DupliM 130100 User Manual

Ssd/hdd copy tower sata hard drive duplicators and sanitizers
Hide thumbs Also See for 130100:
Table of Contents

Advertisement

Quick Links

Download this manual
USER GUIDE
DupliM
TM
SSD/HDD Copy Tower SATA
Hard Drive Duplicators and Sanitizers
1:5 SSD/HDD Copy Tower SATA™ Part No. 130100
1:11 SSD/HDD Copy Tower SATA™ Part No. 130101

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 130100 and is the answer not in the manual?

Questions and answers

Related Manuals for DupliM 130100

Summary of Contents for DupliM 130100

  • Page 1 USER GUIDE DupliM SSD/HDD Copy Tower SATA Hard Drive Duplicators and Sanitizers 1:5 SSD/HDD Copy Tower SATA™ Part No. 130100 1:11 SSD/HDD Copy Tower SATA™ Part No. 130101...
  • Page 2 DupliM Inc. 21722 Lassen Street Chatsworth, CA 91311 U.S.A. DupliM™, 1:5 SSD/HDD Copy Tower SATA™ and 1:11 SSD/HDD Copy Tower SATA™ are trademarks of DupliM Inc. Please record the following information to help expedite any warranty claim: Model No. _________________________ Serial No.________________________...
  • Page 3 TV reception. The user is cautioned that changes and/or modifications made to this equipment, without the approval of manufacturer, could void the user’s authority to operate this equipment. www.duplim.com...
  • Page 4 To prevent fire or shock hazard, do not expose the unit to rain or moisture. To avoid electrical shock, do not open the cabinet. Refer servicing to authorized personnel only. Make sure that the manually switchable power supply is set to the proper voltage for your region. www.duplim.com...

  • Page 5: Table Of Contents

    7-Pass Overwrite ..................24 Secure Erase ....................25 Utility .........................26 Show HDD Info ..................26 Update System ...................27 System Info ....................29 Setup ........................30 Specifications ......................41 Troubleshooting ....................42 Technical Support ....................43 Service and Support .................... 44 Technical Support FAX Back Form ..............47 www.duplim.com...
  • Page 6 www.duplim.com...

  • Page 7: Introduction

    ▪ DOD 5220.22-M 7-Pass • Stand Alone Operation • Lockable Quick Load Drive Doors • Supports 3.5” SATA HDDs and Solid State Drives (SSDs) Supports 2.5” SATA HDDs and SSDs with optional DupliM adapters (P/N 450100 ), not included www.duplim.com...

  • Page 8: Key Items

    Introduction Key Items 1:5 SSD/HDD Copy Tower SATA - Part Number: 350125 Controller Display Panel (see page 6) Source Drive Bay Drive Bay Locks Target Drive Bays Drive Activity Lights Power Switch Drive Bay Power LED Handle/Tab www.duplim.com...
  • Page 9 Key Items 1:11 SSD/HDD Copy Tower SATA - Part Number: 350126 Display Panel Controller (see page 6) Source Drive Bay Drive Bay Locks Target Drive Bays Drive Activity Lights Target Drive Bays Power Drive Bay Power LED Switch Handle/Tab www.duplim.com...

  • Page 10: Ssd/Hdd Copy Tower Sata Copy Controller Display Panel And Buttons

    ESC button is used to cancel a selected function, or exit a menu UP arrow is used to scroll backward through functions or menus DOWN arrow is used to scroll forward through functions or menus Duplicator Stand Installation Instructions (130101 only) www.duplim.com...

  • Page 11: Precautions

    Operating the duplicator immediately after a sudden increase in temperature may result in a malfunction. Transportation Keep the original packing materials for future moving or shipping of the SSD/HDD Copy Tower SATA. Replacement packaging may incur charge. www.duplim.com...

  • Page 12: Overview

    Power Up Sequence During the normal power-up sequence of the SSD/HDD Copy Tower SATA, the following information will be displayed. • Figure 1 shows the searching of the station head. DupliM Searching Station  • Figure 2 shows the first function.

  • Page 13: Main Menu

    Overview Main Menu There are eleven main menu items that can be seen in the SSD/HDD Copy Tower SATA Controller Display Panel. These are: DupliM 1. Copy  DupliM 2. Compare  DupliM 3. Copy+Compare  DupliM 4. Overwrite ...

  • Page 14: Subfunctions

    Overview Subfunctions The “Overwrite” menu has six subfunctions. These are: 4.1 Quick Overwrite DupliM 4. Overwrite  4.2 Full Overwrite 4.3 3-Pass 4.4 3-Pass + Verify 4.5 . 7-Pass Overwrite 4.6 Secure Erase The “Utility” menu has three subfunctions. These are: DupliM 5.
  • Page 15 Overview Subfunctions The “Setup” menu has nine subfunctions. These are: DupliM 6. Setup  6.1 Copy Area 6.1.1 System and Files 6.1.2 ALL Partitions 6.2 Skip Error 6.1.3 Whole HDD 6.3.1 Disable 6.3 Erase Master 6.3.2 Enable 6.4.1 Copy Unknown 6.4 Unknown Format...

  • Page 16: Using The Ssd/Hdd Copy Tower Sata

    Swing the drive bay door closed and press the left side of the door until the tab latches. When it latches, a click can be felt and heard. Source Drive Bay Note: If you are duplicating, the source hard disk drive goes in the top bay. www.duplim.com...

  • Page 17: Removing Hard Drives

    Note: Do not attempt to remove the hard drive if the drive activity LED is on. If drive tray door is locked, use the included key to open. To disengage the HDD, swing the drive tray door to the full open position. Pull drive forward and remove drive. www.duplim.com...

  • Page 18: Main Menu

    Load the source HDD and the target HDDs into the SSD/HDD Copy Tower SATA. The system will auto-detect the hard drives. After the drives have been detected, a screen similar to the one below will be displayed. DupliM 1. Copy ...
  • Page 19 Note: The copying speed, capacity and duration may vary from one hard drive to another. Once duplication is complete, a job status screen will be displayed. Pass: 1 Fail: 0 Time: 20:18  www.duplim.com...

  • Page 20: Compare

    With the source and target HDDs loaded use the arrow buttons (or) to select “Compare”. The following screen will be displayed. DupliM 2. Compare  Press OK to begin the comparison. The system will auto-detect the hard drives.
  • Page 21 Using the SSD/HDD Copy Tower SATA Main Menu Compare - Continued When the comparison is completed, a job status screen will be displayed. Pass: 11 Fail: 0 Time: 20:18  www.duplim.com...

  • Page 22: Compare + Compare

    Load the source HDD and the target HDDs into the SSD/HDD Copy Tower SATA. The system will auto-detect the hard drives. After the drives have been detected, a screen similar to the one below will be displayed. DupliM 3. Copy+Compare ...
  • Page 23 Note: The copying speed, capacity and duration may vary from one source hard drive to another. Once duplication is complete, a job status screen will be displayed. Pass: 11 Fail: 0 Time: 20:18  www.duplim.com...

  • Page 24: Overwrite

    Load up to 25 HDDs into the SSD/HDD Copy Tower SATA. The system will auto-detect the hard drives. Using the arrow buttons (or) select “Overwrite”. The following screen will be displayed. DupliM 4. Overwrite  Note: Overwriting the entire capacity of all connected hard drives can take an extended period of time.

  • Page 25: Full Overwrite

    4.2 Full Overwrite  B2. The estimated time elapsed for the Full Overwrite process will be displayed. In Process Elapsed 13:30  B3. When the process is finished, the following screen will be shown. Full Overwrite Pass: 11 Fail: 0  www.duplim.com...

  • Page 26: 3-Pass

    [ 4. Overwrite ] 4.3 3-Pass  C2. The estimated time elapsed for the 3-Pass process will be displayed. In Process Elapsed 13:30  C3. When the process is finished, the following screen will be shown. 3-Pass Pass: 11 Fail: 0  www.duplim.com...

  • Page 27: 3-Pass + Verify

    D2. The estimated time elapsed for the 3-Pass + Verify process will be displayed. In Process Elapsed 13:30  D3. When the process is finished, the following screen will be shown. 3-Pass + Verify Pass: 11 Fail: 0  www.duplim.com...

  • Page 28: 7-Pass Overwrite

    4.5 7-Pass Overwrite  E2. The estimated time elapsed for the 7-Pass process will be displayed. In Process Elapsed 13:30  E3. When the process is finished, the following screen will be shown. 7-Pass Overwrite Pass: 11 Fail: 0  www.duplim.com...

  • Page 29: Secure Erase

    Pass: 11 Fail: 0  Note: Not all hard disk drives support Secure Erase, although most modern SATA HDDs do. If any of your drives do not support Secure Erase, you will see a “Dev. Not Support” error message. www.duplim.com...

  • Page 30: Utility

    You may use the arrow buttons to select hard drives loaded into different bays. With the source and target HDDs loaded use the arrow buttons (or) to select “Utility”. The following screen will be displayed. DupliM 5. Utility  Press OK to select. The following information will be displayed.

  • Page 31: Update System

    Using the SSD/HDD Copy Tower SATA Main Menu Utility - Update System Before attempting to use this feature, please contact DupliM Support. Use the arrow buttons (or) to select “Utility”. The following screen will be displayed. DupliM 5. Utility ...
  • Page 32 B1. To create an Update HDD, select “Create Update HDD” and press OK. [ 5.2 Update System ] 5.2.2 Create Update HDD  B2. The following information will be displayed. Press OK to confirm. Do FORMAT HDD#1 Confirm?  B3. The formatting is now complete. FORMAT Complete!  www.duplim.com...

  • Page 33: System Info

    This function will help you give more technical information sometimes required by technical support. Use the arrow buttons (or) to select “Utility”. The following screen will be displayed. DupliM 5. Utility  Press OK to select. The following information will be displayed.

  • Page 34: Setup

    SATA. It is suggested to use the factory defaults for optimum performance. Use the arrow buttons (or) to select “Setup”. Press OK to select. The following screen will be displayed. DupliM 6. Setup  Use the arrow buttons to scroll between the types of Setup functions: Copy Area, Skip Error, Erase Master, Unknown Format, Transfer Rate, Buzzer, Language, Advanced Setup, and Restore Default.
  • Page 35 6.1.2 ALL Partitions  Whole HDD: This function will copy the complete HDD including free space. If you need to also copy HPA, please refer to Advanced Setup on page 39. [ 6.1 Copy Area ] 6.1.3 Whole HDD  www.duplim.com...
  • Page 36 This function will set the duplicator to be able to overwrite the source drive when preforming any overwrite function. In the Setup menu, use the arrow buttons (or) to select “Skip Error”. The following screen will be displayed. Press OK to select. [ 6. Setup ] 6.2 Skip Error  www.duplim.com...
  • Page 37 6.3 Erase Master  Press OK to select. Use the arrow buttons to scroll between Enable or Disable options. 6.3 Erase Master Enable  6.3 Erase Master Disable  Press OK to Enable or Disable the erasing of the master disc. www.duplim.com...
  • Page 38 Press OK to select. Use the arrow buttons to scroll between the Copy Unknown or Skip Unknown options. [ Unknown Format ] Copy Unknown  [ Unknown Format ] Skip Unknown  Press OK to Copy Unknown or Skip Unknown when formatting hard drives. www.duplim.com...
  • Page 39 [ 6. Setup ] 6.6 Buzzer  Press OK to select. Use the arrow buttons to scroll between the Turn On and Mute options. Turn On  Mute  Press OK to turn on or mute the buzzer sound. www.duplim.com...
  • Page 40 Press OK to display the current language selection (the default language is English). Language English  Use the arrow buttons () to toggle through the available options. Once you change a configuration option, remember to press OK to save it. www.duplim.com...
  • Page 41 Using the SSD/HDD Copy Tower SATA Main Menu Setup - Advanced Setup The “Advanced Setup” menu contains additional configuration options for the SSD/ HDD Copy Tower SATA. [ 6. Setup ] 6.8 Advanced Setup  www.duplim.com...
  • Page 42 A1. To edit the Wait HDD Time function, select “Wait HDD Time” and press [ 6.8 Advanced Setup ] 6.8.1 Wait HDD Time  A2. The following information will be displayed. [ Wait HDD Time ] 15 seconds  www.duplim.com...
  • Page 43 B2. The following options will be displayed. [ Copy HPA Area ]  [ Copy HPA Area ] Copy and Settings  B3. Press OK to select your perfered option. After changing a setting, remember to press OK to save it. www.duplim.com...
  • Page 44 The following screen will be displayed. [ 6. Setup ] 6.9 Restore Default  Press OK to select. The following screen will be displayed. Warning: Clear Parameter To Default?  Press OK to clear the parameter to default settings. www.duplim.com...

  • Page 45: Specifications

    Specifications 1:5 SSD/HDD Copy Tower SATA - Part Number: 130100 Operating Temperature: 41°F to 122°F / 5°C to 50°C Humidity: 15% - 80% RH Power Requirements 100V-240V AC, 50/60Hz Dimensions 430 mm x 190 mm x 355 mm (depth x width x height) (16.9”...

  • Page 46: Troubleshooting

    SSD/HDD Copy Tower SATA to become inoperable. If the system is working normally, do not attempt this operation. If the system is already experiencing problems, please contact DupliM for repairs. Startup/Shutdown Do not power off the system while it is performing an operation.

  • Page 47: Technical Support

    Technical Support After reading this User Guide, if you need additional assistance with this product, please contact DupliM Technical Support. Our technical staff will be happy to assist you, but they may need your help to better assist you. Contacting support without all the necessary information can be both time consuming and frustrating.

  • Page 48: Service And Support

    If the product fails during normal and proper use within the warranty period, DupliM Inc. will, at its option, repair or replace the product at no cost (except shipping and insurance). This limited warranty does not...
  • Page 49 (even if DupliM Inc. has been advised of the possibility of such damages). In any event, the liability of DupliM Inc. under this Limited Warranty, for damages to you or any third party, regardless of the form of action or theory of liability, shall not exceed the purchase price you paid for this product.
  • Page 50 Duplicator, to prepay shipping charges, and to use the original shipping container or equivalent. Any service outside the scope of this limited warranty shall be at DupliM Inc.’s or its Authorized Service Provider’s rates and terms then in effect. This warranty gives you specific legal rights; you may also have other rights which vary from state to state.

  • Page 51: Technical Support Fax Back Form

    I am experiencing the following issues with my SATA/HDD Copy Tower SATA: ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ By answering these questions, your problem will be solved more rapidly. Make copies as necessary. You can reach us electronically at: www.DupliM.com on the internet. www.duplim.com...
  • Page 52 Document Number: 140100-140101_UG_ENG_Rev. A Copyright © 2022 Specifications subject to change without notice. DupliM Inc. 21722 Lassen Street Chatsworth, CA 91311 U.S.A.
