- Page 1 tSec Multi-Technology Card Reader Installation Manual...
- Page 2 Protege® and the Protege® Logo are registered trademarks of Integrated Control Technology Limited. All other brand or product names are trademarks or registered trademarks of their respective holders. Copyright © Integrated Control Technology Limited 2003-2016. All rights reserved. Publication Date: June 2017 PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017...
-
Page 3: Table Of Contents
7.10 Encryption Keys ......................20 7.11 Custom Format ......................21 7.12 Intelligent Tamper ......................22 7.13 Factory Reset ......................22 7.14 Output Mode ....................... 22 7.15 Clone Card Notify ......................22 PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... - Page 4 FCC Compliance Statements ______________________________________________ 29 Industry Canada Statement ________________________________________________ 30 Ordering Information ______________________________________________________ 31 Warranty ________________________________________________________________ 32 Contact _________________________________________________________________ 33 PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017...
-
Page 5: Welcome
Information relating to UL and ULC compliance Bold text enclosed in brackets is used to show a section number or address of a programmable [TEXT] option or information on programming shortcut sequences PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 6: Tsec Editions
Each edition supports either 125KHz, Mifare/DESFire cards or both. The Standard and Extra have the option of a keypad. All models are available in either black or white. Keypad 125KHz Mifare/DESFire Extra PRX-TSEC-EXTRA tSec Extra Card Reader PRX-TSEC-EXTRA-KP tSec Extra Card Reader with Keypad PRX-TSEC-EXTRA-KP-VRC tSec Extra Card Reader with Keypad and Vandal Resistant... - Page 7 PRX-TSEC-STD-DF tSec Standard DESFire Card Reader PRX-TSEC-STD-DF-KP tSec Standard DESFire Card Reader with Keypad PRX-TSEC-STD-DF-KP-VRC tSec Standard DESFire Card Reader with Keypad and Vandal Resistant Cover Mini PRX-TSEC-MINI tSec Mini Card Reader PRX-TSEC-MINI-125 tSec Mini 125KHz Card Reader PRX-TSEC-MINI-DF tSec Mini DESFire Card Reader...
-
Page 8: Mifare Technology
Mifare Desfire Nano Proximity Card Reader (PRX-NPROX-DF) tSec Multi-Technology Standard Card Reader (PRX-TSEC-STD) tSec Multi-Technology Standard Card and PIN Reader (PRX-TSEC-STD-KP) tSec Multi-Technology Extra Card Reader (PRX-TSEC-EXTRA) tSec Multi-Technology Extra Card and PIN Reader (PRX-TSEC-EXTRA-KP) ... -
Page 9: About Ict Secured Mifare Card Format
Mifare Desfire Nano Proximity Card Reader (PRX-NPROX-DF) tSec Multi-Technology Standard Card Reader (PRX-TSEC-STD) tSec Multi-Technology Standard Card and PIN Reader (PRX-TSEC-STD-KP) tSec Multi-Technology Extra Card Reader (PRX-TSEC-EXTRA) tSec Multi-Technology Extra Card and PIN Reader (PRX-TSEC-EXTRA-KP) ... -
Page 10: Mounting
To complete the installation, use the M3 x 8mm Plastite screw provided in the kit to secure and fasten the top case to the bottom mounted case. PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 11: Vandal Resistant Cover Mounting
The vandal resistant covers are suitable for mounting the tSec card readers on interior or exterior walls. In order to use the capacitive touch keypad with the anti-vandal cover, you must use the variant that is provided in the following kits: PRX-TSEC-STD-KP-VRC PRX-TSEC-STD-DF-KP-VRC ... - Page 12 22.6mm / 0.88” 91 / 3.58” 8X 5.2mm / 0.2” Mounting Holes 70mm / 2.75” PRX-SRVC Vandal Resistant Cover PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017...
- Page 13 22.6mm / 0.88” 120mm / 4.72” 8X 5.2mm / 0.2” Mounting Holes 99mm / 3.9” PRX-XRVC Vandal Resistant Cover PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017...
-
Page 14: Wiegand Connection
DO NOT connect the shield wires together at the reader cable splice. With the shield wire already terminated at the reader terminate the shield at the controller. Compatible access control card reader communication formats are: 26-, 34-, and 37-Bit Wiegand. PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 15: Rs-485 Connection
Reader and a second 330 ohm EOL resistor must be inserted between the NA and NB terminals at the other end of the wiring. The RS-485 Connection has not been evaluated for UL/ULC installations. PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 16: Installer Programming
Data entry and the menu times out after 2 minutes of no activity and reverts back to normal activity, any programming changes will be lost. PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 17: 125Khz Reading Mode
ICT & POSTECH Can only read ICT and POSTECH programmed cards POSTECH & HID Can only read POSTECH and HID programmed cards Disable No 125KHz cards will be read PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 18: Desfire Reading Mode
CSN and CSN Reverse modes of operation are not secure. The CSN and ESN numbers found in ISO compliant RFID devices are transmitted without encryption and can be fraudulently generated. The CSN modes are made available for legacy system compatibility and not recommended for new installations. PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 19: Interface
LED and turns on the green LED. Green On The green LED is on by default. Grounding the brown wire turns off the green LED and turns on the blue LED. PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 20: Backlight
Once you have selected the desired key slot you will be prompted to enter the 6 byte hexadecimal encryption FFFFFFFFFFFF key. This key cannot be read out of the reader and to erase a key program in to a key slot. PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 21: Custom Format
. We repeat this 5 times to read the whole set. The trailing data doesn't need to be read so it can be ignored. %48u%bs%bs%bs%4u%bc%4u%bc%4u%bc%4u%bc%4u%bc This gives the complete format string: PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 22: Intelligent Tamper
If this setting is enabled and a non-standard Mifare compatible card is presented, the reader modifies the card so it cannot be read. To toggle Clone Card Destroy, press the 3 key. PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 23: Custom Rs-485 Format
In 125kHz programming mode, badge the programming card 12 times to restart the card reader. The Restart function immediately causes the card reader to exit programming mode and restart. PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 24: Technical Diagram
10mm Cable Hole tSec Mini tSec Standard tSec Extra 10mm Cable Hole 4.5mm Screw Hole 4.5mm Screw Hole 45mm / 1.77” (tSec Standard / tSec Mini) 73mm / 2.87” ( tSec Extra) PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 25: Technical Specifications
The size of conductor used for the supply of power to the unit should be adequate to prevent voltage drop at the terminals of no more than 5% of the rated supply voltage. Specifications are subject to change without notice, please visit www.ict.co for updated information. PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 26: New Zealand And Australia
10 New Zealand and Australia Intentional Transmitter Product Statement The R-NZ compliance label indicates that the supplier of the device asserts that it complies with all applicable standards. PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 27: European Standards
Equipment Class: Fixed EN 50131-1:2006, EN 50131-3:2009, EN 50131-6:2008 Recognition class 2 (for readers without a keypad) Recognition class 3 (for readers with a keypad) Access class B EN 50133-1:1998 PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 28: Ul And Ulc Installation Requirements
If fire resistance is required for door assembly, portal locking device(s) must be evaluated to UL10B or UL10C. Must be installed with UL 1034 Listed electronic locks for UL installations. Input power must be supplied by a Class 2 or power limited device. PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 29: Fcc Compliance Statements
NOTE: THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 30: Industry Canada Statement
14 Industry Canada Statement This class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 31: Ordering Information
PRX-TSEC-EXTRA: tSec Extra Card Reader PRX-TSEC-EXTRA-KP: tSec Extra Card Reader with Keypad PRX-TSEC-EXTRA-KP-VRC: tSec Extra Card Reader with Keypad and Vandal Resistant Cover PRX-TSEC-EXTRA-125: tSec Extra 125kHz Card Reader PRX-TSEC-EXTRA-125-KP: tSec Extra 125kHz Card Reader with Keypad ... -
Page 32: Warranty
PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... -
Page 33: Contact
0800 ICT 111 (0800 428 111) - New Zealand 1800 ICT 111 (1800 428 111) - Australia 1855 ICT 9111 (1855 428 9111) - USA/Canada Email: sales@incontrol.co.nz or support@incontrol.co.nz (mailto:support@ict.co) Web: www.ict.co PRX-TSEC tSec Multi-Technology Card Reader Installation Manual | June 2017... - Page 34 APAC Integrated Control Technology Limited 4 John Glenn Avenue, Rosedale, Auckland 0632 PO Box 302-340, North Harbour, Auckland 0751, New Zealand Email: sales@ict.co Toll Free: (0800) 428 111 Phone: 64 (9) 476 7124 AMERICAS Integrated Control Technology (USA) LLC 5265 S Rio Grande Street, Suite 201, Littleton, CO 80120 Email: ussales@ict.co Toll Free: (855) 428 9111 Phone: 720 442 0767 EMEA Integrated Control Technology (Europe) Limited...
