Summary of Contents for SANWEI TTR007
- Page 1 TT.Robot TTR007 发球机使用说明书 USER MANUAL...
- Page 2 TTR007 目 录 P2 Accessories & Technical Specification P2标准配件、技术参数 P3-P4安装步骤 P3-P4 Installation P5-P6功能介绍 P5-P6 Functions P7故障处理 P7 Troubleshooting P8注意事项 P8 Precautions P9-P10 Parts Replacement P9-P10配件更换...
- Page 3 TTR007 标准配件 技术参数 Accessories Technical Specification G.W.: 4.5KG 毛重：4.5KG N.W.: 3.3KG 净重：3.3KG Packing Size: 40 x 38 x 37CM 包装体积：长40*宽38*高37CM Rated Voltage: 100-240V 额定电压：100-240V Rated Power: 36W 额定功率：36W Spin: Top Spin, Down Spin, 出球旋转：上旋转、下旋转、 non-spin, Side spin 不旋转、左右侧旋球 Serving Frequency: 40-70/Min 出球频率：40-70/分钟...
- Page 4 TTR007 安装步骤 ①打开包装，检查配件。 ④将储球筒安装到主机的卡位上， ①Unpack and then check 旋转固定即可。 the accessories. ④Fix the ball storage barrel to the main body and rotate it to fix. ⑤取出固定架，安装到标准 球台上，然后将发球机固定 ②将机头连接主机，然后用固定盖 在铁架上 固定，扭上螺丝。 ②Connect the robot head to the ⑤Take out the frame and main body.
- Page 5 TTR007 安装步骤 B. 调节越大，机头的摆头 频率越快。 B. Wider the balls can cover A. 开关和出球频率调整 A. Switch, and serving frequency 开关和出球频率调整 while turning it up B. 摆动频率调整 B. Swing frequency 摆动频率调整 C. 上旋转速调整 C. Top spin speed 上旋转速调整 C. 调节越大，上旋轮转速 D. 下旋转速调整...
- Page 6 TTR007 功能介绍 Tips: When the Swing Frequency is set to 0, Robot will serve to fixed location. When the Swing Frequency is set to 1, Robot will serve to all possible locations on Functions the table. 摆动范围 Swing range 小提示：...
- Page 7 TTR007 功能介绍 Functions Serve directly (1 jump) Robot head swing range 机头 旋 转范 围 Top-Wheel 上 轮 水 平 线 水 平线 horizontal line horizontal line 铜旋钮 Serve indirectly (2 jumps) Copper knob 下轮 发球跳动示意图 1 80 必须松开铜旋钮才能调整机头高低 1 2 1 3 当机头正在摇摆时不要调整...
- Page 8 TTR007 故障处理 Troubleshooting 故障 现象 故障原因 处理 办 法 Fault phenomenon Failure cause Solutions 更 换 电 源 电源 故 障 打 开 电 源机器无反应 Power failure Replace power supply Power and no reaction 插 好 连 线 连线 没 有插好...
- Page 9 40MM 或40+乒乓球，可选用三维品牌训练球或一星以上球。请勿使用太软或者 2. Please use the standard 40+ balls. Better performance with SANWEI® ABS 1 Star Ball or others better than 1 star ball. 不规则乒乓球，避免造成发球机卡球。 Please don’t use the balls that are too soft or irregular to avoid any clamping.
- Page 10 TTR007 更换配件 Parts Replacement 请在干净的环境下使用发球机， A. Change the serving wheel 定时清理发球机灰尘和清洗乒乓球。 ②.拆卸机头侧面4个螺丝 Please use robot in clean environment, clean ①.请检查和确定损坏是上轮发球轮 ②.Disassemble 4 screws from the dust and wash the balls regularly. 还是下轮发球轮 side board ①.Check which driving wheel is damaged Down serving motor ③.然后卸下固定发球轮的螺丝，...
- Page 11 TTR007 Parts Replacement 1. Find out which motor is damaged. 2. After taking out the wheel, 3. Then disassemble screws of motor 4. Cut the positive and negative line. Disassemble the ball wheel first disassemble 2 screws. cover, and take out the damaged motor 更换配件...
