLESS 1/4" IMPACT DRIVER ASSEMBLY AND OPERATION CHECKING THE BATTERY CHARGE STATUS The level of charge remaining in the battery can be checked by using the battery LED power indicator that is contained on the end of the battery. -
Page 14: Installing A Battery In The Impact Driver
NOTE: a) When the charger is plugged into the wall receptacle and NO battery is on the charger, the green indicator light (5) will turn ON indicating the charger is “live”. b) When a discharged battery is installed on the charger, the green indicator light will turn OFF and the red indicator light (6) will FLASH. -
Page 15: Installing Screwdriver Bits And Sockets
1239-300 20V MAX BRUSHLESS 1/4" IMPACT DRIVER FIG. 3 INSTALLING SCREWDRIVER BITS AND SOCKETS WARNING: Never hold the impact driver with your fingers near the switch while changing the screwdriver bits. Accidentally touching the switch may start the tool and possibly cause an injury. -
Page 16: Forward/Reverse Switch
FIG. 4 FORWARD/REVERSE SWITCH The forward/reverse switch (1) is conveniently mounted above the trigger switch (2) (Fig. 5). To make the impact driver rotate clockwise for driving screws, push the forward/reverse switch to the left. To make the driver rotate counter-clockwise for removing screws, push the forward/reverse switch to the right NOTE: a) Never change the position of the forward/ reverse switch while the chuck is turning. -
Page 17: Speed And Auto-Stop Control
1239-300 20V MAX BRUSHLESS 1/4" IMPACT DRIVER SPEED AND AUTO-STOP CONTROL (Located on tool foot) Push the selection button when the tool is in forward for low or high speeds. Push to select the auto-stop feature when the tool is in reverse. -
Page 18: Driving Screws
5. If using a flat head screw, counter-sink the hole (4) so the head of the screw will be flush with the surface when fully driven into place. FIG. 8 FIG. 9 DRIVING SCREWS When driving screws, care must be taken to use a bit that correctly fits the head of the screw being driven. -
Page 19: Installing Nut Drivers For 3/16" To 3/8" Nuts
1239-300 20V MAX BRUSHLESS 1/4" IMPACT DRIVER FIG. 10 This impact driver may be used with nut drivers and impact sockets. Although these accessories are NOT included with this tool, they may be purchased separately. WARNING: Nut drivers, socket adaptor and sockets MUST be impact rated and include the ANSI locking groove. -
Page 20: Removing Nuts
REMOVING NUTS 1. Press the forward/reverse button to the RIGHT for removing nuts (Fig. 5). 2. Place the socket fully onto the nut. 3. Hold the nut driver socket and impact driver firmly against the nut with both hands. With the nut driver aligned with the nut, squeeze the trigger switch to start the impact driver and remove the nut. -
Page 21: Maintenance
1239-300 20V MAX BRUSHLESS 1/4" IMPACT DRIVER MAINTENANCE GENERAL WARNING: When servicing, use only identical replacement parts. The use of any other part may create a hazard or cause product damage. DO NOT use solvents when cleaning plastic parts. Plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use. -
Page 22: Battery Pack Removal And Preparation For Recycling
NOTE: A fully charged battery will lose about 2% of its charge per month during storage. BATTERY PACK REMOVAL AND PREPARATION FOR RECYCLING To preserve our natural resources, please recycle or dispose of batteries properly. The batteries supplied with this tool may contain chemicals and metals that are harmful to the environment. -
Page 23: Exploded View
1239-300 20V MAX BRUSHLESS 1/4" IMPACT DRIVER EXPLODED VIEW... -
Page 24: Parts List
PARTS LIST Always order by part number. KEY # PART # PART NAME / QUANTITY KEY # PART # PART NAME / QUANTITY 4030010263 ST3 9 X 25 / 4 2010090070 Inner ring / 1 3140100011 Rubber sleeve / 1 4020010007 Gear box / 1 4020020017 M3X8 / 2 2020010027 Motor gear / 1... -
Page 25: Warranty
20V MAX BRUSHLESS 1/4" IMPACT DRIVER WARRANTY If this Benchmark tool fails due to a defect in material or workmanship within five years from the date of purchase, return it to any Home Hardware store with the original bill of sale for exchange. 3-year warranty for the battery and charger. This warranty does not include expendable parts including but not limited to blades, brushes, belts, light bulbs. - Page 26 20V MAX BRUSHLESS 1/4" IMPACT DRIVER 5 Year Limited Warranty 3 Year Limited Warranty on Battery and Charger 1239-300 BENCHMARK TOOLS CANADA Made in China ST. JACOBS, ONTARIO N0B 2N0 © 2020 Home Hardware Stores Limited CUSTOMER SERVICE/TECH SUPPORT 1-866-349-8665 * This Benchmark product carries a five (5) year LIMITED warranty against defects...
