- Page 1 USER'S MANUAL 17.3" FS17 Outdoor TV Support For additional help with your All Season Outdoor TV, please email support@AllSeasonTVs.com...
-
Page 2: Table Of Contents
Table of Contents General Safety Information Safe Use & Warranty Basic Operation Connections Remote Control Selecting the Source Menu Operation Picture Sound Time Setup Channel NOTE:This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. -
Page 3: Safety Information
Read these instructions. Keep these instructions. Heed all warnings. Follow these instructions. Do not use this apparatus near standing water. Clean only with a dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or any other apparatus (including amplifiers) that produce heat. -
Page 4: Safe Use & Warranty
Safe Use Using a Surge Protector It is extremely important for you to use a surge protector with your All Season TV. Electronics are very sensitive to electrical surges, and having a TV outside can make it even more vulnerable. An adequate surge protector will help protect your TV and help lengthen its life. -
Page 5: Basic Operation
How To Turn the TV On or Off 1. After connecting your desired input signal, plug the power cord into the TV and connect the other end into a surge protector and then into a GFI outlet. 2. Press the power button the the TV or the remote control. 3. -
Page 6: Connections
General Description Overview of back panel PC AUDIO POWER INPUT HEADPHONE OUT HDMI VIDEO 1. YPbPr 6. POWER INPUT Component video input with Y/Pb/Pr inputs. 7. HEADPHONE OUT (3.5mm) 2. VIDEO Audio output for connecting headphones or other Composite video input for connecting external audio devices. - Page 7 17/18 SCAN 19/20 21/22 23/24 29/30 25/26 27/28 45/46 39/40 43/44 41/42 53/54 47/48 49/50 51/52 Please Note: Not all buttons will be functional with your TV.
- Page 8 POWER MUTE SLEEP P.MODE S.MODE ASPECT DISPLAY SOURCE MENU EXIT Press this button to go to desired position GOTO Press to turn ON/OFF captions AUDIO SCAN AUTO R(DELETE) D.MENU G(RENAME) SETUP Y(MOVE) D.SISP B(SKIP) TIME SHIFT REC.MENU SUBTITLE REVEAL TEXT...
- Page 9 You can repeatedly play a given portion by operating as follows: To press this button once to define the portionhead. To press this button again to define the portion toe. Then the portion will be played repeatedly. To press this button again to return to normal playback. When stereo program is received, press this button to switch sound system between mono and stereo.
-
Page 10: Selecting The Source
Menu Operations Selecting the Source Press the SOURCE button to display the input source list. Press ▼/▲ buttons to highlight the input source you want to watch. Press the OK button to select the input source. -
Page 11: Picture
Menu Operations Picture Variable Range Default Explanation Item Standard, Dynamic, Picture Mode Standard Soft , User Carefully watch the picture while Contrast 0‐‐‐‐100 adjusting to obtain ideal contrast settings. Bright 0‐‐‐‐100 Adjust to your preference. This item is unavailable under VGA Color 0‐‐‐‐100 and DVI signals. -
Page 12: Sound
Menu Operations Sound Variable Range Default Explanation Item Standard, Music, Sound Mode Standard Movie, User 0‐‐‐100 Bass 0‐‐‐100 Treble 0‐‐‐100 Balance Off / On Surround On / Off Auto Volume Only available under DTV channel SPDIF RAW / PCM and HDMI channel. It is gray under other channels. -
Page 13: Time
Menu Operations Time Variable Range Explanation Default Item Off / 5 Min / 10 Min / 15 Min 30 Min / 45 Min / 60 Min / 90 Min Sleep Timer 120 Min / 180 Min / 240 Min Pacific /Alaska/Hawaii Time Zone Pacific Eastern/Central/Mountain... -
Page 14: Setup
Menu Operations Setup Item Variable Range Default Explanation Menu Language English / French / Spanish English Off/On Transparency Non VGA Inputs: Wide/ Zoom/Cinema/Normal Only can be adjusted when Wide Zoom Mode there is signal. VGA Input： Wide/Normal Noise Reduction Off/Weak/Middle/Strong Middle Stands for the preliminary menu Advanced... -
Page 15: Channel
Menu Operations Channel Default Item Explanation Variable Range Select whether you will be using Air/Cable Air/Cable Cable cable or an over-the-air antenna. Shows all the Select channels to show or hide. Show/Hide channels found. Shows all the Channel No. channels found. Shows all the Channel Label Create a name for channels. - Page 16 Troubleshooting If you have any problem, check the countermeasures for each symptom listed below. The following symptoms may have been caused by inappropriate adjustments rather than actual malfunctions of the TV. If trouble persists, contact your sales person. Symptom Possible Solutions Disconnect the power cord, wait for 60 seconds, then No power reconnect the power cord and turn on the TV.
