- Page 1 Festwertregler Montage- und Bedienungsanleitung Constant temperature controller Installation and operating instructions Régulateur à valeur constante Notice de montage et d’utilisation Vaste waarde regelaar Montage- en bedieningshandleiding Regolatore di temperatura costante Istruzioni per il montaggio e l´uso...
-
Page 2: Table Of Contents
Introduction Temperature settings Contents Appearance of the controller Operation mode Initial controller setup Manual mode Step 1 - Heating or cooling operation Language selection mode selector Step 2 - 10.0 Basic settings Hydraulic scheme selection 11.0 Data overview Step 3 - 12.0 Controller parameter Opening of the mixing valve... -
Page 3: Appearance Of The Controller
Appearance of the controller 1. Graphic display 2. Clutch for manual operation. 3. Button Return back. 4. Button Move to left, decreasing. 5. Button Menu entry, confirmation of selection. 6. Button Move to right, increasing. 7. Button Help. 8. LED indication - valve rotation right. 9. -
Page 4: Initial Controller Setup
Constant temperature controllers are equipped with an innovative solution, which allows Initial controller setup initial setup of the controller in only three steps. When you connect the controller to the power supply for the first time, the software ver- sion is shown. Next, the first step appears on the screen. Using buttons you select the required Step 1 -... -
Page 5: Graphic Lcd Display
Graphic LCD display All important data of controller operation are shown on the graphic LCD display. Description and design of the main display Notifications and warnings. Controller mode. Controller mode. Temperature, protection functions and overview of other data. Display of information on the screen: The controller mode, notifications and warnings are displayed in the upper third of the display. -
Page 6: Descpription Of Symbols
Descpription of symbols on the display Symbol Description Controler mode symbols Heating Cooling Automatic mode Stand by Manual mode Symbol Description Temperature and other data symbols Measured temperature Set point or calculated temperature Supply temperature Boiler temperature Stand- pipe temperature Stand- pipe temperature Boiler return temperature Temperature measured by the sensor T1, T2... -
Page 7: Display For Help, Notices And Warnings
By pressing the button the screen for help, messages and warnings will be oppened in Display for help, which the following icons are available. notices and warnings Short manual Short manual for use of the controller. Controller version Overview of controller type and software version. Notifications Log of exceeded maximum temperatures and activated protection functions. -
Page 8: Menu Structure
Menu structure TEMPERATURE SETTINGS and description Set-point temperature OPERATION MODE Automatic operation Switch-off Select Heating / Cooling mode Manual operation BASIC PARAMETERS Language selection Time and date DISPLAY SETTINGS Duration of active display illumination and menu autoexit DATA OVERVIEW Diagrams of measured temperatures by days for last week Diagrams of measured temperatures for current day Output operation time counter* Special service data... -
Page 9: Manual Mode
In the menu only the temperatures are displayed, where you can set the Temperature settings set-point temperature by the selected hydraulic scheme. By pressing buttons you choose the required temperature, and a new window opens: Current value of set-point temperature (numeric mode) Value of the last Graphic review... -
Page 10: Heating Or Cooling Operation
This mode is used for testing the system or in case Manual mode of malfunction. Every output can be manually acti- vated or deactivated. Move with the buttons between the in- dividual outputs R1, M- or M +. The output, which you want to change is selected by pressing the but- ON, OFF or AUTO starts flashing. -
Page 11: Data Overview
The following settings are available: Data overview Time of active screen illumination and autoexit from menu to the main screen. By pressing buttons and you select and confirm required setting. A new window opens: Graphic current setting value symbol (numeric value) The last confirmed current setting value of setting... -
Page 12: Controller Parameters And
All additional settings and adjustments of controller performance are carried out by 12.1 Controller parameters means of parameters. User-, Service- and parameters are found on the second menu and auxiliary tools screen. The basic parameters are listed in one group P1 - basic parameters. 12.2 Basic parameters Content of basic parameters is displayed as follows:... -
Page 13: Basic Parameters
Basic parameters: Basic parameters 12.2 Para- Function Parameter description Setting Default meter range value P1.1 TEMPERATURE ROUND You set the accuracy of displayed 0- 0.1 °C temperatures. 1- 0.2 °C 2- 0.5 °C 3- 1 °C AUT. SHIFT OF CLOCK With the help of a calendar, the control- 0- NO P1.2... -
Page 14: Service Parameters
Service parameters are arranged in groups S1 - Basic parameters, S2 - Parame- 12.3 Service parameters ters for the heating circuit. With service parameters it is possible to activate or select many additional functions and adaptations of controller performance. When you select the required para meter group in the menu, a new screen opens: Parameter Parameter value... - Page 15 Modify the value of the unlocked parameter by pressing buttons . The setting Service parameters 12.3 is confirmed by pressing the button . By pressing buttons you can move to another parameter and repeat the procedure. exit parameter settings by pressing the button Warning: Change of service and functional parameters must be carried out only by a properly qualified expert.
- Page 16 12.3 Service parameters Parameters for mixing circuit: Para- Function Parameter description Setting Default meter range value S2.1 MIN. SETPOINT Setting of minimal allowed setpoint 5 ÷ 70 °C TEMPERATURE IN temperature in heating mode. Setpoint 50 °C HEATING MODE temperature cannot be adjusted lower as with this parameter.
- Page 17 Service parameters 12.3 Wartungseinstellungen für den Mischerkreis: Para- Function Parameter description Setting Default meter range value S2.15 BOILER CIRCULATION Setting of delayed circulation pump 30 ÷ 900 PUMP - SWITCH-OFF switch-off when there is no require- seconds DELAY (SECONDS) ment for heating. S2.16 BOILER CIRCULATION This setting determines the difference...
-
Page 18: Factory Settings
12.3 Service parameters Parameters for heat source: Para- Parameterbezeichnung Beschreibung des Parameters Einstellungs- Übernommener meter bereich Wert S3.4 SYSTEM PROTECTION Setting of controller respond in case if 0- WITHOUT IN COOLING MODE T2 sensor is installed. If T2 temperature 1- TMIN - SENSOR T2 is lower as paremeter S3.5, the control- 2- TMAX... -
Page 19: Operation Mode By
Stand pipe temperature sensor isn’t connected or has a malfunction. Operation mode by Mixing valve opens. sensor Failure TABLE: Resistance values for temperature sensors type Pt-1000 Install the regulator inside in a dry place, where it is not exposed to any strong Controller installation electromagnetic fields. -
Page 20: Technical Data
16.0 Controller’s electric connection Esbe, Seltron, Somatherm, Acaso, Afriso, IVAR, PAW, Hora, BRV, IMIT, Barberi, ASCAVMSA LK Armatur, Vexve, Olymp, Hoval ASCAVMSC Centra DR/ZR ASCAVMSD Centra DRU ASCAVMSE Siemens VBI / VBF / VBG / VCI ASCAVMSF Meibes, Wita ASCAVMSG Esbe VRG ASCAVMSH FIRŠT Rotomix... -
Page 21: Disposal Of Old Electrical
Discarding old electrical and electronic equipment (valid for EU member states and other Disposal of old electrical European countries with organized separate waste collection). & electronic equipment This symbol on the product or packaging means the product cannot be treated as a hou- sehold waste and it has to be disposed of separately via designated collection facilities for old electrical and electronic equipment (OEEO). - Page 22 OEG GmbH Industriestraße 1 • D-31840 Hess. Oldendorf info@oeg.net • www.oeg.net Kostenfreie Bestell- und Service-Hotline: Fon 0800 6 343662 • Fax 0800 6 343292 Free service number: Phone 00 800-63 43 66 24 • Fax 00 800-63 43 29 24 N°...
