SERVICE MANUAL
This service manual mainly consists of the following items:
• The items which differ from those for the AV-25PX service manual.
• The initial value for each setting item.
For details other than those described in this manual, please refer to the following service manual.
Reference Service Manual: AV-25PX Service Manual (No. 51752, Aug. 2000)
Note: The page in parentheses shows the one for the AV-25PX service manual (No. 51752, Aug. 2000).
HOW TO IDENTIFY MODEL
While referring to the illustration given below, identify model name on the rating label affixed to the rear cover.
COPYRIGHT © 2000 VICTOR COMPANY OF JAPAN, LTD.
COLOUR TELEVISION
AV-25P8
Basic model name
MODEL NO.
XXXXX XXXXXXX
XXXXXXX XXXXX
XXXXXX
XXXXX
XXX XXXXX XXXXX
XXXXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXXXX
SERIAL No.
Identify model name
AV-25P8-PH
(PH)
AV-25P8
XXXX XX XXXX
XXX XX XXXX
XXXXXX–XXX
No. 56070
AV-25P8
AV-25P8
BASIC CHASSIS
JK
No. 56070
1
Sep. 2000
